Samsung RF266AERS/XAA-01 refrigerator Parts

Yes. For your Samsung RF266AERS refrigerator, we recommend ordering replacement parts directly from the parts list for this model so you get the correct match for your exact configuration. Use the diagrams and part descriptions, then confirm installation details in the owner's manual.

Best way to get the right part for RF266AERS

Because Samsung refrigerators often have multiple versions and revisions, matching by model and part number prevents fit and compatibility issues.

• Find your model number on the rating label and confirm it matches RF266AERS
• Use the model parts list to identify the exact part name and part number
• Compare symptoms to the likely system (ice maker, water filter, door seal, cooling fan)
• Replace only the failed component (not the whole assembly) when appropriate
• Keep your old part until the repair is complete, in case you need to compare connectors or mounting points

Common replacement parts customers order for this model

These are examples of parts available for RF266AERS that often come up in repairs and maintenance:

Problem area	Part you may need	What it affects
No ice or poor ice production	Samsung refrigerator ice maker assembly DA97-07603B	Ice harvest and fill cycle
Slow water flow or bad taste	Samsung refrigerator water filter DA29-00003G	Water quality and dispenser flow
Warm temps or noisy airflow	Refrigerator evaporator fan motor DA31-00146H	Cold air circulation
Leaks or puddles	Refrigerator cabinet drain tube assembly DA97-04049H	Defrost drain routing
Frost or air leaks at doors	Samsung refrigerator door gasket DA63-06542A	Door sealing and efficiency

Why it matters

Ordering by the RF266AERS model parts list helps prevent returns and repeat repairs. A correct-fit Samsung ice maker, water filter, or door gasket restores performance, reduces leaks, and helps the refrigerator maintain stable temperatures.

Last updated: February 2026

The Samsung RF266AERS refrigerator has a total capacity of about 25.8 cubic feet. For the exact breakdown between fresh food and freezer space for your specific configuration, we recommend confirming the specs in the owner's manual.

Capacity details you can expect

Most Samsung bottom-mount (French door) refrigerators in this size class are organized into two main storage zones:

• Fresh food (refrigerator) compartment holds the majority of the space
• Bottom freezer compartment holds the remaining space
• Usable capacity can feel smaller if shelves, bins, or the ice maker take up room
• Overpacking reduces airflow and can cause warm spots
• Door gasket leaks can make temperatures unstable and reduce effective storage

Quick reference

Spec	Value
Model	RF266AERS
Total capacity	25.8 cu. ft.
Refrigerator type	Bottom-mount

Why it matters

Capacity helps you compare models and plan food storage, but day-to-day usable space depends on airflow and how well key parts (like the door seal and ice maker) are working. If you are losing space due to frost buildup or temperature swings, checking the manual’s loading and temperature guidance is the fastest first step.

Last updated: February 2026

The most common ice problem we see on Samsung RF266AERS refrigerators is the ice maker freezing up from ice buildup, which can stop ice production or cause clumping and jams. This usually traces back to restricted water flow, air leaks at the doors, or a failing ice maker component; check the owner's manual for model-specific checks.

Most common causes (and what to check first)

• Water filter restriction: a clogged filter reduces flow and can lead to small cubes, hollow cubes, or slow fill.
• Low household water pressure: the ice maker may not fill correctly, leading to freeze-ups and poor harvest.
• Door seal air leaks: warm, moist air entering the ice room promotes frost and ice buildup.
• Water inlet valve issues: weak or inconsistent fill can cause irregular cube formation and freezing.
• Ice maker wear or internal icing: the assembly can ice up or fail to cycle normally.

Quick troubleshooting steps for RF266AERS

1. Replace the water filter and flush several gallons through the dispenser.
2. Confirm the freezer is holding a steady 0°F (typical target) and avoid frequent door openings.
3. Inspect the door gasket for gaps, tears, or areas not sealing flat; clean the sealing surface.
4. Make sure the ice bin is seated correctly and not overfilled or packed with clumped ice.
5. If the ice maker repeatedly freezes or stops cycling, replacement is often the most reliable fix.

Parts that commonly solve ice problems

Symptom	What it often points to	Part to consider
Slow or no ice, small cubes	Restricted water flow	Samsung refrigerator water filter DA29-00003G
No fill or weak fill	Valve not opening fully	Kenmore pro refrigerator water inlet valve DA62-00914B
Ice maker stops cycling or freezes up repeatedly	Ice maker mechanism issue	Samsung refrigerator ice maker assembly DA97-07603B

Why it matters

Ice buildup is more than an inconvenience; it can cause repeated jams, inconsistent cube size, and extra frost that makes the ice maker work harder. Fixing airflow and water supply issues early helps prevent repeat freeze-ups and protects the dispenser system.

For deeper step-by-step guidance, we recommend our troubleshooting article: why your Samsung fridge stopped making ice and how to fix it.
