Why is my Kenmore refrigerator leaking underneath?
On Kenmore refrigerator model 79572597710, leaking underneath is most often caused by a clogged or frozen defrost drain that overflows into the base area, or a water supply connection that is seeping and dripping down. We recommend checking the defrost drain path and all water line fittings first.
Quick checks that fix most leaks
- Unplug the refrigerator before inspecting internal panels.
- Look for a sheet of ice or standing water under the crisper area (common sign of a blocked defrost drain).
- Inspect the rear water line connection and shutoff valve area for slow drips.
- Confirm the tubing behind the refrigerator is not kinked, rubbing, or vibrating against the cabinet.
- Check the drain pan underneath for cracks, misalignment, or overflow.
Most common causes and what to do
| What you see | Likely cause | What to do next |
|---|---|---|
| Water pooling inside fridge, then leaking to floor | Defrost drain clogged or frozen | Flush the drain with warm water; clear debris with a soft pipe cleaner |
| Drips from back/bottom near water line | Loose compression nut or fitting | Tighten fittings and recheck for leaks (do not overtighten) |
| Leak only when dispensing water or making ice | Water inlet valve or tubing issue | Inspect valve and tubing for cracks; replace the failed part if needed |
| Random puddles, worse in humid weather | Door not sealing well, excess condensation | Clean gaskets and confirm doors close evenly |
Model-specific notes for 79572597710 water leaks
Your manual emphasizes checking for leaks at the water line connections after turning the water on and tightening any connections that leak. Use the 79572597710 owner's manual for the exact water line connection procedure and safety steps.
If the leak traces back to the valve area (usually behind the unit), a failed inlet valve can seep even when not dispensing. For this model, the matching replacement is the lg refrigerator water inlet valve AJU72992601.
Why it matters
Water under a bottom-mount refrigerator can damage flooring and can also freeze into a slab under the freezer drawer, which can interfere with door closing and airflow. Fixing the source early prevents repeat icing and cooling problems.
Last updated: January 2026
What model Kenmore refrigerator do I have?
If you have a Kenmore bottom-mount refrigerator, the fastest way to identify the exact model is to find the model and serial number label on the cabinet (not the door). On Kenmore model 79572597710, the manual notes this label should not be removed; once you read that model number, you can match it to the correct parts and instructions in the 79572597710 owner's manual.
Where to find the model number label
Check these common locations first (use a flashlight and look for a white or silver rating plate):
- Inside the fresh food compartment on a side wall
- On the cabinet frame behind the door gasket area (door open)
- Near or behind the crisper drawers area
- Under the front of the refrigerator (some models store a tech sheet there, so look carefully)
How Kenmore model numbers work (quick guide)
Many Kenmore refrigerators use a prefix that helps identify the manufacturer.
| What you see | What it usually means | Why it helps |
|---|---|---|
| Starts with 795 | Often indicates an LG-built Kenmore refrigerator | Helps narrow down compatible parts and service info |
| Full model like 79572597710 | Your exact configuration | Ensures correct shelves, filters, ice maker, and electronics |
Why it matters
We use the model number to match the correct refrigerator parts and troubleshooting steps. Even small model differences can change the water filter style, ice maker design, or control board version.
After you find the model number
Use the model number to do these next steps:
- Compare it character-for-character (including all digits)
- Record the serial number too (useful for service and production variations)
- Use the model to confirm consumables like the water filter
- If you are troubleshooting, check any display messages and reference a Kenmore error code guide such as Kenmore 795 model bottom freezer refrigerator error codes
Last updated: January 2026
What does DH mean on Kenmore Elite refrigerator?
On Kenmore model 79572597710, dH (often shown as Er dH) indicates a defrost heating problem: the refrigerator is not sensing the expected temperature rise during the defrost cycle. This commonly points to the defrost heater circuit, wiring, or the main control not powering the heater.
What to check first (quick, safe steps)
- Power reset: unplug the refrigerator for 5 minutes, then plug it back in.
- Look for symptoms: heavy frost on the rear freezer panel, warm fresh-food section, weak airflow.
- Confirm doors are sealing: a leaking gasket can cause excess frost that overwhelms defrost.
- Check for blocked vents: avoid packing food tightly against air returns.
- Listen for the evaporator fan: if airflow is poor, cooling and defrost performance suffer.
Likely causes of a dH / Er dH code
In most bottom-mount Kenmore (LG-built) refrigerators, dH is triggered when the unit cannot complete defrost normally.
| What’s failing | What you may notice | Typical fix |
|---|---|---|
| Defrost heater circuit (heater, thermal fuse, wiring) | Frost buildup returns quickly | Test heater circuit; repair wiring or replace failed component |
| Temperature sensing issue (thermistor) | Erratic temps, defrost issues | Test/replace sensor as needed |
| Control not sending power to heater | Repeated dH code after reset | Diagnose control outputs; replace control if confirmed |
When a part is commonly involved
If you have poor airflow or a noisy fan along with frost buildup, the evaporator fan area is a common place to inspect during diagnosis. For this model, a related replacement part is the refrigerator evaporator fan motor EAU63923603.
Why it matters
A defrost heating fault lets frost build up on the evaporator coil, which blocks airflow. That can make the refrigerator section warm, reduce ice production, and force the compressor to run longer than normal.
Use the model-specific troubleshooting and diagnostics
We recommend following the troubleshooting and diagnostics steps in the 79572597710 owner's manual to confirm the failure before replacing parts.
Last updated: January 2026
What is the bottom part of a refrigerator called?
On a Kenmore bottom-mount refrigerator like model 79572597710, the “bottom part” is most often the machine compartment (also called the compressor compartment). It houses major cooling and airflow components, and you may also see a lower cover area that protects vents and wiring.
What you will typically find in the bottom area
The bottom section is where the sealed system and heat-rejection parts usually live. Common components include:
- Compressor (pumps refrigerant through the sealed system)
- Condenser coil (releases heat from the refrigerant)
- Condenser fan and airflow passages (move air across the condenser area)
- Drain pan (catches defrost water so it can evaporate)
- Lower access cover or grille (protects the compartment and directs airflow)
If you need model-specific diagrams and access steps, use the 79572597710 owner's manual.
Names you might hear (and what they mean)
Different people use different terms for the same general area. Here is a quick guide:
| Term people use | What it usually refers to | Where it is |
|---|---|---|
| Machine compartment | Compressor and condenser area | Bottom rear (most common) |
| Compressor compartment | Same as machine compartment | Bottom rear |
| Toe grille / lower grille | Front lower cover for airflow | Bottom front |
| Base / bottom panel | Structural base and lower covers | Bottom front or rear |
Why it matters
Knowing the correct name helps you find the right part and the right instructions. For example, cooling problems often trace back to machine-compartment parts such as the refrigerator compressor TCA38091801 or the refrigerator condenser coil ACG73749403.
Safety and care tips for the bottom area
We recommend these basics before inspecting or cleaning around the bottom of the refrigerator:
- Unplug the refrigerator before removing any lower covers.
- Keep hands and tools away from vents and electrical components.
- Vacuum dust from the condenser cover and vents (a brush attachment works well).
- Do not remove panels that the manual says to leave in place.
- If you see water underneath, check for a clogged defrost drain path.
Last updated: January 2026
