A Kenmore Elite refrigerator like model 79571059011 typically lasts 12 to 15 years. You can often reach the high end of that range by keeping airflow clear, cleaning the condenser area regularly, and fixing water or cooling issues early using the care guidance in the owner's manual.

Typical lifespan and what affects it

Most bottom-mount refrigerators land in the same general window, but these factors make the biggest difference:

• Condenser coil cleanliness (dust buildup makes the compressor run longer)
• Room temperature and ventilation around the cabinet
• Door gasket condition (air leaks increase run time)
• How often doors are opened and how full the compartments are
• Water system upkeep (filter changes help protect the valve and ice maker)

Maintenance that helps you hit 12 to 15 years

Use these habits as your baseline for model 79571059011:

• Vacuum and brush the condenser area on a regular schedule (more often with pets)
• Keep food organized so doors stay open for less time
• Clean door gaskets and confirm the doors seal evenly
• Replace the water filter on schedule; use the correct filter for this model
• Address puddles, slow dispensing, or weak ice production before they strain components

Quick reference: symptoms vs. what to do

What you notice	What it usually means	What we do next
Compressor seems to run a lot	Warm room, frequent door openings, dirty condenser	Improve ventilation, clean condenser, reduce door-open time
Clicking, gurgling, fan sounds	Normal operating sounds on many newer designs	Compare to the sound descriptions in the manual
Slow water or small ice cubes	Filter restriction or water supply issue	Replace filter, check supply line and valve

Why it matters

A refrigerator that runs longer than necessary uses more energy and puts extra wear on sealed-system and airflow components. The manual for this model even notes that modern, high-efficiency designs can run longer under normal conditions, especially in warmer rooms.

Helpful DIY guidance

• Follow the steps in how to replace the water filter in a Kenmore refrigerator to keep water flow and ice production consistent.

Last updated: February 2026

On Kenmore Elite model 79571059011, the model and serial number are printed on an identification label inside the fresh food (refrigerator) compartment, on the right-hand side wall. Use that label when ordering parts or checking the correct owner's manual.

Common places to check on this refrigerator

We recommend looking in these spots in order:

• Right-hand side wall inside the refrigerator compartment (primary ID label location)
• Upper side wall near the front opening (sometimes easier to see with the door fully open)
• Behind or beside the crisper drawers (if the label is positioned lower)
• Door frame area near the hinge side (less common, but worth a quick check)

Quick tips to read the label

• Use a flashlight; labels are often low-contrast.
• Wipe condensation or food residue off the label with a dry cloth.
• Write down both the model number and serial number; both are useful for parts lookup.

Why it matters

The model number confirms the exact Kenmore Elite bottom-mount configuration (controls, ice maker, water filter setup). That prevents ordering the wrong part, especially for water system items like the genuine Kenmore refrigerator water filter 9690 AGF80300801 or the ice maker assembly.

Model vs. serial number (what each one does)

Label item	What it identifies	When you need it
Model number	The exact refrigerator design and parts list	Ordering parts, using diagrams, troubleshooting
Serial number	The specific unit and production run	Service history, warranty paperwork

Last updated: February 2026

On the Kenmore Elite 79571059011 bottom-mount refrigerator, the water filter is installed in the filter housing (manifold) inside the fresh food (refrigerator) section. You access it by opening the filter cover, then pulling the filter down and out to remove it; install the new one by pushing it in until it stops. See the owner's manual for the exact location and cover style on your unit.

How to find and remove the filter

• Open the refrigerator (top) compartment and look for a small filter cover or filter head assembly.
• Place a towel under the filter area to catch drips.
• Open the filter cover; it should click open.
• Pull the filter downward, then pull it straight out.
• Install the new filter with the tabs horizontal; push it into the manifold hole until it stops.
• Close the cover; it should click back into place.

After you replace it (flush and reset)

After installing a new filter, flush about 2.5 gallons of water through the dispenser (about 5 minutes) and check for leaks. Then reset the filter indicator by pressing and holding Ultra Ice (Filter Reset) for 3 seconds.

Task	What to do	Typical time
Flush the filter	Run water until 2.5 gallons passes through	~5 minutes
Reset indicator	Hold Ultra Ice (Filter Reset)	3 seconds

Filter vs bypass plug (when you do not have a replacement)

You must have either a filter or a bypass plug installed.

• Use a replacement filter for normal filtered water and ice.
• Use a bypass plug only when a replacement filter is not available.

If you need the correct replacement, match your filter to genuine Kenmore refrigerator water filter 9690 AGF80300801 (part number ADQ36006102) for this model.

Why it matters

A properly installed filter helps protect the water inlet valve and ice maker from sediment buildup, keeps water taste consistent, and prevents dispenser leaks caused by mis-seated O-rings or an unlocked filter.

Last updated: February 2026

Water leaking from the bottom of your Kenmore Elite 79571059011 refrigerator is usually caused by a clogged or frozen defrost drain that overflows into the base, or a leak in the water supply system for the dispenser and ice maker. Start by checking the drain path and then inspect the tubing and inlet valve.

Quick checks we recommend first

• Look for a sheet of ice or standing water on the freezer floor (common sign of a drain issue).
• Check for a puddle that appears after a defrost cycle (water should normally go to the drain pan).
• Inspect the water line connection and tubing for drips, kinks, or cracks.
• Pull the toe grille and look for water in the drain pan; some water there is normal.
• If the leak happens only when dispensing water or making ice, focus on the water system parts.

Most common causes (and what to do)

1) Clogged or frozen defrost drain

During defrost, water is supposed to flow through a drain to the drain pan where it can evaporate. If the drain clogs, water can back up and leak out the bottom.

What to do

• Unplug the refrigerator.
• Remove the freezer drawer/bins as needed and look for ice buildup near the drain area.
• Melt ice with warm air (hair dryer on low) and flush the drain with hot water using a turkey baster.
• If the drain tube is damaged or won’t clear, replace the refrigerator drain tube 5251JA3003D.

2) Leak in the dispenser/ice maker water supply

A small split in tubing or a seeping valve can drip down and collect under the cabinet.

What to check

• Tubing condition and connections: replace the refrigerator water tubing MJU62070602 if it’s brittle, kinked, or leaking.
• Valve seepage: replace the lg refrigerator water inlet valve AJU72992601 if it drips, won’t fully close, or leaks at fittings.

Helpful symptom guide

What you notice	Most likely area	Good next step
Water after defrost, ice on freezer floor	Defrost drain	Clear/flush drain; inspect drain tube
Leak only when using dispenser	Tubing, fittings, valve	Inspect tubing; check valve for seepage
Slow drip all day, even with no dispensing	Inlet valve or tubing	Check valve and tubing behind/under unit

Why it matters

Water under the refrigerator can damage flooring and can also lead to ice buildup in the freezer, airflow problems, and inconsistent temperatures.

For model-specific access steps and cleaning guidance, follow the owner's manual.

Last updated: February 2026

Common issues on the Kenmore Elite 79571059011 bottom-mount refrigerator include no cooling (often caused by Demo mode being on), ice maker not making enough ice (water supply or temperature related), dispenser water flow getting weak (clogged filter), and normal but “new” operating noises during defrost and fan operation. See the owner's manual for model-specific checks.

Most common symptoms and what to check first

• Refrigerator not cooling at all: confirm it is not in Store Demo mode (cooling disabled).
• Ice maker not producing ice or not enough ice: verify water supply is on, line is not kinked, freezer temp is cold enough, and doors close fully.
• Slow water dispensing: replace the water filter on schedule (typically every 6 months).
• Lights not working: check power, then bulb seating or a failed door switch.
• Vibration or rattling: level the refrigerator and confirm it sits solidly on the floor.

Quick troubleshooting table (symptom to likely cause)

Symptom	Most likely cause	What we recommend
No cooling but lights/display work	Demo mode enabled	Disable Demo mode using the button sequence in the manual
Ice maker slow or empty	Water supply off, kinked line, warm freezer, frequent door openings	Restore water flow, set colder freezer temp, reduce door openings
Water dispenser weak	Clogged filter	Replace genuine Kenmore refrigerator water filter 9690 AGF80300801
Interior lights out	Door switch or bulb issue	Reseat/replace bulb; test/replace refrigerator door switch 6600JB1010A
“Sizzling,” “popping,” fan noises	Normal defrost and airflow sounds	Confirm temps are stable; noises during defrost are normal

Why it matters

Catching the simple causes first (Demo mode, water supply, filter restriction, leveling) prevents unnecessary part replacement and helps protect key components like the compressor and control boards.

Parts that commonly solve these problems

• Genuine Kenmore refrigerator water filter 9690 AGF80300801 (low water flow, taste/odor issues)
• Refrigerator water filter bypass ABN73019101 (temporary testing without a filter installed)
• Lg refrigerator water inlet valve AJU72992601 (no water to dispenser or ice maker)
• Refrigerator ice maker assembly AEQ73110205 (ice maker not cycling or not harvesting)
• Refrigerator temperature sensor 6500JB2001B (temperature regulation problems)
