Kenmore 25364824400 refrigerator Parts

Your Kenmore refrigerator model number is printed on the serial plate inside the refrigerator compartment. On Kenmore model 25364824400, you will typically find this plate on an inside wall; once you locate it, write down both the model and serial numbers for parts lookup and service records.

Where to look for the model number tag

Check these common locations on a Kenmore top-mount refrigerator:

• Inside the fresh food (refrigerator) compartment on a side wall
• On the ceiling area inside the refrigerator compartment
• On the inside wall behind or near the lower crisper drawers
• Along the door frame area (fresh food door)
• Inside the freezer compartment on a side wall

For the exact location and what the label looks like for your unit, use the owner's manual.

What to write down (and why)

Record the information exactly as shown on the serial plate:

• Model number (example: 25364824400)
• Serial number (unique to your refrigerator)
• Any revision or production code listed

Why it matters

The model number narrows your appliance to the correct parts list (door gasket, evaporator fan blade, shelves, drawers) and the serial number helps match the correct version when designs change during a production run.

Quick checklist: model number vs. serial number

Item on the label	What it tells us	Used for
Model number	The exact refrigerator design family	Finding the correct parts diagrams and compatible replacement parts
Serial number	The specific unit and build sequence	Matching the correct variation and service history

After you find it: next best steps

• Use the model number to shop the correct Kenmore parts for your refrigerator
• If you are replacing broken storage components, match the part by name and ID (for example, crisper drawer - refrigerator storage component by frigidaire 240337103)
• Keep a photo of the serial plate on your phone for future reference

Last updated: February 2026

Your Kenmore refrigerator model 25364824400 has its exact cubic-foot capacity listed on the model and serial plate inside the fresh food compartment, and it is also shown in the specifications section of the owner's manual. Using the rating plate is the fastest, most accurate way to match capacity to your exact build.

Where to find the cubic-foot capacity on model 25364824400

Look for the serial plate inside the refrigerator compartment (the manual notes the model and serial information is located there). Once you find it, check for a line that lists capacity or cu. ft.

• Open the refrigerator door and look on the side wall near the crisper area
• Check the ceiling area near the light cover
• Look behind the crisper drawers or near the temperature control housing
• Write down the full model number and serial number for reference

If you are using the manual instead of the rating plate

The owner's manual typically lists capacity in the specifications section. This is helpful when the rating plate is hard to read or missing.

Quick comparison: rating plate vs. manual

Method	What you get	Best for
Rating plate inside the fridge	Exact capacity tied to your unit	Most accurate confirmation
Manual specifications	Capacity for the model series	Fast lookup and cross-check

Why it matters

Cubic-foot capacity helps us match the right storage components, shelves, and airflow expectations for a top-mount refrigerator. It also helps when comparing replacement items like a crisper drawer or door bin parts for your Kenmore 25364824400.

Related parts customers often replace

If you are checking capacity because you are reorganizing or replacing broken storage pieces, these model-matched parts are commonly used:

• Crisper drawer - refrigerator storage component by frigidaire 240337103
• Refrigerator crisper drawer cover insert 240350608
• Refrigerator spill-safe shelf 240358926

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 25364824400 are cooling issues (often airflow or defrost related), water leaks, ice maker or dispenser troubles, and unusual noises. Many fixes start with basic checks in the owner's manual and simple maintenance like cleaning and sealing.

Common problems and what usually causes them

• Not cooling or weak cooling: dirty condenser coils, blocked vents, evaporator fan problems, or a defrost system issue (ice buildup on the evaporator).
• Refrigerator runs but won’t start: loose power cord, tripped breaker, blown fuse, or the unit is in a normal defrost cycle (wait about 20 minutes and recheck).
• Water leaking or puddles: clogged defrost drain, door left ajar, or a door seal that is not closing tightly.
• Frost buildup in freezer: door not sealing, frequent door openings, or a defrost thermostat/heater problem.
• Noisy operation: normal operating sounds, fan blade rubbing ice, or vibration from the cabinet/rollers.

Quick checks we recommend first (fast, no parts)

• Confirm the temperature controls are set correctly; allow 24 hours for temperatures to stabilize after changes.
• Make sure the plug is fully seated and the circuit is good (breaker, outlet, fuse).
• Check that air vents inside are not blocked by food packages.
• Inspect door closing and alignment; clean the gasket sealing surface.
• Listen for a fan noise change when you open the door (helps narrow down evaporator fan vs. compressor noise).

Parts that commonly solve these symptoms

Symptom	Commonly involved part	Example part for this model
Frost buildup, warm fridge	Defrost thermostat	Refrigerator defrost bi-metal thermostat 5303918202
Warm temps, poor airflow	Evaporator fan blade (and fan motor in some cases)	Refrigerator evaporator fan blade 5308000010
Door not sealing, moisture/frost	Door gasket	Refrigerator gasket 242193213

Why it matters

Most “big” refrigerator complaints trace back to airflow, sealing, or defrost performance. Catching a weak door seal or early frost buildup helps protect food temperatures and reduces compressor run time.

Last updated: February 2026

Most Kenmore refrigerators average 10 to 15 years of service life with normal household use. For your Kenmore 25364824400 top-mount refrigerator, consistent maintenance (cleaning coils, keeping door gaskets sealing, and fixing cooling issues early) is what most directly determines whether it lands closer to 10 years or pushes beyond that.

Typical lifespan ranges (what we see most often)

Kenmore refrigerators vary by design and usage, but these ranges are reliable for planning repairs versus replacement:

• 10 to 15 years: typical for most household refrigerators
• 15+ years: common when condenser coils are kept clean and airflow is good
• Shorter lifespan: more likely with poor ventilation, dirty coils, or frequent warm-food loading

Quick reference table

What you do	What it protects	Why it helps lifespan
Clean condenser coils	Compressor and sealed system	Reduces run time and overheating risk
Keep doors sealing tightly	Cooling system workload	Prevents warm air and moisture intrusion
Maintain steady power	Compressor	Low voltage stresses the compressor
Fix fan or frost issues early	Evaporator airflow	Prevents chronic warm temps and overwork

Maintenance that adds years (high impact)

We recommend these practical steps for a top-mount refrigerator like model 25364824400:

• Vacuum condenser coils and the rear/bottom area every 6 to 12 months
• Confirm both doors close easily and stay closed (no “bounce back”)
• Keep vents inside the fresh food section and freezer unblocked
• Set stable temps (typical targets: 37°F fresh food, 0°F freezer)
• Replace worn sealing parts when you see gaps, tearing, or persistent condensation

If you are troubleshooting a poor seal, our guide how to fix a fridge door seal walks through cleaning, reshaping, and deciding when replacement makes sense.

Why it matters

A refrigerator’s most expensive wear items are the compressor and the sealed refrigeration system. The owner’s guide notes that insufficient power can damage the compressor, and that damage is not covered under warranty; keeping voltage stable and avoiding accidental shutoff helps protect the system long-term (see the owner's manual).

Last updated: February 2026
