What is the top part of a fridge called?
On the Kenmore 25364702400 top-mount refrigerator, the top section is the freezer compartment. It’s the colder compartment designed to keep foods frozen and, on some versions, it can also support an ice maker setup. For layout and use details, follow the 25364702400 owner’s manual.
What the freezer compartment does
- Maintains temperatures cold enough for long-term frozen storage
- Helps freeze fresh items quickly when air can circulate around packages
- Provides door shelves and interior space (interior stays more temperature-stable than the door)
- Works with the fresh food (refrigerator) section through airflow and controls
Freezer vs. refrigerator: quick comparison
| Section | Typical purpose | Best place for | Common mistake |
|---|---|---|---|
| Freezer (top) | Frozen storage | Meat, frozen meals, ice cream (interior) | Overloading with warm food at once |
| Fresh food (bottom) | Chilled storage | Produce, dairy, leftovers | Blocking air vents with tightly packed items |
Tips for better freezing performance
We see the best results when you use the freezer the way it’s designed:
- Leave space between packages so cold air can circulate
- Avoid putting hard-to-freeze items (like ice cream) in the freezer door shelves
- Don’t add too much warm food at one time; it slows freezing and can warm existing frozen food
- Keep the refrigerator level so doors close tightly (leveling guidance is in the 25364702400 installation guide)
Why it matters
Knowing the top compartment is the freezer helps you store foods in the right zone, avoid temperature swings (especially on door shelves), and reduce issues like soft ice cream or thawing at the edges.
Last updated: January 2026
How to tell cubic feet of Kenmore refrigerator by model number?
For Kenmore model 25364702400, the most reliable way to confirm cubic feet is to look up the capacity in the specifications section of the 25364702400 owner's manual. If you only have the model number and no spec sheet, you can still estimate capacity by measuring the interior and converting cubic inches to cubic feet.
Best ways to find cubic feet (in order)
- Check the specifications section in the 25364702400 owner's manual.
- Look for a rating/spec label inside the fresh food compartment (often on a side wall or near the serial plate area).
- Search the model number on the appliance’s spec sheet if you have it from purchase paperwork.
- Estimate capacity by measuring the interior (helpful when labels are missing).
How to estimate cubic feet by measuring
- Empty the compartment you are measuring (refrigerator section and freezer section).
- Measure usable interior:
- Width (inches)
- Depth (inches)
- Height (inches)
- Multiply:
W x D x H = cubic inches - Convert:
cubic inches ÷ 1728 = cubic feet
Quick conversion table
| What you have | What to do | Result |
|---|---|---|
| Interior inches (W x D x H) | Multiply to get cubic inches | Total cubic inches |
| Cubic inches | Divide by 1728 | Cubic feet (approx.) |
What the model number can and cannot tell you
Kenmore model numbers help identify the product family and parts, but they do not consistently encode the exact cubic-foot capacity. For many Kenmore refrigerators that start with 253, the model number points you to the correct manual and specs, which is the dependable way to get the true capacity.
Why it matters
Cubic feet helps you choose correctly sized replacement shelves and bins, compare refrigerator sizes, and understand expected cooling load. It is also useful when planning kitchen space and food storage.
Last updated: January 2026
What is a top mount refrigerator?
A top-mount refrigerator is a classic refrigerator layout where the freezer is on top and the fresh food (refrigerator) section is below. Your Kenmore 25364702400 uses this configuration, which makes everyday refrigerated items easy to reach while keeping frozen foods in the upper compartment.
How a top-mount layout works
In a top-mount design, cold air is produced in the freezer area and then shared with the fresh food section through internal airflow passages and controls.
Common characteristics include:
- Freezer compartment on top, refrigerator compartment below
- Separate temperature controls for fresh food and freezer (varies by model)
- Door swing can often be reversed for better kitchen access (common on this style)
- Designed for straightforward installation clearances and airflow
What to know for installation and airflow
For the Kenmore 25364702400, proper leveling and clearance help the doors seal correctly and keep temperatures stable.
Recommended setup basics:
- Level the refrigerator side-to-side and tilt it slightly back (about 1/4 inch) so doors close reliably
- Allow typical installation clearances for airflow: 3/8 inch at the sides and top, and 1 inch at the back
- If installed next to a wall, leave at least 1/2 inch near the hinge side so the door can swing open
| Setup item | Typical target | Why it matters |
|---|---|---|
| Side/top clearance | 3/8 in. | Helps airflow and easier installation |
| Back clearance | 1 in. | Prevents heat buildup behind the cabinet |
| Cabinet leveling | Slight tilt back | Improves door closing and sealing |
Why it matters
Top-mount refrigerators like the Kenmore 25364702400 are popular because they balance freezer capacity and fresh-food access, and they are usually simpler to install and maintain than more complex configurations.
For model-specific operating details (controls, door reversal notes, and first-time startup steps), use the 25364702400 use & care manual and the 25364702400 installation guide.
Last updated: January 2026
What water filter fits my Kenmore fridge?
Kenmore model 25364702400 only uses a water filter if it is connected to a water supply for an ice maker or dispenser; the correct filter is determined by the filter location and the part number printed on the existing cartridge (or the inline filter on the water line). Use the 25364702400 owner's manual to confirm your refrigerator’s water and ice configuration.
How to find the exact filter your 25364702400 uses
Check these spots in this order; you will quickly narrow it down to the correct replacement.
- Look inside the fresh food compartment for a twist-in or push-in filter cartridge
- Check the base grille for a pull-out or twist-in filter
- Inspect the water line behind the refrigerator for an inline filter canister
- Read the part number printed on the old filter (this is the most accurate match)
- If there is no water line connected and no ice maker kit installed, you do not need a water filter
What we can confirm from the parts list for this model
The available parts list for model 25364702400 includes sealed-system and airflow parts (not a drinking-water filter cartridge). For example, refrigerator filter drier 5303305677 is a sealed-system component and is not a water filter for drinking water.
| Item type | What it filters | Where it’s used | Replace it? |
|---|---|---|---|
| Water filter cartridge / inline water filter | Drinking water to ice maker/dispenser | Inside fridge, base grille, or water line | Yes, routine maintenance |
| Filter drier | Refrigerant in sealed system | Inside sealed system tubing | Technician-only repair |
Replacement tips (avoid leaks and low flow)
- Turn off the household water supply before changing an inline filter
- Fully seat the cartridge until it clicks or stops; partial seating causes leaks
- Flush several gallons of water after replacement to clear air and carbon fines
- If flow is still slow, check for a kinked supply line or a partially closed shutoff valve
For general step-by-step guidance, use how to replace the water filter in a Kenmore refrigerator.
Why it matters
Using the correct filter style for your 25364702400 keeps water flow strong, helps protect the water inlet valve and ice maker from sediment, and prevents leaks caused by a mismatched or improperly seated cartridge.
Last updated: January 2026
