Bosch SHV68TL3UC/04 dishwasher Parts

The most common Bosch dishwasher issue we see on the SHV68TL3UC is a drain-related problem: the dishwasher will not drain fully or leaves water in the bottom. In most cases, the fix is clearing a clogged filter area, drain path, or a restricted drain hose.

• Cancel the cycle and run a drain function (if your model offers it).
• Remove and clean the filter area in the tub bottom; clear food debris and labels.
• Check the sink drain/disposer connection for a blockage.
• Inspect the drain hose for kinks, crushing, or a low spot that traps water.
• Make sure the drain hose routing matches the high-loop/air-gap method shown in the installation guide.

A close second to draining issues is filling trouble (no water or too little water). If the unit is not filling, verify the shutoff valve is fully open and the supply line is not kinked. If water supply is good, a failed inlet valve is a common cause.

Drain and fill problems can stop the wash cycle, trigger error codes, and leave dishes dirty. Fixing the basics first (filter cleaning, hose routing, water supply) prevents unnecessary part replacement and repeat clogs.

If you are seeing an error code along with the problem, use our Bosch dishwasher error codes reference to narrow it down before replacing parts.

Last updated: February 2026

A Bosch dishwasher typically lasts 10 to 15 years with normal household use and basic care. For your Bosch SHV68TL3UC, keeping water temperature and supply pressure in the recommended range and doing routine cleaning helps you reach the high end of that lifespan; see the SHV68TL3UC installation guide.

• Water quality and temperature: Hot water around 120°F cleans well without reducing detergent performance.
• Water pressure: Consistent supply pressure helps proper filling and wash performance.
• Regular cleaning: Filters, spray arms, and the sump area stay clearer, reducing strain on the circulation system.
• Loading habits: Overloading blocks spray and forces longer, harder-running cycles.
• Small leaks or slow drains: Catching these early prevents bigger pump and control issues.

• Run the hot water at the sink until it is hot before starting a cycle.
• Clean the filter area and check for debris in the sump.
• Inspect spray arms for clogs and clear food particles.
• Use the right detergent amount for your water hardness.
• Watch for slow filling, which can point to a restricted supply or a failing dishwasher water inlet valve 10023852.

A dishwasher that is maintained and supplied with proper hot water and pressure runs shorter, cleans better, and puts less wear on high-cost components like the circulation pump, heater, and electronic controls.

Last updated: February 2026

For your Bosch dishwasher model SHV68TL3UC, we find the correct part number by matching the appliance’s model information from the rating plate to the parts list, then selecting the exact part by name and ID. Use the SHV68TL3UC installation guide to confirm where model information is referenced during service and installation.

On Bosch dishwashers, the rating plate is typically on the door edge or the inner door area. Once you locate it, write down everything exactly as shown.

• Model number (for this unit: SHV68TL3UC)
• FD number (production date code) if listed
• E-Nr (Bosch “E number”) if listed
• Any additional index like “/04” shown on the label

Bosch often uses similar model families; the index (such as “/04”) can change which parts fit.

After you confirm the model information, match the part using the parts list for Bosch SHV68TL3UC and verify by part name plus the Sears PartsDirect part ID.

Common examples for this model include:

• Water fill problems: dishwasher water inlet valve 10023852
• Draining problems: dishwasher drain hose 00744881
• Detergent door issues: dishwasher detergent dispenser assembly 00645208

Use this checklist before ordering:

• Confirm the symptom (leak, no fill, no drain, not cleaning)
• Match the part by part name and part ID (not just a photo)
• Compare your old part’s markings to the listing when possible
• Check whether the part is left/right or front/rear specific
• Verify connections (hose size, electrical plug style) match your original

Using the exact rating-plate information prevents ordering a look-alike part that does not fit your SHV68TL3UC dishwasher, especially when Bosch uses multiple revisions within the same series.

Last updated: February 2026

Yes, repairing a Bosch dishwasher is usually worth it when the unit is mid-life and the fix is a common, contained repair (fill, drain, or wash performance) rather than major electronic or leak damage. For Bosch model SHV68TL3UC, we use the repair cost, age, and the failing part to decide.

• Repair it if the dishwasher is under 8 years old and the repair is under 50% of replacement cost.
• Consider replacement if it is 10+ years old and needs a control board, multiple major parts, or repeated service.
• Repair it when symptoms point to a single serviceable part (no fill, no drain, poor cleaning).
• Replace it when there is cabinet rust-through, chronic leaking, or multiple failures at once.

Labor varies by area, but these part types are common decision points on SHV68TL3UC:

Model-matched examples you can price out:

• Dishwasher water inlet valve 10023852
• Dishwasher electronic control board 00752740

Many “needs repair” calls are actually installation or setup issues. For example, Bosch installation guidance calls for routing the drain hose with a high loop (a portion at least 20 inches above the cabinet floor) to help prevent draining problems. Confirm the basics before spending on parts or service using the SHV68TL3UC installation guide.

• Look for an error code and match it to the likely system (fill, heat, drain) using Bosch dishwasher error codes.
• Verify the dishwasher is getting water and power (dedicated 120V circuit and solid connections).
• Rule out simple causes first: clogged filter area, kinked drain hose, closed water shutoff.
• If the issue is “won’t fill,” the inlet valve is a common suspect.
• If the issue is “won’t drain,” confirm the drain hose routing and check for blockages.

Last updated: February 2026
