Kenmore 25328052801 freezer Parts

On the Kenmore upright freezer model 25328052801, the model and serial number plate is typically located on the upper left wall inside the freezer cabinet. This label is the fastest way to confirm the exact model number before ordering parts or using troubleshooting steps in the 25328052801 owner's manual.

Most common label locations (upright freezers)

We recommend checking these spots in order:

• Upper left interior wall inside the freezer compartment (most common for upright models)
• Side wall inside the cabinet, near the front edge
• Ceiling area inside the freezer (some upright designs)
• Behind the kick plate or lower front grille area
• Back exterior panel (less common, but possible)

What the label looks like and what to copy

The plate usually lists both numbers; copy them exactly.

Item on label	What it’s used for	Example format
Model number	Matching parts and diagrams	253. or 970. prefix families
Serial number	Dating the unit, service identification	Letters and numbers

Why it matters

We use the model number to match the correct Kenmore parts for your exact freezer configuration (door style, control type, shelves, and defrost system). Even small model differences can change which parts fit.

Tips before you order parts

• Write the model and serial numbers down or take a clear photo
• If the label is frosted over, wipe it gently with a damp cloth and dry it
• Use the model number when selecting parts like a freezer door gasket 5304507199 or a crosley freezer door switch 297243800

Last updated: January 2026

To find the cubic feet of your Kenmore freezer model 25328052801, we calculate the usable interior space by measuring the inside height, width, and depth (in inches), then converting to cubic feet. This gives you the freezer’s storage capacity for organizing food and planning loads.

Measure the inside of the freezer

Use a tape measure and measure the interior (not the outside cabinet). For the most accurate number, measure to the nearest 1/8 inch.

• Height: floor of the freezer to the underside of the top interior surface
• Width: left interior wall to right interior wall
• Depth: back interior wall to the inside front edge (do not include the door thickness)
• Remove bulky bins if they block a straight measurement
• Measure the main cavity; door bins are usually not counted in “cubic feet”

For model-specific features and interior layout notes, use the 25328052801 owner’s manual.

Calculate cubic feet (simple formula)

1. Multiply: height x width x depth (in inches) to get cubic inches.
2. Divide by 1,728 (because 12 x 12 x 12 = 1,728) to convert to cubic feet.

Quick reference table

What you have	What to do	Result
Interior measurements in inches	Multiply H x W x D	Cubic inches
Cubic inches	Divide by 1,728	Cubic feet

Why it matters

Cubic feet helps you plan storage and freezing loads. The manual guidance for freezers like this is to freeze about 3 pounds of fresh food per cubic foot at one time, and allow about 4 hours for the freezer to cool down for safe food storage.

Tips to keep your measurement useful

• Measure the main compartment only for a standard capacity estimate
• If shelves reduce usable space, note both “gross” (empty cavity) and “usable” (with shelves)
• Keep the freezer level so the door seals properly; poor sealing can reduce effective storage due to frost buildup

Last updated: January 2026

To manually defrost your Kenmore upright freezer model 25328052801, we recommend unplugging the freezer, removing food, and letting the ice melt with the door open. Defrost when frost buildup reaches about 1/4 to 1/2 inch; this restores airflow and cooling efficiency (see the 25328052801 owner's manual).

Step-by-step: manual defrost (upright models with a defrost drain)

1. Move food to a cooler with ice packs.
2. Turn the temperature control to OFF, then unplug the freezer (OFF does not remove power to all components).
3. Open the door.
4. Pull out the internal drain plug on the freezer floor.
5. If your model has a base panel, remove it (typically held by screws) to access the external drain tube.
6. Place a shallow pan under the drain tube; check it often so it does not overflow.
7. When ice is gone, clean and dry the interior.
8. Reinstall the drain plug and any panels; plug the freezer back in and allow time to return to temperature.

Tips to speed up defrosting safely

• Use a shallow pan under the drain tube to catch water.
• Use a plastic scraper to remove loose frost (pulling motion).
• Place towels around the base to protect flooring.
• Keep the door open to let warm air in and melt frost faster.
• Never use a metal tool to chip ice; it can puncture the evaporator.

What not to do

• Do not use boiling water directly on freezer surfaces.
• Do not use a knife, screwdriver, or other metal instrument to remove frost.
• Do not pull the power cord to unplug; grip the plug.

Quick reference

Task	Best practice	Why it matters
Power off	Unplug the freezer	Prevents electrical hazard while defrosting
When to defrost	1/4 to 1/2 inch frost	Maintains airflow and efficient cooling
Frost removal	Plastic scraper only	Protects the liner and sealed system

Why it matters

Heavy frost acts like insulation and can restrict airflow, which makes the compressor and evaporator system work harder. Regular manual defrosting helps your Kenmore 25328052801 hold temperature more consistently and reduces energy waste.

Last updated: January 2026

On the Kenmore 25328052801 upright freezer, there is not a general “reset” button for the whole freezer; instead, the control panel uses an ALARM RESET button to silence the Hi Temp alarm and buzzer after temperatures rise above about 23°F. See the 25328052801 owner's manual for the exact control layout.

What the “reset” button usually means on this model

On this freezer, “reset” commonly refers to resetting the alarm, not rebooting the electronic control.

• ALARM RESET: silences the buzzer when the Hi TEMP light is on
• Hi TEMP light: turns on when the freezer temperature rises above about 23°F
• If an “E” appears on the display: it indicates a fault condition that needs service attention
• Power interruptions can trigger alarms; the Hi Temp feature will not function without household power

Quick checks we recommend before calling for service

These steps address the most common reasons the alarm keeps coming back.

• Confirm the temperature control is set correctly (typical target is 0°F for food storage)
• Make sure the door is fully closing and the gasket is sealing all the way around
• Avoid overpacking; blocked airflow can cause warm spots and longer run times
• After a power outage, give the freezer time to pull back down to temperature before judging performance
• If the alarm won’t silence or returns every hour, check for an error code and follow the manual guidance

Alarm behavior at a glance

What you see/hear	What it usually means	What to do
Hi TEMP light on + buzzer	Freezer is above about 23°F	Press ALARM RESET; verify door seal and settings
Buzzer returns about every hour	Temperature is still above threshold	Check airflow, loading, and cooling performance
“E” on display	Control detected a malfunction	Arrange service per the manual

Why it matters

A recurring Hi Temp alarm is an early warning that food may be warming into an unsafe range. Silencing the buzzer is helpful, but the priority is restoring normal cooling by correcting airflow, door sealing, or a cooling-system issue.

Last updated: January 2026
