Whirlpool ED5PHAXSQ01 side-by-side refrigerator Parts

The Whirlpool ED5PHAXSQ01 is a full-size side-by-side refrigerator. Most Whirlpool side-by-sides in this series measure about 35 1/2 inches wide, 33 to 35 inches deep (depth varies with handles), and 69 to 71 inches tall; use your tape measure for exact fit in your kitchen opening.

Typical size and what to measure

Because exact ED5PHAXSQ01 dimensions are not provided in the page data, we recommend measuring these three points to confirm clearance and door swing:

• Width: cabinet side to cabinet side (also measure with doors slightly open if the opening is tight)
• Depth: cabinet only, then cabinet plus handles
• Height: floor to top of hinge cover (and to the top of the cabinet)
• Clearance: at least 1 inch behind for airflow, plus room above if you have overhead cabinets
• Door swing: space needed for doors to open and bins to clear adjacent walls

Quick reference: common side-by-side ranges

Measurement	Typical range for this style	Why it varies
Width	35 to 36 inches	cabinet design and trim
Depth (with handles)	33 to 35 inches	handle style and door thickness
Height	69 to 71 inches	hinge cover and leveling legs

Why it matters

Correct dimensions prevent installation problems like doors hitting walls, poor airflow that hurts cooling performance, and water line kinks that can affect the dispenser and ice maker.

Related parts that affect “fit” and clearance

If you are troubleshooting space issues (door not closing, rubbing, or alignment), these model-compatible parts are often involved:

• Refrigerator door cam (black) WP2182179 (helps the door close and align)
• Refrigerator gasket panel (white) 2159075 (a poor seal can mimic alignment problems)

Last updated: February 2026

Most Whirlpool refrigerators, including the Whirlpool ED5PHAXSQ01 side-by-side refrigerator, typically last 10 to 18 years. In real-world use, units that get steady airflow, clean condenser coils, and timely part replacement often reach the upper end of that range.

Typical lifespan ranges (what to expect)

Refrigerator life varies most by maintenance and how hard the sealed system has to work.

• Average: 10 to 18 years
• Often replaced early: 8 to 12 years (heavy use, poor ventilation, dirty coils)
• Often lasts longer: 15 to 18 years (good airflow, stable temps, routine cleaning)
• Major repairs tend to show up: after year 10 (ice maker, controls, fans, defrost)

What you notice	What it usually means	What we check first
Warm fridge or freezer	Cooling airflow or defrost issue	Coils, evaporator fan, frost buildup
No ice or slow ice	Water supply or ice maker issue	Filter, inlet valve, ice maker
Water leaking or puddles	Defrost drain or water line issue	Drain path, valve, tubing

Maintenance that extends life

These steps reduce compressor run time and prevent common failures.

• Vacuum the condenser coils and grille area every 6 to 12 months
• Keep 2 to 3 inches of clearance around the cabinet for ventilation
• Replace the water filter on schedule; a clogged filter can reduce flow and strain the valve (see refrigerator water filter EDR3RXD1)
• Confirm doors seal tightly; fix gaps before they cause long run times
• Keep freezer around 0°F and refrigerator around 37°F for stable operation

When a repair makes sense vs replacement

We use a simple rule: if the refrigerator is cooling well and the cabinet is in good shape, replacing common wear parts is usually worthwhile.

• Good repair candidates: ice maker, inlet valve, evaporator fan motor, temperature control
• Bigger decision repairs: compressor, electronic control, evaporator

For water and ice performance issues that can shorten lifespan, follow how to prevent water dispenser and ice maker problems.

Why it matters

A refrigerator that runs longer than necessary (dirty coils, poor airflow, weak door seal) cycles the compressor more often. That extra run time increases energy use and accelerates wear on cooling and defrost components.

Last updated: February 2026

For Whirlpool side-by-side refrigerators like model ED5PHAXSQ01, the biggest problem we see is loss of cooling (warm fridge or freezer). It’s commonly caused by restricted airflow from dirty condenser coils, an evaporator fan issue, or a defrost failure that lets frost block the evaporator.

Quick checks we recommend first

• Confirm the freezer is near 0°F and the fresh food section is near 37°F.
• Make sure vents inside both compartments are not blocked by food packages.
• Listen for the evaporator fan; it should run when the compressor is running.
• Check for heavy frost on the freezer back wall (a strong defrost-system clue).
• Clean condenser coils and verify the condenser fan (if equipped) is running.

Common causes and the parts that often fix them

If basic airflow and settings look good, these are the most frequent “root causes” on side-by-side units:

Symptom	Most likely system	Part that commonly applies on ED5PHAXSQ01
Warm temps, weak airflow	Evaporator airflow	Refrigerator evaporator fan motor WP2315549
Frost-packed freezer back wall, warming	Defrost system	Refrigerator defrost bi-metal WPW10225581 or refrigerator heater WP2323198
No ice and no water flow	Water supply/valve	Refrigerator inlet valve W10408179
Bad taste/slow dispense	Filtration/flow restriction	Refrigerator water filter EDR3RXD1

Why it matters

Cooling problems usually get worse quickly: food safety is affected, the compressor can run nonstop, and ice maker and water dispenser performance often drops because the freezer never stabilizes at the right temperature.

Helpful DIY guidance

• Use our Whirlpool refrigerator error codes reference if your control shows a code or flashing lights.
• If you suspect a water or ice issue is contributing, follow how to replace the water filter in a Whirlpool refrigerator to restore flow and reduce restrictions.

Last updated: February 2026
