Kenmore 79078653602 gas range Parts

On Kenmore gas range model 79078653602, the model and serial number are printed on an identification plate located on the right-hand side of the oven front frame, inside the storage or warmer drawer compartment (or the lower panel area). Confirm the exact location in the installation guide.

Check these spots in this order:

• Pull out the storage drawer or warmer drawer and look on the right side of the front frame
• Look along the lower front frame area near the drawer opening
• If your range has a lower panel instead of a drawer, check the right-hand lower panel area
• Wipe the area clean; grease can hide the label
• Use a flashlight and look for a plate with Model, Serial, and sometimes a lot number/letter

When you find the plate, record:

• Model number (example format: 790.7865 with additional digits)
• Serial number
• Lot number or letter (if shown)
• Gas type and pressure rating (often listed on the same plate)

Using the exact model and serial information helps us match the correct parts for your range, especially for components like an oven igniter, oven temperature sensor, or surface burner parts where small design changes can affect fit.

Last updated: February 2026

On the Kenmore gas range model 79078653602, the model and serial number are printed on the serial plate located on the right side of the oven front frame, inside the storage drawer or warmer drawer compartment. Use the serial plate information when ordering parts or requesting service.

Pull the drawer out and look along the oven front frame.

• Open the storage drawer (or warmer drawer, depending on your range)
• Look on the right-hand side of the oven front frame
• Check the frame area just inside the drawer opening
• If your range has a lower panel instead of a drawer, check the lower panel area
• Write down the model number, serial number, and any lot number/letter shown

For the exact placement illustration, use the 79078653602 owner's manual.

We use the serial plate details to match the correct Kenmore parts and specifications for your exact build. The identification plate can also list burner ratings, fuel type, and the gas pressure setting the range was adjusted for at the factory.

Last updated: February 2026

Your Kenmore gas range model number is printed on the appliance’s identification plate. For Kenmore model 79078653602, the manual specifies the ID plate is on the right side of the oven front frame, inside the storage drawer or warmer drawer compartment. Confirm it using the owner's manual.

Check these common label locations on Kenmore gas ranges like model 79078653602:

• Inside the storage drawer or warmer drawer compartment (right side of the oven front frame)
• On the oven front frame behind the drawer opening
• Along the oven door jamb area (around the front frame)
• On the back panel near the vent area (varies by design)

1. Turn the range off and let it cool.
2. Pull the storage drawer or warmer drawer fully out.
3. Look on the right side of the front frame for a plate or sticker.
4. Write down the full model number and serial number exactly as shown.

Most Kenmore ranges in this series show a model format like:

We use the exact model number to match the correct parts diagrams and replacement parts (for example, burner components, igniters, and oven sensors) so the fit and electrical or gas connections are right the first time.

Last updated: February 2026

A Kenmore gas range like model 79078653602 typically lasts 15 years with normal household use. Consistent cleaning, good ventilation during high-heat cycles, and fixing ignition or temperature issues early help you get the full service life.

Most gas ranges reach their expected life when these basics are handled:

• Keep burner heads and ports clean so flames stay even.
• Use an exhaust hood or ventilation during smoky cooking and the first self-clean cycle.
• Avoid slamming the oven door; it can damage hinges, seals, and alignment.
• Replace wear items promptly (for example, oven light bulbs and igniters).
• Address temperature problems early to prevent overworking the oven.

Your owner's manual covers care, cleaning, and self-clean guidance. For example, it notes the kitchen should be well ventilated during the first self-clean cycle to help with normal odors.

• Wipe spills after the oven cools; remove heavier spills before self-clean.
• Clean grates and burner caps regularly to prevent poor ignition.
• Check the oven door seal for gaps, tears, or hardening.
• If baking seems off, use the oven temperature adjustment procedure in the manual.

Many problems that feel like the range is “wearing out” are actually part failures.

A 15-year lifespan assumes safe operation and routine maintenance. Keeping ignition, temperature control, and ventilation in good shape helps cooking performance and reduces stress on key components like the gas valve, sensor, and igniters.

Last updated: February 2026

Kenmore is a brand name, and the Kenmore 79078653602 gas range was produced for Sears by a major appliance manufacturer (Kenmore does not operate its own range factory). For this model family (790.7865*, 790.7866*, 790.7867*, etc.), the design and parts sourcing align with Frigidaire/Electrolux-built ranges.

We recommend checking the identification plate and the model prefix details in the owner's manual. The manual notes the ID plate location on the right side of the oven front frame in the storage or warmer drawer compartment.

• Pull out the storage drawer or warming drawer and look on the right side of the oven frame
• Write down the full model number and serial number exactly as shown
• Look for a manufacturer code or prefix information tied to the 790 model series
• Match parts by model number to avoid ordering the wrong igniter, sensor, or valve

Kenmore ranges can be built by different manufacturers across different model series. Knowing who built the unit helps you choose the correct style of gas valve, igniter, and control components for safe fit and performance.

Common examples on this model’s parts list include:

• Frigidaire range oven temperature sensor 316490000 (helps regulate oven temperature)
• Frigidaire range bake igniter 5304534663 (common cause of “no bake heat”)
• Range pressure regulator 5304521339 (critical for proper gas pressure)

If you are diagnosing ignition or gas flow issues, shut off power and the gas supply before accessing internal components. For installation, conversions, or gas supply changes, follow the installation guide.

Last updated: February 2026
