Kenmore 79095261990 electric range Parts

The Kenmore 79095261990 is a standard 30-inch class electric range; most models in this size are about 30 inches wide, roughly 25 to 29 inches deep (not counting the handle), and about 36 inches tall to the cooktop. For the exact dimensions for your unit, use the 79095261990 owner's manual.

How to confirm the exact size on your range

We recommend verifying measurements on the appliance itself because depth and height can vary with leveling legs, rear trim, and door handle style.

• Measure width at the widest point of the cooktop (typically about 30 inches)
• Measure height from floor to cooktop; include leveling legs
• Measure depth from the back to the front; note whether you include the door handle
• Check the model/serial tag location (right side of the oven front frame in the storage compartment) to confirm you are measuring the correct unit

Typical dimensions you can expect (30-inch freestanding range)

Measurement	Typical range	Notes
Width	~29 7/8 to 30 in.	Fits a 30-in. opening in most kitchens
Height	~36 in.	Adjusted by leveling legs
Depth	~25 to 29 in.	Deeper if you include handle and rear trim

Why it matters

Correct dimensions help you avoid fit issues with countertops and cabinets, confirm clearance for the oven door swing, and ensure the power cord and terminal block area have enough space behind the range.

Last updated: February 2026

Your Kenmore range model number is printed on the appliance identification plate; on model 79095261990, that plate is located on the right side of the oven front frame in the storage compartment. Use that exact model number when ordering parts or looking up instructions in the 79095261990 owner's manual.

Where to look on model 79095261990

Pull out the bottom storage drawer and look along the right side of the oven front frame for the identification plate. It lists both the model and serial number.

• Remove the storage drawer for a clear view of the frame
• Look for a sticker or metal plate (often silver or white)
• Record the full model number (include every digit)
• Record the serial number too (helps match production variations)
• Keep the info with your purchase records for future reference

Quick checklist: model number vs. serial number

Item	What it tells you	When you need it
Model number	Exact design and parts fit	Ordering parts, finding diagrams, using the correct manual
Serial number	Production run details	Confirming compatible revisions, service history

Why it matters

Kenmore ranges can look similar across model families (for example, many start with “790”), but parts like the bake element, surface element control switch, or temperature probe can differ. Using the exact model number helps us match the correct replacement part the first time.

If you are ordering a common part

Once you confirm the model number, match the part by description and ID. For example, the oven’s heating issue often points to the bake element 316075103 on this model.

Last updated: February 2026

To reset a Kenmore 79095261990 electric range oven, we turn the oven off, then reset power at the breaker (or unplug) for a few minutes and restore power; after power returns, we reset the clock and reselect the oven function per the 79095261990 owner's manual.

Quick reset steps (most common)

• Turn all surface burners and the oven OFF.
• If the oven is running a cycle, press CLEAR/OFF first.
• Switch the range circuit breaker OFF (or unplug the range).
• Wait 3 to 5 minutes.
• Restore power.
• Reset the clock, then try BAKE again.

If the reset is related to a power outage

Your range is designed so that if power fails, you should turn the range off; when power resumes, you reset the clock and oven function.

What to do

• Confirm all knobs are in OFF.
• Restore power.
• Reset the clock.
• Start a fresh cooking mode (for example, BAKE at 350°F).

If the oven is “stuck” after self-clean

If you needed to stop a self-clean cycle, the control reset is pressing CLEAR, then waiting for the oven to cool for about 1 hour until the door lock indicator goes out before opening the door.

Situation	Best “reset” action	What to expect
Control acting glitchy, no error code	Power reset (breaker/unplug)	Clock needs to be set again
After power outage	Reset clock and reselect function	Oven operates normally once set
Self-clean interrupted	Press CLEAR, wait about 1 hour	Door unlocks after cooling

Why it matters

A power reset clears minor control-board glitches and forces the electronic oven control to reboot. Resetting the clock and selecting a new cooking function ensures the oven starts with a clean, safe command.

Last updated: February 2026

If your Kenmore electric range 79095261990 is not heating, the most common causes are a failed bake or broil element, a bad temperature probe, or a 240V power supply problem (one breaker leg tripped). Start with power and element checks first.

Safety and first checks

Follow the shutdown and power-failure guidance in the 79095261990 owner's manual before testing.

• Turn the double-pole range breaker fully OFF, then ON.
• Let the oven cool completely before touching internal parts.
• Disconnect power before removing panels or testing continuity.
• If you smell burning insulation or see arcing at the cord connection, keep power off.

Most likely causes and fixes

1) Bake or broil element failed

A cracked, blistered, or broken element often tests open with a multimeter.

• Inspect the lower bake element for splits or burn spots.
• Inspect the upper broil element for visible damage.
• With power disconnected, test continuity end-to-end.
• Replace the failed part if it is damaged or reads open.

Helpful part: bake element 316075103

2) Temperature probe problem

A faulty probe can prevent proper heating or cause long preheat times.

• Check the probe connector for a loose plug or damaged wiring.
• If the control shows an error code, use a Kenmore 790 code chart.
• Replace the probe if it tests out of spec.

Helpful part: temperature probe 5304497424

3) Power supply issue (loss of one leg of 240V)

The clock and light can work on 120V, while the oven will not heat correctly without full 240V.

What you see	Most common cause	What to do
No bake and no broil	No 240V supply	Reset breaker; check terminal connections
Broil works, bake does not	Bake element open	Test and replace bake element
Bake works, broil does not	Broil element open	Test broil element

Why it matters

Restoring full 240V power and a closed heating circuit lets the oven reach and hold temperature safely, preventing undercooking and repeated breaker trips.

Last updated: February 2026
