Kenmore 67518528 chest freezer Parts

Yes. A Kenmore chest freezer like model 67518528 is repairable in most cases; common fixes include restoring power, correcting airflow and temperature control issues, and replacing failed electrical or sealed-system components when testing confirms a fault.

What we check first (fast, no-parts steps)

• Confirm the outlet has power and the plug fits tightly.
• Check the temperature control is set colder and the lid is fully sealing.
• Make sure the freezer has clearance around the cabinet for airflow.
• Clean dust from the condenser area (if accessible) to improve cooling.
• Let the freezer run 24 hours after a move or major temperature change.

Common repairable problems and likely causes

Symptom	What it usually points to	What to do next
No power, no lights/sound	Outlet, cord, control, internal wiring	Verify power, then test components with a meter
Runs but not cold enough	Dirty condenser, poor airflow, weak start device, low refrigerant	Clean and check airflow; test start components
Clicking on and off	Start relay/overload, compressor issue	Test start device; compressor diagnosis if needed
Heavy frost or warm spots	Lid gasket leak, frequent openings, defrost/air leak issues	Inspect gasket and lid alignment

When a repair is worth it (and when it is not)

• Worth it: power issues, thermostat/control problems, lid gasket leaks, wiring faults.
• Often higher cost: compressor or refrigerant-system problems (sealed system work).
• Do not keep running: if you smell burning insulation, see melted wiring, or the breaker trips repeatedly.

Tools and safety basics

Unplug the freezer before removing panels or testing parts.

• Multimeter (for continuity/voltage checks)
• Insulated gloves
• Vacuum or coil brush

For electrical troubleshooting, we use guides like how to use a multimeter to test electrical parts video and how to tell if a fuse is blown.

Why it matters

Quick checks and basic maintenance prevent food loss and reduce compressor run time, which helps your Kenmore 67518528 chest freezer cool more consistently and efficiently.

Last updated: February 2026

Yes, many chest freezers have condenser coils that can benefit from cleaning, but some models use a sealed or “skin condenser” design with no exposed coils to brush or vacuum. For Kenmore chest freezer model 67518528, check around the compressor area and exterior cabinet for any visible coil tubing or a condenser fan.

How to tell what your freezer has

Look in these common locations:

• Back lower panel area near the compressor (often behind a cover)
• Bottom rear where dust collects around the compressor compartment
• No visible coils anywhere (often indicates a skin condenser built into the cabinet walls)

If you do not see exposed coils, you still want to keep the compressor area free of dust and lint for good airflow.

Safe cleaning steps (works for most chest freezers)

1. Unplug the freezer.
2. Pull it out so you can access the back and bottom.
3. Vacuum dust from the compressor compartment and any vents.
4. If coils are exposed, gently brush and vacuum them.
5. Restore clearance around the freezer so air can circulate.

What to use

• Soft coil brush or soft paintbrush
• Vacuum with a crevice tool
• Dry cloth (avoid spraying cleaners into the compressor area)

Quick guide: exposed coils vs. no exposed coils

What you see	What it means	What to do
Coil tubing you can touch/see	Traditional condenser coils	Brush and vacuum coils 1 to 2 times per year
No coils visible	Skin condenser (coils in cabinet walls)	Vacuum vents and compressor area; keep airflow clear

Why it matters

Dust buildup makes the sealed system run hotter and longer, which can reduce cooling performance and increase energy use. Keeping the condenser area clean helps the compressor and thermostat maintain stable freezer temperatures.

Helpful DIY resource

If you plan to do any electrical checks while you are back there, use our guide: how to use a multimeter to test electrical parts video.

Last updated: February 2026

On a Kenmore chest freezer like model 67518528, the model number is printed on the appliance’s rating label. We most often see that label on an inside wall near the top rim, but it can also be on an exterior side panel or on the back of the cabinet.

Most common label locations to check

• Inside the freezer on a side wall (often near the top edge)
• Inside near the lid opening or upper rim
• Exterior side panel of the cabinet
• Back of the freezer cabinet (near the power cord area)
• Near the compressor compartment cover (if accessible)

Quick steps to find it fast

1. Unplug the freezer for safety.
2. Open the lid and use a flashlight to scan the upper inside walls.
3. If you do not see a label inside, check the exterior side panels.
4. Pull the freezer forward and look on the back panel.
5. Write down the full model number and any serial number exactly as shown.

What the label usually looks like

What you may see	Why it helps
Model number	Matches the correct parts list and diagrams
Serial number	Helps identify production run details
Electrical ratings (volts/amps)	Useful for diagnosing power and start issues

Why it matters

Using the exact model number (for example, 67518528) helps us match the correct Kenmore chest freezer parts and avoid ordering a look-alike component that will not fit.

For more help identifying the correct number format, use how to find your appliance model number (and what it means for parts).

Last updated: February 2026
