Kenmore 79551022010 refrigerator Parts

The exact cubic-foot capacity for Kenmore side-by-side refrigerator model 79551022010 is listed on the model’s rating label and in the specifications section of the 79551022010 owner's manual. Most Kenmore 795-prefix side-by-side refrigerators are commonly in the 20 to 26 cu. ft. range.

Check these spots first (no tools needed):

• Inside the fresh food compartment on a side wall near the crisper drawers
• Ceiling area inside the refrigerator compartment near the light housing
• Door jamb area (around the hinge side)
• Back exterior near the power cord entry (less common)

The label typically lists model/serial information and may include capacity or a reference to the spec details.

Your 79551022010 owner's manual covers multiple closely related models (795.5102 and 795.5101 families). Use the specifications section for your exact model number to confirm the cubic feet.

Capacity helps you compare storage space accurately and choose correctly sized accessories (like bins and drawers). It also helps when planning airflow clearance and organizing food so the compressor does not run longer than necessary.

If you are ordering replacement parts, we match by model number, not cubic feet. You can order parts for Kenmore 79551022010 from the parts list for this model, or search by model on Sears PartsDirect.

Last updated: February 2026

To clean the condenser coils on your Kenmore 79551022010 side-by-side refrigerator, we unplug the refrigerator, remove the lower rear access cover (if equipped), then vacuum and brush dust off the coils and nearby fan area. Dirty coils make the compressor work harder and can reduce cooling.

• Unplug the refrigerator (or disconnect power at the breaker).
• Pull the refrigerator straight out from the wall to get working room.
• Locate the condenser coil area (commonly behind the lower rear cover or underneath the cabinet).
• Use a coil brush and a vacuum with a crevice tool to remove lint and dust.
• Clean the floor area under and behind the refrigerator.
• Reinstall any rear cover you removed, then plug the refrigerator back in.

For model-specific care and cleaning guidance and safety notes, follow the 79551022010 owner's manual.

Most households should clean refrigerator condenser coils every 6 months. If you have pets, heavy cooking grease, or a dusty utility area, clean them every 3 months.

The manual’s troubleshooting guidance notes that dirty condenser coils restrict heat transfer; that forces longer run times, warmer temperatures, and higher energy use. Keeping coils clean helps protect the sealed system and supports steady refrigerator and freezer performance.

If temperatures are still warm after coil cleaning, check these common causes:

• Doors not sealing (gasket not closing fully)
• Air vents blocked by food packages
• Fan noise or no airflow (evaporator or condenser fan issue)
• Ice maker or dispenser issues affecting airflow in the freezer

If you need replacement parts for this model, order from the parts list for Kenmore 79551022010, or search by model on Sears PartsDirect.

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 79551022010 are not cooling well, ice maker or dispenser issues, water leaks, and door sealing problems. Many symptoms trace back to airflow, door gasket sealing, or water supply; use the 79551022010 owner's manual for model-specific troubleshooting steps.

• Not cooling or temperature swings: restricted airflow, dirty condenser area, or a fan/defrost airflow issue
• Ice maker slow or not making ice: freezer too warm, door left open, or water supply not fully on (allow 24 hours after hookup)
• Small ice cubes: restricted water supply or a clogged shutoff valve feeding the refrigerator
• Doors hard to open: dirty or sticky gaskets, or reopening too quickly after closing (pressure equalization)
• Frost or ice crystals on food: door not sealing or frequent door openings

• Make sure doors close fully and nothing is holding them open.
• Clean gaskets and the surfaces they touch; apply a thin coat of appliance polish or paraffin wax.
• If the door feels “vacuum-sealed,” wait about 5 minutes before reopening.
• Confirm the water supply is connected and turned on; allow 24 hours for ice production after hookup.
• Unplug the refrigerator before cleaning or any repair.

If the dispenser has no water, fill is slow, or the ice maker will not fill after confirming supply is on, the refrigerator water inlet valve 5221JA2006D is a common failure point on this style of refrigerator.

Fixing door sealing, airflow, and water supply early prevents food spoilage, reduces frost buildup, and helps the ice maker run consistently.

Last updated: February 2026

On Kenmore side-by-side refrigerator model 79551022010, the model number is printed on the refrigerator’s identification label inside the fresh food (refrigerator) compartment. You will find that label on the right-hand side wall of the refrigerator compartment.

• Open the refrigerator (fresh food) door, not the freezer door.
• Look along the right interior wall of the refrigerator compartment.
• Check near the front edge where the door gasket meets the cabinet.
• Use a flashlight; the label can be easy to miss in low light.
• Write down both the model number and serial number for parts lookup and service records.

The identification label usually includes both numbers you need.

We use the exact model number to match the correct Kenmore refrigerator parts (like a water inlet valve, thermistor, or door gasket) because small design changes can affect fit and wiring. The model and serial number also help confirm the right version when you reference the 79551022010 owner's manual.

Once you have the model number, you can order parts from the parts list for model 79551022010, or search by model on Sears PartsDirect.

Last updated: February 2026
