Craftsman 917376541 lawn mower Parts

For Craftsman walk-behind mower model 917376541, the serial number tells you the mower’s build date, but the date is not a universal “MMDDYY” code. We use the serial number from the rear housing decal to identify the manufacturing run, then match it to the model’s production information in the 917376541 owner’s manual.

Where to find the serial number on 917376541

The model and serial numbers are on a decal on the rear of the lawn mower housing.

• Look at the back of the deck (rear housing), not the handle
• Clean grass and dirt off the decal so every character is readable
• Write down both the model number and serial number exactly
• Also record your purchase date if you still have it

How to estimate the mower’s age (practical method)

If you do not have the original receipt, the most reliable approach is to use the serial number plus the engine information and parts history.

• Compare the serial number to any date or batch markings on the decal
• Check the engine model family (many 917376541 units use a Honda GCV160 series engine) and note any engine date label
• If the mower has had major drive repairs, note when parts like the belt or transmission were replaced
• Use your purchase date as the “in-service” date if it is available

Quick age estimate guide

What you have	What it tells you	Best use
Purchase date	When it started service	Warranty and maintenance timing
Serial number	Manufacturing run identifier	Best for build-date lookup
Engine label	Engine build window	Cross-checking mower age

Why it matters

Knowing the approximate age helps us pick the right replacement parts and maintenance intervals for your Craftsman mower, especially for wear items like the blade, drive belt, and drive system.

Parts commonly tied to age and wear

• Husqvarna lawn mower 22-inch deck 3-in-1 blade 532421825 (cut quality and vibration)
• Lawn mower ground drive belt 532196853 (self-propel speed and slipping)
• Lawn mower transmission assembly 589600601 (loss of drive)

Last updated: January 2026

The most common issues we see with the Craftsman 917376541 walk-behind mower are drive problems (self-propel not pulling), poor cutting or uneven cut, and discharge or bagging issues. These usually trace back to normal wear items like the blade, drive belt, wheels, or chute and mulch-door hardware.

Common symptoms and what they usually point to

• Mower will not self-propel or slips: worn or stretched drive belt, worn drive components, or transmission wear
• Cuts unevenly or leaves strips: dull/bent blade, deck packed with wet grass, wheels set to different heights
• Clumps grass or blows out the side: clogged deck, damaged deflector, weak chute springs, mulch door not sealing
• Bagging is poor: bag frame not seated, chute restriction, wet grass, blade not lifting properly
• Vibration: bent blade, loose blade hardware, debris wrapped around the blade adapter area

Quick checks we recommend first

1. Shut the engine off and disconnect the spark plug wire.
2. Tip the mower safely (air filter and carburetor side up) and clear packed grass from the deck.
3. Confirm all four wheels are set to the same cutting height.
4. Inspect the blade for nicks, bends, and heavy rounding.
5. Check the drive belt for glazing, cracking, or looseness.

Parts that commonly solve these problems

Symptom	Common wear part	Example part for this model
Poor cut, clumping, vibration	Blade	Husqvarna lawn mower 22-inch deck 3-in-1 blade 532421825
No self-propel or slipping	Drive belt	Lawn mower ground drive belt 532196853
Side discharge not closing or flapping	Chute springs	Husqvarna lawn mower discharge chute door spring, left 532419949 and husqvarna lawn mower discharge chute door spring, right 532419948
Bagging/discharge control issues	Mulch door	Mulch door assembly 532420019

Why it matters

Catching these issues early prevents extra wear on the transmission, reduces vibration that can loosen fasteners, and improves cut quality. Routine cleaning and replacing wear parts on schedule keeps the 917376541 mowing safely and consistently.

For model-specific adjustment points, belt routing, and deck cleaning guidance, follow the owner's manual.

Last updated: March 2026

Many Craftsman mowers labeled “6.75” are identified by the full model number on the mower’s ID tag; for the Craftsman walk-behind mower covered here, the model number is 917.376541 (often shown without the dot as 917376541). Use the model number to match the correct blade, belt, and drive parts.

Where to find the model number on the mower

We recommend checking the mower’s model/serial label first, then confirming it against the documentation.

• Look for a sticker or metal tag on the rear of the deck, near the handle mounts, or by the engine area
• Write down the full model number exactly as shown (including any dots)
• Use the model number when ordering parts like a blade, drive belt, or control cable
• Confirm the model number and key specs in the 917376541 owner's manual

“6.75” vs. model number: what’s the difference?

“6.75” is a power rating/marketing label used on some mower engines; it is not a unique identifier for parts. The model number is what ties your Craftsman mower to the correct illustrated parts list.

Label you see	What it tells you	What to use for parts
6.75	General engine power class	Model number (example: 917.376541)
917.376541 / 917376541	Exact mower configuration	Use this every time

Parts that commonly depend on the exact model

If your mower is 917.376541, these are examples of parts that must match the model to fit correctly:

• Blade and blade hardware (deck size and mounting pattern)
• Ground drive belt and drive pulley
• Transmission and drive pawls
• Zone control cable and bail control bar

For example, the correct 22-inch deck 3-in-1 blade for this model is the lawn mower 22-inch deck 3-in-1 blade 532421825.

Why it matters

Using the correct Craftsman model number prevents ordering the wrong walk-behind mower parts, especially for drive system items (belt, transmission, pulleys) where small differences can stop the mower from self-propelling.

Last updated: January 2026
