On Kenmore refrigerator model 10653332300, the quickest “reset” is to restart ice production by turning the ice maker OFF, then ON again (wire shutoff arm down, or the ON/OFF switch to ON). If needed, unplug the refrigerator briefly to reset power, then restore your temperature controls.

Reset steps for model 10653332300

• Turn the ice maker OFF:
  • If your ice maker uses a wire shutoff arm, lift it until it clicks into the OFF (up) position.
  • If your ice maker uses an ON/OFF switch, slide it to OFF (right).
• Wait 30 to 60 seconds.
• Turn the ice maker ON:
  • Lower the wire shutoff arm to the ON (down) position, or slide the switch to ON (left).
• Make sure the freezer door closes tightly and the ice bin is pushed in fully.
• After restoring operation, allow up to 24 hours for the first batch of ice; allow up to 3 days to completely fill the ice container.

If “resetting” does not restore ice production

Most ice maker issues after a reset come down to temperature, water supply, or a jam.

• Confirm the water shutoff valve to the refrigerator is fully open.
• Check for a jammed cube in the ejector area; clear it with a plastic utensil.
• If the refrigerator was turned on before the water line was connected, keep the ice maker OFF until the water line is connected.
• Flush the water system after water hookup.
• If you suspect a fill problem, inspect the inlet valve and supply line; the refrigerator water valve is a common failure point.

Quick checks (what to expect)

What you check	Normal result	What it means if not normal
Ice maker control/arm	ON position	Ice maker will not cycle or fill
Water shutoff valve	Fully open	No water to ice maker
Time after hookup/reset	24 hours	Too soon to judge production
Ice container fill	Up to 3 days	Slow fill can be normal initially

Why it matters

Resetting the ice maker control (arm or switch) restores the correct “make ice” command, but the ice maker still needs proper freezer temperature and steady water flow to produce 70 to 120 cubes per day once fully cooled.

For model-specific control locations and ice bin removal steps, follow the 10653332300 owner's manual. If you need to diagnose water supply to the ice maker, the refrigerator water valve W10822681 is the correct inlet valve kit listed for this model.

Last updated: February 2026

For Kenmore model 10653332300, the most accurate way to get the exact cubic-foot capacity is to use the model and serial label inside the fresh food compartment, then confirm the listed capacity in the 10653332300 owner's manual. That label matches your unit as-built.

Fast ways to find the capacity (best to least)

• Check the model and serial number label on the inside wall of the refrigerator compartment; many units list capacity on the same label or nearby rating information.
• Look up the specifications section in the 10653332300 owner's manual.
• If you are measuring for fit, use typical side-by-side sizing as a guide (most are about 20 to 26 cu. ft.) and then confirm with the label.
• If you are troubleshooting cooling or airflow, focus on temperatures and ventilation clearances rather than capacity.

Where to look inside the refrigerator

On this Kenmore 106. series platform, the manual points you to the model and serial number label located on the inside wall of the refrigerator compartment. Use that label information when comparing specs or ordering parts.

Capacity vs. “usable space” (why numbers can feel off)

Even when you find the official cubic feet, usable storage can vary based on shelves, bins, and accessories.

What you are comparing	What it includes	Why it differs
Advertised capacity (cu. ft.)	Total interior volume	Standardized measurement, not how you pack food
Usable space	Shelves, bins, ice maker space	Ice maker and door bins reduce practical room
Fit in your kitchen	Exterior dimensions and door swing	Needs clearance for ventilation and doors

Why it matters

Knowing the correct cubic feet helps you compare refrigerators fairly, plan food storage, and confirm you are looking at the right specifications for Kenmore 10653332300 (especially when shopping for accessories or organizing shelves and bins).

Last updated: February 2026

You can date a Kenmore refrigerator by using the serial number from the model and serial label inside the fresh food compartment. On Kenmore model 10653332300, the manual confirms the label location; once you have the serial, you can decode the manufacturing date from its date code. See the 10653332300 owner's manual.

Where to find the serial number on model 10653332300

The model and serial number label is located on the inside wall of the refrigerator compartment (fresh food section).

• Open the refrigerator door and look along the inside side walls
• Copy the serial number exactly as printed (include letters and numbers)
• Also record the full model number: 10653332300
• Write down the purchase date from your receipt if you have it
• Take a clear photo of the label if characters are faint

How to decode the manufacture date from the serial number

Kenmore refrigerators use a serial number date code that indicates when the unit was built. The exact letter and number meaning varies by the manufacturer that produced the Kenmore model.

Use this practical approach:

• Identify the first few characters of the serial number (often where the date code appears)
• Compare the serial format to Kenmore 106-series decoding resources and service references
• Use your purchase date as a cross-check to confirm the likely year
• If you are ordering parts, match by model number first, then use the serial to narrow revisions

What to record (and why)

Item to capture	Example	Why it matters
Model number	10653332300	Ensures correct parts diagrams and fit
Serial number	(from label)	Contains the manufacture date code
Purchase date	(receipt)	Confirms the timeframe if the serial code is unclear

Why it matters

Knowing the build date helps us match the correct version of parts used during production runs and plan maintenance on a side-by-side refrigerator (cooling, defrost, and ice maker systems).

Last updated: February 2026

Most Kenmore side-by-side refrigerators are about 32 to 36 inches wide; for your Kenmore 10653332300, confirm the exact cabinet width and required clearances in the 10653332300 owner's manual.

Typical width ranges (what you can expect)

Side-by-side refrigerators are commonly built in a few standard widths. Use these as a quick sizing guide before you measure.

• 32 to 33 inches: space-saving models
• 35 to 36 inches: most common full-size width
• 42 inches: larger, premium configurations (less common)

How to measure width the right way

We recommend measuring both the refrigerator and the opening so you avoid fit issues with doors, trim, and water line hookups.

• Measure the cabinet width (main box), not just the doors
• Measure at front and back of the opening (walls are often not perfectly square)
• Check for baseboard or trim that can reduce usable width
• Plan for door swing clearance next to a wall
• If you have an ice maker, allow room at the back for the water line

Clearance guidance from the manual

Your manual calls out ventilation and swing space that affects the real-world width you need.

What you’re planning for	Typical space to allow	Why it matters
Ventilation at sides and top	about 1/2 inch	Helps cooling efficiency and prevents overheating
Door swing next to a fixed wall	about 2 inches (varies by setup)	Prevents doors from binding and improves access
Back clearance (ice maker/water line)	extra space as needed	Prevents kinked tubing and leaks

Why it matters

Width is not just about sliding the refrigerator into place. Proper clearance helps the condenser and airflow do their job, keeps doors opening smoothly, and reduces the chance of water line pinching if your 10653332300 has an ice maker.

Last updated: February 2026

Yes, replacing the ice maker is usually worth it on a Kenmore 10653332300 when the refrigerator is otherwise cooling well and the problem is isolated to ice production. Start by confirming the ice maker is turned on and the freezer is cold enough; many “bad ice maker” symptoms are caused by setup or water-supply issues (see the 10653332300 owner's manual).

Quick checks before you buy an ice maker

These steps solve a large share of no-ice complaints and cost nothing.

• Make sure the wire shutoff arm is down (ON position) if your model uses an arm.
• If your model uses an ON/OFF switch, verify it is set to ON.
• After a new hookup or restart, allow 72 hours for full ice production.
• Confirm the freezer temperature is set cold enough; adjust in small steps and wait 24 hours between changes.
• Discard the first three batches of ice after installation or long downtime.

When replacement is the right call

Replace the ice maker when the refrigerator cools normally but the ice maker will not cycle, will not fill, or repeatedly jams even after the checks above.

Typical “replace it” symptoms

• No ice production after the freezer is cold and the ice maker is ON
• Ice maker cycles but does not harvest cubes
• Persistent leaking or freezing in the ice mold area
• Stripped coupler or drive issues at the dispenser/auger interface (inspect the refrigerator auger motor coupler WP2220458 if cubes dispense poorly)

Cost vs. value: a simple rule

If the refrigerator is in good overall condition, an ice maker replacement is a high-value repair compared with replacing the entire unit.

Situation	Usually worth replacing the ice maker?
Fridge cools well; only ice is failing	Yes
Multiple cooling problems (warm fridge/freezer)	No, diagnose cooling first
Water dispenser also weak or dead	Diagnose water supply/valve first

Why it matters

An ice maker depends on three basics: cold freezer temps, correct ON/OFF settings, and steady water supply. Verifying those first prevents replacing parts that are not actually failed.

For step-by-step water line and ice maker setup details, use the 10653332300 installation guide.

Last updated: February 2026

The exact overall height, width, and depth for Kenmore model 10653332300 depend on how the refrigerator is configured (handles, hinges, and door position). For the correct fit, we recommend measuring your unit and matching those numbers to the space and clearance guidance in the 10653332300 owner's manual.

How to get accurate dimensions at home

Measure the refrigerator itself, not the cabinet opening. Use a rigid tape measure and record each dimension twice.

• Width: widest point of the cabinet; then measure again including handles
• Height: floor to the highest point (top hinge cover or top of cabinet)
• Depth: back of cabinet to front; then measure again including handles
• Door swing: measure how far doors extend when opened to your normal use angle
• Water line space: allow room behind the unit if it has an ice maker or water dispenser

Clearances to plan for (from the manual)

The manual calls out ventilation and wall clearance that affects real-world space needs.

Location	Minimum clearance	Why it matters
Each side and top	1/2 in.	Ventilation for efficient cooling
Next to a fixed wall	2 in.	Allows doors to swing open
Behind unit (water/ice models)	Extra space	Room for water line connections

Why it matters

A refrigerator that is too tight in the opening can run warmer, sound louder, and have doors that do not open fully. Planning for door swing and water line clearance prevents installation surprises.

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 10653332300 are poor cooling, water leaks, ice maker or dispenser issues, and unusual noises. These usually trace back to airflow restrictions (dirty coils), defrost system trouble, door sealing problems, or a failing fan or water valve; use the 10653332300 owner's manual troubleshooting section to narrow it down.

Quick symptom-to-cause checklist

• Not cooling or warm temps: dirty condenser coils, evaporator fan not running, defrost frost buildup, thermostat/control issue
• Water under the fridge: clogged defrost drain, cracked water tube, leaking water inlet valve
• No ice or slow ice: water supply shutoff, frozen fill tube, bad ice maker, weak inlet valve
• Loud buzzing, rattling, popping, sizzling: normal operating sounds, items vibrating, water valve filling ice maker, defrost cycle sounds
• Doors hard to open or not closing well: dirty or sticky door gaskets, leveling issue

What to check first (fast, high-impact steps)

1. Confirm airflow: keep vents inside clear; do not pack food against the back wall.
2. Clean condenser coils: dust buildup makes the compressor run longer and cooling suffer.
3. Listen for fan operation: you should typically hear airflow from the evaporator fan when the unit is running.
4. Inspect door gaskets: clean sticky gaskets so doors seal and open correctly.
5. Check for ice buildup: heavy frost on the freezer back panel points to a defrost problem.

Common parts involved on this model

Problem area	What fails often	Example part for 10653332300
Defrost system	Defrost thermostat (bi-metal)	Refrigerator defrost bi-metal WPW10225581
Cooling airflow	Condenser fan motor	Refrigerator condenser fan W10181323
Water and ice	Water inlet valve	Refrigerator water valve W10822681
Ice production	Ice maker assembly	Refrigerator ice maker WPW10190961

Why it matters

Catching the root cause early prevents food spoilage, reduces energy use, and avoids secondary damage (for example, a small leak turning into floor damage or a defrost issue turning into a no-cool situation).

For model-specific operating sounds, our guidance matches what’s described in the manual (buzzing during ice maker fill, sizzling during defrost, gurgling at cycle end, and fan airflow noises). Review the care and troubleshooting sections in the 10653332300 owner's manual for cleaning, light bulb changes, and door/leveling checks.

Last updated: February 2026

On Kenmore side-by-side refrigerator model 10653332300, the model number is printed on the model and serial number label located on the inside wall of the refrigerator (fresh food) compartment. Use that label any time you order parts or schedule service; see the 10653332300 owner's manual.

What to look for on the label

The label typically lists both the model number and the serial number together. When you find it, record the information exactly as shown.

• Open the refrigerator door (not the freezer door)
• Check the inside side wall of the fresh food compartment
• Look for a sticker or plate that says Model and Serial
• Write down the full model number (10653332300) and the full serial number
• Keep the information with your purchase date for future reference

Quick ID guide (model vs. serial)

Use this as a simple way to avoid mixing the numbers up.

Item	What it’s used for	Tip
Model number	Matching parts and diagrams	Must match your appliance exactly (example: 10653332300)
Serial number	Manufacturing details and service history	Unique to your specific refrigerator

Why it matters

We use the model number to ensure parts like a thermostat, ice maker, or water valve match your exact Kenmore 106 series configuration. Even small design changes can affect fit and wiring.

Last updated: February 2026

If your Kenmore refrigerator model 10653332300 ice maker is not making ice, the most common causes are the ice maker being turned off (wire shutoff arm up), the freezer not being cold enough yet, or a water supply problem. Use the steps in the 10653332300 owner's manual to confirm the ice maker is ON and the unit has had enough time to produce ice.

Quick checks that fix most “no ice” problems

• Make sure the wire shutoff arm is down (ON). If it is up, the ice maker is off.
• If the ice maker was just installed or reconnected, allow 24 hours for ice to start and up to 72 hours for full production.
• Confirm the freezer is cold; after adjusting controls, wait 24 hours before judging results.
• Check the household water supply line for kinks, pinches, or a closed shutoff valve.
• Look for an ice plug in the fill tube (a frozen fill tube stops water from entering the mold).

What “normal” ice production looks like

Your 10653332300 is designed to ramp up over time. This table helps you decide whether you have a true failure or a timing/temperature issue.

Situation	What to expect	What to do
New install or first start	First ice can take about 24 hours	Keep doors closed, wait 24 hours
Full output after cooling	Up to about 70 to 120 cubes per 24 hours	Give it up to 72 hours
Ice is slow	Fewer batches per day	Adjust freezer colder in small steps, wait 24 hours

When to suspect a part problem

If the ice maker is ON, the freezer is cold, and water supply is good, we focus on the water fill and control components.

• A weak or failed inlet valve can prevent proper filling; consider diagnosing or replacing the refrigerator water valve W10822681.
• If cubes are small or hollow, the valve or supply pressure is often the cause.
• If the ice maker cycles but never fills, the fill tube may be frozen or the valve may not open.

Why it matters

Ice production depends on three basics: cold freezer temperature, water flow, and the ice maker being enabled. Fixing the simple ON/OFF and timing issues first prevents unnecessary part replacement and gets ice back faster.
