Kenmore 79090313010 electric range Parts

To reset your Kenmore electric range model 79090313010, we recommend doing a full power reset: turn the range off, cut power at the breaker for 1 to 5 minutes, then restore power and re-set the clock. This clears many control glitches and false error displays.

• Turn all surface element knobs to OFF.
• If the oven is running, press Cancel/Off on the control.
• Switch the range circuit OFF at the home breaker (preferred) or unplug the cord if accessible.
• Wait 1 to 5 minutes.
• Restore power.
• Set the clock and test Bake and Broil.

A reset clears temporary faults, but a repeating code usually points to a failed component (sensor, control, wiring) or an overheat condition.

Use this guide to match the code to the next step: Kenmore 790 self-cleaning range error codes.

• Loose or burned wiring connection at the back terminal area
• Failed oven temperature sensor
• Stuck relay or failed electronic control
• Door lock system problem after a self-clean cycle

If the oven still will not heat correctly after a reset, these model-compatible parts are common suspects:

Resetting restores the control to a known good state, which helps you separate a one-time electronic glitch from a real failure (like a bad sensor, bake element, or door lock). It also prevents repeated overheating or nuisance shutdowns.

For model-specific control features and operating steps, use the 79090313010 owner's manual.

Last updated: January 2026

For the Kenmore 79090313010 electric range, the installation instructions focus on required clearances (not the oven cavity capacity). Most 30-inch freestanding electric ranges like this are built to fit a standard 30-inch opening; confirm the exact cutout and clearance dimensions in the 79090313010 installation guide.

When customers ask for “oven size,” it typically refers to one of these:

• Overall range dimensions (width, height, depth)
• Cabinet opening and clearance requirements (what your kitchen must accommodate)
• Oven capacity (cubic feet)
• Interior oven dimensions (rack width/depth)

The Kenmore 79090313010 installation instructions call out key clearance rules that affect fit and safety:

• Plan for a 30-inch class freestanding range installation
• Maintain 30 inches minimum from cooktop to an unprotected cabinet bottom (or 24 inches if properly protected)
• Allow 0 inches minimum clearance at the rear (per the guide’s stated minimum)
• Install the anti-tip bracket any time the range is installed or moved

Using the correct opening and clearance dimensions prevents heat damage to cabinets, reduces fire risk, and helps the range sit level so the bake element and temperature sensor can regulate heat more consistently.

Last updated: January 2026

On Kenmore electric range model 79090313010, the model and serial plate is typically on the lower right front frame of the range; on some units it may be under the cooktop. Use the plate information when ordering parts or checking installation requirements in the 79090313010 installation guide.

• Open the oven door and look along the lower right front frame
• Look under the cooktop (alternate location on some units)
• Check near the storage or warmer drawer opening area for a rating plate
• If the range has been moved, check the rear area for any secondary labels

Record these exactly as shown on the plate:

• Model number (for this page: 79090313010)
• Serial number
• Electrical rating (volts/amps)
• Brand (Kenmore)

The model and serial plate is the fastest way to match the correct Kenmore electric range parts and confirm installation details like grounding and power cord requirements.

• Wipe gently with a damp cloth and mild dish soap; dry fully
• Use a flashlight at an angle to make faint printing easier to see
• Take a close-up photo and zoom in to capture the full number string

Last updated: January 2026
