Frigidaire FRT21PRCW2 top-mount refrigerator - 5995283529 Parts
Here are the diagrams and repair parts for Frigidaire FRT21PRCW2 top-mount refrigerator - 5995283529, as well as links to manuals and error code tables, if available.
Error CodesBy Schematic
By Part
SELECT DIAGRAM
Browse Parts for FRT21PRCW2 Refrigerators
System diagram
Drier-r12
Part #218541000Replaced by #5303305677
Manufacturer substitutionThis part replaces 218541000. Substitute parts can look different from the original.In Stock$26.1219% OFF Phone Price : $32.12
Qty
Shelves/controls diagram
Appliance Light Bulb, 40-watt
Part #5303001179Replaced by #316538904
Manufacturer substitutionThis part replaces 5303001179. Substitute parts can look different from the original.In Stock$18.4510% OFF Phone Price : $20.45QtyCabinet diagram
Refrigerator Fan Blade
Part #218649000Replaced by #5308000010
Manufacturer substitutionThis part replaces 218649000. Substitute parts can look different from the original.In Stock$29.0417% OFF Phone Price : $35.04QtySystem diagram
Compr-r134a
Part #5303917694Replaced by #5304478809
Manufacturer substitutionThis part replaces 5303917694. Substitute parts can look different from the original.In Stock$465.60$12.00 OFF Phone Price : $477.60QtyCabinet diagram
Refrigerator Motor
Part #218322200Replaced by #5300158289
Manufacturer substitutionThis part replaces 218322200. Substitute parts can look different from the original.In Stock$101.0711% OFF Phone Price : $113.07Qty#NI
All parts diagram
Touch Paint
Part #5303305324Replaced by #5303321319
Manufacturer substitutionThis part replaces 5303305324. Substitute parts can look different from the original.This item is not returnableIn Stock$16.5811% OFF Phone Price : $18.58QtyDoor diagram
Kelvinator Refrigerator Screw
Part #5303314236
The manufacturer no longer makes this part, and there's no substitute part
Door diagram
Refrigerator Door Support
Part #215552601Replaced by #218758602
Manufacturer substitutionThis part replaces 215552601. Substitute parts can look different from the original.This item is not returnableIn Stock$26.5018% OFF Phone Price : $32.50QtyShelves/controls diagram
Refrigerator Screw Roller
Part #215005100Replaced by #215005101
Manufacturer substitutionThis part replaces 215005100. Substitute parts can look different from the original.This item is not returnableIn Stock$16.4211% OFF Phone Price : $18.42QtyCabinet diagram
Refrigerator Grommet
Part #5308009759Replaced by #5304500407
Manufacturer substitutionThis part replaces 5308009759. Substitute parts can look different from the original.This item is not returnableIn Stock$7.6812% OFF Phone Price : $8.68Qty
RECOMMENDED MAINTENANCE PARTS AND ACCESSORIES
Refrigerator Roller Assembly
In Stock
$57.01
Qty
Refrigerator Ice Cube Tray
Part #215667501
This item is not returnable
In Stock
$5.20
16% OFF Phone Price : $6.20
Qty
Refrigerator Cover
In Stock
$45.02
Qty
Refrigerator Roller Assembly
In Stock
$108.65
Qty
Refrigerator Plate
In Stock
$57.65
Qty
Refrigerator Evaporator Insulation
In Stock
$46.91
Qty
