Kenmore 25362922015 refrigerator

Kenmore 25362922015 refrigerator Parts

Here are the diagrams and repair parts for Kenmore 25362922015 refrigerator, as well as links to manuals and error code tables, if available.

By Schematic
By Part
SELECT DIAGRAM
?

This is the number corresponding to the part on the diagram / schematic

Browse Parts for 25362922015 Refrigerators

Kenmore Refrigerator 25362922015 FAQs

Kenmore model 25362922015 is a top-mount refrigerator, not an upright freezer. Its exact cubic-foot capacity depends on the specific 253-series variant and is typically listed on the model’s rating label and in the 25362922015 owner's manual.

How to find the exact capacity for model 25362922015

We recommend checking these spots first because they match the appliance’s configuration and serial data:

  • Look on the serial plate inside the fresh food (refrigerator) compartment for the full model and serial information.
  • Check the specifications section in the manual for “capacity” or “cubic feet.”
  • If your unit has a product data sheet behind the toe grille or rear cover, check it for capacity.
  • If you are comparing sizes, measure usable space (shelves and bins) rather than exterior dimensions.
Typical capacity range (helpful for planning)

Most Kenmore 253-series top-mount refrigerators commonly fall into this range:

Appliance type Typical total capacity Notes
Top-mount refrigerator 14 to 20 cu. ft. Varies by width, height, and interior layout
Upright freezer 14 to 21 cu. ft. Different product type than model 25362922015
Why it matters

Capacity is used for fit and storage planning, but it also affects airflow and temperature stability. Using the correct product type (top-mount refrigerator vs. upright freezer) helps you choose the right shelves, door bins, and cooling parts for your Kenmore 25362922015.

Last updated: January 2026

The most common issues we see with the Kenmore 25362922015 top-mount refrigerator are warm temperatures (often airflow or defrost related), unusual fan noise, water leaking or puddles, and door sealing problems that cause frost and poor cooling. Your 25362922015 owner's manual helps confirm normal settings and operating sounds.

Common symptoms and what usually causes them
  • Fridge warm, freezer OK: restricted airflow, a stuck air damper, or evaporator frost buildup
  • Both sections warm: dirty condenser area, condenser fan problem, or sealed system/compressor issue
  • Loud humming, rattling, or clicking: fan blade hitting ice or a failing fan motor
  • Water under the refrigerator or inside: defrost drain issue or ice buildup melting
  • Frost around doors, moisture, or poor cooling: worn or misaligned door gasket
Quick checks we recommend first
  1. Set temps to mid-range and allow 24 hours to stabilize.
  2. Make sure vents are not blocked by food packages.
  3. Listen for the evaporator fan in the freezer; it should run when the compressor runs.
  4. Inspect door gaskets for gaps, tears, or hardened sections.
  5. Clean dust from the condenser area and confirm the condenser fan runs.
Parts commonly involved (when symptoms match)
Symptom Likely area Example part for this model
Fridge warm, freezer cold Airflow control Refrigerator air damper 241542001
Fan noise or no airflow Evaporator fan Refrigerator evaporator fan motor 241854301 or refrigerator evaporator fan blade 5308000010
Frost buildup, warming Defrost system Refrigerator defrost bi-metal thermostat 5303918634 or refrigerator defrost timer 215846604
Warm temps, poor efficiency Condenser airflow Refrigerator condenser fan 242018404
Moisture, frost at door Door seal Frigidaire refrigerator door gasket (white) 242193204 or refrigerator door gasket (black) 241872510
Why it matters

Cooling problems on a top-mount refrigerator often start as airflow or defrost issues; catching them early prevents food spoilage, heavy frost, and extra strain on the compressor.

Last updated: March 2026

The model number and serial number for your Kenmore 25362922015 are printed on the serial plate inside the fresh food (refrigerator) compartment. Open the refrigerator door and look along the interior walls for the rating label; record both numbers for ordering parts and service.

Where to look (fast checklist)
  • Open the refrigerator (not freezer) door
  • Look for a label or plate that lists Model and Serial
  • Check the inside walls of the refrigerator compartment (commonly a side wall)
  • Write down the full model number (it typically starts with 253. on the label)
  • Use only soap and water if you need to clean the label so it stays readable
What the label looks like

The Use & Care Guide notes the serial plate is located inside the refrigerator compartment and is where you will find the model and serial numbers.

Item on label What it’s used for Example format
Model number Matching parts and diagrams 253.XXXXXXX
Serial number Identifying production run Letters and numbers
Why it matters

Using the exact model number from the serial plate prevents ordering the wrong door gasket, light bulb, or fan motor for your specific Kenmore top-mount refrigerator.

For more details on recording the numbers and caring for the serial plate, use the owner's manual.

Last updated: March 2026
