Kenmore 79097453800 electric range Parts

For Kenmore electric range model 79097453800, the model number is printed on the appliance identification (serial) plate. On this model, that plate is located on the right side of the oven front frame, inside the storage or warmer drawer compartment; pull the drawer out to see it. See the 79097453800 owner's manual for the exact serial plate location diagram.

Where to look on model 79097453800

Check these spots in this order:

• Pull out the storage or warmer drawer and look on the right side of the oven front frame
• Look for a label that lists Model and Serial
• Write down the full model number (all digits) and the serial number
• Take a clear photo of the label for ordering parts later

Quick steps to access the serial plate

1. Make sure the oven is off and cool.
2. Pull the storage or warmer drawer straight out.
3. Use a flashlight and look along the right front frame.
4. Record the model and serial numbers exactly as shown.

What the label typically includes

Label item	What it’s used for
Model number (example: 79097453800)	Matching the correct parts diagrams and parts
Serial number	Identifying production series and compatible revisions
Electrical ratings	Verifying power requirements during installation/service

Why it matters

We use the exact model number to match the correct Kenmore parts list, wiring layout, and component versions (such as the oven control board, bake element, or temperature sensor). One missing digit can pull up the wrong range family.

Last updated: January 2026

The Kenmore electric range model 79097453800 is a standard freestanding 30-inch class range. Most ranges in this series fit a 30-inch wide opening and stand about 36 inches tall to the cooktop (height can vary slightly with leveling legs). For exact cabinet cutout and overall dimensions, use the 79097453800 owner's manual and the 79097453800 installation guide.

Typical size you can plan around

These are the most common planning dimensions for a freestanding electric range like the Kenmore 79097453800:

• Width: about 29 7/8 inches to 30 inches
• Cooktop height: about 36 inches (adjustable with leveling legs)
• Overall height to backguard/control panel: often around 46 inches to 48 inches
• Depth: often around 25 inches to 28 inches (varies with handle and rear clearance)

Quick planning table (typical)

Measurement	Typical value	What can change it
Opening width	30 inches	Cabinet tolerances
Cooktop height	~36 inches	Leveling legs, flooring
Overall height	~46 to 48 inches	Control panel/backguard design
Depth	~25 to 28 inches	Door/handle, rear clearance

Why the exact dimensions matter

Correct dimensions help prevent installation problems like a range that will not slide in fully, a door that hits adjacent cabinets, or an anti-tip bracket that does not line up correctly.

What we recommend before you measure the space

• Measure the cabinet opening width at the front and back
• Measure height to the countertop on both sides (floors can slope)
• Check for rear clearance for the power cord and outlet
• Confirm the anti-tip bracket location requirements
• Compare your measurements to the dimension diagram in the installation instructions

Last updated: January 2026

To reset a Kenmore electric range model 79097453800, turn the range OFF and restore power by cycling the circuit breaker (or unplugging, if accessible) for about 1 minute, then power it back on and reset the clock and oven function as needed. See the 79097453800 owner's manual for control-specific steps.

Quick reset steps (most common)

• Turn all surface element knobs to OFF.
• If the oven is running, press CANCEL/OFF (if your control has it).
• Switch the range circuit breaker OFF for about 60 seconds.
• Switch the breaker ON.
• Set the clock, then test BAKE at 350°F for 10 to 15 minutes.

If the control panel is locked (looks like it will not respond)

Your model has an Oven Lockout feature that can make it seem like the oven needs a reset.

• Press and hold the Oven Lockout pad for 3 seconds.
• Wait for the door to fully unlock and the display to clear.
• Try setting BAKE again.

What you see	What it usually means	What to do
Controls do not respond, “LOC” or “DOOR LOCKED”	Oven lockout is active	Hold lockout pad 3 seconds
Display is blank after outage	Power interruption	Cycle breaker, then set clock
Oven heats poorly after “reset”	Heating or sensing issue	Troubleshoot bake/broil/sensor

Why it matters

A true power reset clears minor control glitches after a power interruption, but it will not fix a failed heating circuit. If the oven still will not heat after resetting, common causes include a failed bake element, temperature sensor, or control board. For temperature-sensing problems, the frigidaire range oven temperature sensor 316490000 is a common related part for this model.

Last updated: January 2026

Kenmore model 79097453800 is part of the Kenmore 790 model series; that prefix is widely used for ranges built for Kenmore by Frigidaire/Electrolux. You can confirm the model and serial tag location on your range using the 79097453800 owner's manual.

How to confirm on the appliance

We recommend verifying the full model number and serial number directly from the identification plate before ordering parts or scheduling service.

• Pull out the storage or warmer drawer.
• Look on the right side of the oven front frame inside that drawer compartment.
• Match the full model number exactly: 79097453800.
• Record the serial number and purchase date for your records.
• Use the full model number when selecting parts like a bake element, oven control board, or temperature sensor.

What the model prefix means

Kenmore uses model prefixes to indicate the original manufacturer behind the Kenmore-branded appliance.

What you see	What it typically indicates	Why it matters
Model starts with 790	Built for Kenmore by Frigidaire/Electrolux	Helps match correct wiring, controls, and heating parts
Full model number (example: 79097453800)	Exact configuration for your range	Ensures correct fit for elements, switches, and sensors

Why it matters

Knowing who built your Kenmore electric range helps when you are troubleshooting symptoms (no heat, temperature issues, burner problems) and when you are choosing compatible replacement parts and installation procedures.

Related help

• For fault displays and troubleshooting steps, use Kenmore 790 self-cleaning range error codes.

Last updated: January 2026
