What size is a Kenmore refrigerator model 253?
For Kenmore top-mount refrigerator model 25363702201, the exact exterior dimensions vary by the specific 253-series design; the most reliable way to confirm your unit’s height, width, and depth is to match the measurements and clearance notes in the owner's manual.
How to measure your refrigerator correctly
Measure with doors closed, then add space for airflow and door swing.
- Width: measure the cabinet left-to-right (not the door handles)
- Height: floor to top of cabinet (include hinge cover if it sits above the cabinet)
- Depth: front of cabinet to back (then measure to the front of handles separately)
- Door swing clearance: allow extra space on the hinge side if near a wall
- Ventilation clearance: keep required gaps so the compressor can cool properly
Installation clearances to include (important)
Your Kenmore 25363702201 needs clearance for air circulation and easier installation. The manual calls out these typical minimum clearances:
| Location | Minimum clearance |
|---|---|
| Sides and top | 3/8 in. |
| Back | 1 in. |
If your refrigerator has exposed condenser coils/tubing on the back, allow additional space above the cabinet as noted in the manual.
Why it matters
Correct sizing prevents overheating, helps the doors close properly, and reduces frost and temperature problems. Tight installs often lead to poor airflow, warm temperatures, and higher energy use.
Quick tip for “model 253” confusion
“253” is a Kenmore model prefix used across many refrigerator styles and sizes. Always use the full model number 25363702201 when checking specs, ordering parts, or comparing dimensions.
Last updated: February 2026
Who makes Kenmore refrigerator model 25363702201?
Kenmore is a brand name, and different companies have manufactured Kenmore refrigerators over the years. For model 25363702201, the 253 model prefix identifies it as a refrigerator built for Kenmore by Frigidaire (Electrolux/Frigidaire).
How to confirm it on your refrigerator
You can verify the manufacturer by checking the model and serial label inside the fresh food compartment (the use and care guide notes the serial plate is inside the refrigerator compartment). See the owner's manual.
- Look for the full model number: 25363702201
- Confirm the prefix: 253
- Check for a second label that may list a manufacturing source or electrical ratings
- Record the serial number for parts matching and service history
Why the manufacturer matters for parts and repairs
Knowing who built the unit helps match the correct design family for parts like the defrost system, door hardware, and cooling components.
Common part categories where this matters:
- Defrost parts (heater, thermostat, timer)
- Door seal and door closure parts
- Evaporator fan components
- Electrical harnesses and control box parts
Quick reference
| What you see | What it usually means | Why it helps |
|---|---|---|
| Model starts with 253 | Frigidaire-built Kenmore refrigerator | Improves parts compatibility and troubleshooting accuracy |
| Model/serial plate inside fresh food section | Official identification point | Confirms exact model for ordering |
Related parts you might see on this model
If you are ordering repair parts for Kenmore 25363702201, match by model number first, then choose the exact part from the parts list. For example, the refrigerator defrost bi-metal thermostat 5303918202 is one of the defrost components used on many top-mount designs.
Why it matters
Kenmore model numbers are the fastest way to identify the original manufacturer; that prevents ordering the wrong gasket, timer, or electrical part when multiple Kenmore versions look similar.
Last updated: February 2026
What is the upper part of a fridge called?
On a Kenmore 25363702201 top-mount refrigerator, the upper compartment is the freezer. It is designed to keep foods frozen, and its temperature is controlled separately from the fresh food (refrigerator) section on many models.
What the freezer does (and what’s up there)
The freezer compartment is where your refrigerator maintains below-freezing temperatures for long-term storage. In many top-mount designs, it also houses key cooling and defrost components.
Common freezer-related functions include:
- Freezing and storing food at stable, low temperatures
- Helping cool the refrigerator section by circulating cold air
- Running automatic defrost cycles to prevent frost buildup
- Supporting an optional automatic ice maker on some models
How the controls usually work on this model
Your manual explains that the refrigerator and freezer controls can affect temperatures differently: the refrigerator control can influence both compartments, while the freezer control changes only freezer temperature on some models. For exact control locations and recommended starting settings, use the owner's manual.
| Control you adjust | What it changes | Typical use case |
|---|---|---|
| Refrigerator control | Often affects both compartments | Fine-tuning overall cooling |
| Freezer control (some models) | Freezer temperature only | Correcting freezer too warm or too cold |
Why it matters
Knowing the upper section is the freezer helps when you are troubleshooting issues like “freezer cold but fridge warm,” airflow problems from blocked vents, or normal sounds during the defrost cycle (clicking, sizzling, water draining).
Last updated: February 2026
How to tell what model Kenmore refrigerator?
To tell what model Kenmore refrigerator you have, look for the model and serial plate inside the fresh food (refrigerator) compartment. On Kenmore model 25363702201, the Use & Care Guide notes the serial plate is located inside the refrigerator compartment; record the full model number exactly as shown and match it to your parts list and owner's manual.
Where to look for the model number label
Most Kenmore top-mount refrigerators place the model/serial plate in one of these spots:
- Inside the refrigerator compartment on a side wall
- On the ceiling of the fresh food compartment
- Behind or beside the crisper drawers
- Along the door frame (open the door and check the inner liner edges)
- Near the bottom front area behind the toe grille (on some designs)
How to read the number so you get the right parts
Use the complete model number, including every digit. For this refrigerator, the model format starts with 253 (example: 25363702201). That full number is what we use to match the correct shelves, gaskets, controls, and sealed system parts.
Quick check table
| What you see | What it means | What to do next |
|---|---|---|
| Model number starts with 253 | Kenmore refrigerator model family identifier | Use the full model number to look up diagrams and parts |
| Only partial digits are readable | Label is worn or dirty | Clean gently and re-check under bright light |
| Model and serial are both present | Best-case for accuracy | Record both for future repairs |
Tips if the label is hard to read
The manual recommends cleaning the serial plate with only soap and water. After cleaning, try these steps:
- Use a flashlight held at an angle to make faint printing stand out
- Take a close-up photo and zoom in
- Write down the model number first, then the serial number
- Avoid abrasive cleaners that can remove the ink
Why it matters
Kenmore refrigerators share similar styling across many model families, but parts like a door gasket, defrost timer, or light bulb can vary by revision. Using the exact model number helps ensure the replacement part fits and the repair instructions match your unit.
Last updated: February 2026
Can you still get parts for Kenmore refrigerators?
Yes. We still offer replacement parts for Kenmore refrigerators, including model 25363702201. You can match parts by model number and then choose the exact component you need (like a light bulb, door gasket, or defrost part) to restore proper cooling and door sealing.
How to find the right part for your Kenmore 25363702201
Use your model number to avoid ordering a similar-looking part that will not fit.
- Confirm the full model number on the rating label (inside the fresh food section)
- Use the model-based parts list to narrow results to exact-fit items
- Compare the part name and part ID before ordering
- Check whether the part is listed as In Stock or Check Availability
- Use the diagrams to confirm location and mounting style
For model-specific part identification and basic operating guidance, use the owner's manual.
Common parts customers replace on this model
These are examples of parts available for Kenmore 25363702201 that often solve everyday issues:
- Interior light not working: refrigerator light bulb 316538904
- Frost buildup or warm freezer: refrigerator defrost bi-metal thermostat 5303918202 or refrigerator defrost heater 5303918203
- Noisy fan or poor airflow: refrigerator evaporator fan blade 5308000010
- Door not sealing well: refrigerator gasket 241872501 (availability varies)
Quick “symptom to part” guide
| Symptom | What to check first | Example part on this model |
|---|---|---|
| Light out | Bulb, door switch | Refrigerator light bulb |
| Frost on back wall | Defrost heater, thermostat, timer | Defrost heater, bi-metal thermostat |
| Warm fridge, freezer OK | Evaporator fan airflow | Evaporator fan blade |
| Door pops open or leaks air | Gasket, hinges, closure cam | Refrigerator gasket, door closure |
Why it matters
Using the correct Kenmore 25363702201 parts helps maintain safe food temperatures, reduces compressor run time, and prevents problems like frost buildup, leaks, and premature wear on the sealed refrigeration system.
Last updated: February 2026
