Bosch SHV4803UC/07(FD7812-7905,7907-8010) dishwasher Parts

Bosch “Silence Plus 44 dBA” is a noise rating used on multiple Bosch dishwashers, not one single model. For your Bosch dishwasher, the exact model is the E-Nr (model number) printed on the rating label on the door edge or inner door frame; that label is the only reliable way to match “44 dBA” to a specific model.

How to identify the exact model (E-Nr) on a Bosch dishwasher

Look for a sticker or metal tag when you open the door.

• Check the top or side edge of the door (often on the right side)
• Check the inner door frame around the tub opening
• Write down the E-Nr (example format: SHP…/.. or SHV…/..)
• Also note the FD number (production date code) if shown
• Use the E-Nr to match the correct parts list and diagrams

How this relates to model SHV4803UC

The Sears PartsDirect page you are on is for Bosch model SHV4803UC. If your rating label shows SHV4803UC (sometimes with a slash and two digits after it), then this is the correct model family for your dishwasher parts.

Quick check table

What you see	What it means	What to do next
“Silence Plus 44 dBA” only	Noise rating, not a model	Find the E-Nr on the door label
E-Nr starts with SHV	Integrated/built-in style model family	Match the full E-Nr to parts
E-Nr is SHV4803UC (or SHV4803UC/XX)	You have this model family	Use SHV4803UC parts listings

Why it matters

Bosch uses the same “Silence Plus” branding across many series and years. The exact E-Nr determines the correct door latch, drain hose routing, and water inlet components, so you get parts that fit and function correctly.

Helpful next step if your dishwasher will not run

If you are chasing a “Silence Plus” label because the dishwasher is not starting, use our troubleshooting steps in dishwasher wont start video.

Last updated: January 2026

The most common issue we see with Bosch dishwashers like model SHV4803UC is a drain problem (standing water or not draining), followed closely by poor drying (normal for Bosch condensation drying if settings and loading are off). Drain issues usually trace back to a clogged filter area, a kinked/blocked drain path, or a restricted hose.

Most common symptoms and what they usually mean

• Water left in the bottom: drain hose restriction, clogged filter/sump area, or a drain path blockage
• Dishes not drying well: condensation drying behavior, rinse aid low, or plastics holding water
• Stops mid-cycle: door not fully latched, intermittent drain issue, or a control pause after an error
• Fills when it should not: inlet valve not sealing fully or a float/overfill sensing issue
• Leaks: door seal wear, door not closing squarely, or oversudsing

Quick checks you can do first (no tools)

1. Cancel/drain the cycle and listen for the drain pump; a weak or noisy drain often points to a restriction.
2. Inspect the drain hose routing under the sink; remove kinks and confirm a high loop/air gap if used.
3. Clean the filter area and check for debris around the sump.
4. Confirm the door closes firmly; a worn latch can cause intermittent stopping.
5. For drying complaints, use rinse aid and avoid nesting plastics.

Parts that commonly relate to these problems on SHV4803UC

Symptom	Common cause	Part to consider
Not draining / standing water	Restricted or damaged drain line	Drain hose 00263099
Random filling or overfilling behavior	Water inlet not sealing, fill control issues	Valve 00425458 or dishwasher float switch 00165256
Stops mid-cycle / won’t run unless door is pressed	Door not latching consistently	Dishwasher door latch 00419828
Leaks at the door	Worn or deformed seal	Door gasket 00263096

Why it matters

Drain and fill problems can lead to poor cleaning, odors, and repeated cycle interruptions. Addressing restrictions early also helps protect the wash system and prevents water from backing up into the tub.

For error-based troubleshooting, use Bosch dishwasher error codes.

Last updated: January 2026

On a Bosch dishwasher model SHV4803UC, an E22 error typically points to a drain or filter restriction. We do not recommend continuing to run cycles until you clear the blockage; running it anyway can leave dirty water in the tub, reduce cleaning performance, and strain the drain system.

What E22 usually means on a Bosch dishwasher

E22 is most often related to water not draining properly because something is restricting flow.

Common causes to check first:

• Food debris clogging the filter area or sump
• A kinked, clogged, or improperly routed drain hose
• A restriction at the sink drain or garbage disposer connection
• A drain pump area obstruction (glass, labels, seeds)
• A control response to slow draining (water remains in the base)

What to do before you run another cycle

Start with the easiest, highest-impact checks.

• Turn off power to the dishwasher at the breaker before reaching into the sump area
• Remove standing water (if present) so you can inspect the filter area
• Clean the filter and screen area thoroughly; reinstall securely
• Inspect the drain hose routing for kinks and clogs; confirm it is not pinched behind the unit
• If the dishwasher still will not drain, inspect the drain path and pump area for obstructions

If you suspect a drain-hose restriction or damage, replacing the hose is often the most direct fix: drain hose 00263099.

Quick “use it or stop” guide

Situation	What we recommend	Why
E22 appears and water remains in the tub	Stop using it and clear the drain/filter restriction	Prevents poor cleaning and pump strain
E22 appears but tub is empty	Run only after cleaning filter and checking hose routing	Avoids repeat faults mid-cycle
E22 returns after cleaning	Stop and troubleshoot drain hose, pump area, and connections	Points to a persistent restriction

Why it matters

A dishwasher depends on steady drain flow to wash and rinse correctly. When draining is restricted, soil can redeposit on dishes, cycles can end with dirty water, and the drain pump can work harder than it should.

Helpful DIY resources

• Bosch dishwasher error codes
• Dishwasher not draining video

Last updated: January 2026
