Kenmore Elite 11023012101 washer Parts

Most Kenmore washers last 10 to 15 years with normal household use and basic maintenance. For your Kenmore Elite washer 11023012101, regular cleaning, correct loading, and fixing small issues early are the biggest factors that help you reach the high end of that range; see the 11023012101 owner's manual for care and troubleshooting steps.

What affects washer lifespan most

• Load size and balance: frequent overloading or unbalanced loads increase wear on the drive system and suspension.
• Water quality: hard water and sediment can shorten the life of the inlet valve and internal seals.
• Drain performance: slow draining strains the pump and can leave residue that causes odors.
• Routine care: periodic cleaning and hose checks reduce leaks and corrosion.
• Early repairs: replacing small wear parts prevents bigger failures later.

Common “wear items” that can shorten life (and what they do)

Part	What you may notice when it wears	Example part for this model
Agitator dogs	Agitator slips, weak agitation, clothes not moving well	Agitator dog 80040
Motor coupling	Washer won’t agitate or spin, loud rattling, motor runs but tub does not move	Washer motor coupling 285753A
Drain pump	Won’t drain, drains slowly, humming during drain	Washer drain pump WP3363394

Signs it may be time to repair vs replace

• Repair is usually worth it when the washer is otherwise solid and the issue is a common part failure (coupling, pump, lid switch).
• Replacement becomes more likely when you have repeated leaks, persistent loud gearcase noise, or multiple major repairs close together.

Why it matters

A washer that is maintained and repaired promptly typically runs longer, cleans better, and is less likely to develop leaks that can damage flooring.

Last updated: January 2026

The Kenmore Elite washer model 11023012101 is typically about 3.2 cu. ft. in capacity. This is the common tub size for many Kenmore 110-series top-load washers; for the exact rated capacity for your specific unit, confirm it in the 11023012101 owner's manual.

How to confirm the capacity on your exact washer

We recommend checking the model-specific literature first because capacity can vary slightly by revision and basket style.

• Look for “capacity” or “cu. ft.” in the specifications section of the 11023012101 owner's manual
• Check the model tag to confirm you are using the exact model number 11023012101 (not a close 110-series variant)
• If your washer has a different basket or tub installed, capacity can effectively change for real-world loads
• Compare your basket size and fill level to typical 3.2 cu. ft. top-load performance

What 3.2 cu. ft. means in everyday use

A 3.2 cu. ft. top-load washer is generally sized for everyday family loads and works best when you avoid packing clothes tightly.

Load type	Typical fit in a 3.2 cu. ft. top-load washer	Practical tip
Mixed everyday load	Medium to large	Load loosely for better agitation
Towels	Medium	Balance the load to reduce vibration
Bulky items (comforter)	Often 1 item	Use bulky/bedding cycle if available

Why it matters

Knowing the cubic-foot capacity helps us choose the right cycle and water level, prevent overloading (which can strain the drive system), and reduce issues like poor cleaning, out-of-balance spinning, and premature wear on parts such as the clutch and gear case.

Last updated: January 2026

To force your Kenmore Elite washer model 11023012101 to drain, use the built-in Drain and Spin procedure: set rinse to One Rinse, choose a spin speed, turn the timer to a Spin setting, then pull the knob out so the washer drains and spins. See the 11023012101 owner's manual for the exact control positions.

Fastest way to drain (Drain and Spin)

Use this when the tub is full of water and you want the washer to pump out and spin.

• Set Rinse Options to One Rinse.
• Set Speeds:
  • Heavy Duty for fast spin.
  • Delicate for slow spin.
• Push in the Cycle Selector (Timer) knob and turn it clockwise to any Spin setting.
• Pull the knob out; the washer drains, then spins.

If it still will not drain

A no-drain problem is usually a restriction (hose or pump) or a failed drain component.

• Check the drain hose for kinks; keep the hooked end positioned to prevent kinks.
• Make sure the drain hose is not shoved too far into the standpipe; it needs an air gap.
• Look for a clog at the pump inlet or in the hose path.
• If you hear the motor running but water does not move, the pump can be jammed or worn.
• If the washer will not run the drain portion at all, a lid safety issue is common on top-load designs.

Common parts involved

Symptom	Most likely area	Example part for this model
Hums but will not pump	Drain pump jammed or failed	Washer drain pump WP3363394
Stops mid-cycle, no drain/spin	Lid safety circuit	Washer lid switch WP8054980
Drains slowly	Hose restriction	Inspect drain hose routing per the manual

Why it matters

Standing water can cause odor, poor rinsing, and repeated out-of-balance spins. Getting the washer to complete a Drain and Spin also helps confirm whether the issue is a simple clog or a part such as the drain pump or lid switch.

Last updated: January 2026

To hard reset your Kenmore Elite washer model 11023012101, unplug the washer (or switch off the breaker) for 3 to 5 minutes, then restore power and run a short cycle to confirm the controls, fill, drain, and spin respond normally. Use the 11023012101 owner's manual for the correct start/stop steps.

Hard reset steps (11023012101)

• Turn the washer OFF by pushing in the cycle selector (timer) knob.
• Unplug the power cord (or turn the circuit breaker off).
• Wait 3 to 5 minutes to clear the control state.
• Restore power.
• Close the lid and pull out the cycle selector (timer) knob to start a cycle.

What a reset can help with

A hard reset often clears temporary control glitches that can look like a “stuck” cycle or non-response.

• Timer knob not starting the cycle
• Washer pauses and will not restart after a stop
• Odd behavior during the shift from wash to drain/spin
• Intermittent no-agitate or no-spin symptoms (after power flickers)

Quick checks if it still will not run

If the washer still will not start or complete a cycle after the reset, these are the most common next checks for this style of Kenmore top-load washer.

• Confirm the lid closes firmly; a failed lid switch can prevent spin (see washer lid switch WP8054980).
• Verify both water faucets are fully open and inlet hoses are not kinked.
• Listen for draining; a weak or jammed pump can stall the cycle (see washer drain pump WP3363394).
• If the basket will not spin but the motor runs, inspect the drive connection (see washer motor coupling 285753A).

Reset vs. restart: what is the difference?

Action	What you do	What it fixes
Restart	Push in timer knob to stop, then pull out to start	Simple pause or lid opened
Hard reset	Remove power 3 to 5 minutes	Control glitch after interruption

Why it matters

A proper reset helps you avoid unnecessary part replacement by confirming whether the issue is a temporary control state or a true failure in the lid switch, drain pump, or drive system.

Last updated: January 2026
