Kenmore Elite 63013003017 dishwasher Parts

Yes. We still offer replacement parts for Kenmore dishwashers, and for Kenmore Elite model 63013003017 you can match parts by model number and symptom, then replace common wear items like pumps, switches, and sensors to restore normal washing and draining.

How to make sure you get the right part

Use your full model number (63013003017) and then confirm the part by location in the diagrams and by the failure symptom.

• Match the part to the exact model number on the rating label
• Compare the part name and ID (not just a description)
• Check whether the issue is drain, fill, door, or power related
• Replace any damaged seals or fasteners you remove during service
• Follow the wiring and mounting steps in the installation guide

Common Kenmore Elite 63013003017 parts customers replace

These are frequently ordered parts for this model when the dishwasher will not drain, will not start, or shows inconsistent cleaning results.

Symptom	Likely part to check	Example part for this model
Won’t drain or drains slowly	Drain pump area, drain path	Drain pump 00611332
Intermittent wash performance	Soil sensing/turbidity feedback	Sensor 00611323
Won’t power on or won’t respond	Power switch and supply wiring	Dishwasher on/off switch 00611295
Door won’t start cycle when closed	Door latch/switch circuit	Sensor 00611312

Why it matters

Dishwashers are model-specific. Even when a part looks similar across Kenmore models, the electrical connectors, mounting points, and calibration can differ; matching by 63013003017 helps prevent returns and repeat repairs.

Quick install-related tip that affects draining

If you are installing or reinstalling the dishwasher, the drain hose routing matters. The install instructions for this platform specify keeping a portion of the drain hose at least 20 inches (508 mm) above the cabinet floor to help prevent poor draining.

Last updated: February 2026

Yes, repairing a Kenmore Elite dishwasher like model 63013003017 is usually worth it when the unit is under about 10 years old and the fix is a common wear item (switches, sensors, drain components) rather than a major rebuild. Use the installation guide to confirm safe access and correct reinstallation.

A simple way we judge “repair vs. replace”

We use three practical checks that apply well to most dishwashers:

• Age: Under 10 years typically favors repair; over 10 years depends on condition and repair cost.
• Repair cost vs. replacement cost: If the repair is under about 50% of replacement cost, repair usually makes sense.
• Type of failure: Drain, fill, and door-switch problems are often cost-effective; repeated leaks or multiple major failures point toward replacement.

Common repairs that are often worth it on model 63013003017

These are frequent, targeted fixes that can restore normal washing and draining without replacing the dishwasher:

• No-drain or slow-drain issues: check/replace the drain pump 00611332 and inspect the drain path
• Intermittent wash results: a soil/turbidity issue can involve the sensor 00611323
• Won’t start or stops when the door moves: door safety circuit can involve the sensor 00611312
• Random shutoff or no power at the control: inspect the power connection and consider the dishwasher on/off switch 00611295

Quick cost-benefit table

Situation	Usually worth repairing?	Why
Dishwasher drains poorly but otherwise runs	Yes	Often a single-part fix (pump, blockage)
Unit won’t start but has power	Yes	Commonly a switch/door circuit issue
Multiple leaks, corrosion, or repeated failures	No	Repair stack-up gets expensive
Major repair plus high age (10+ years)	No	Better long-term value replacing

Why it matters

A dishwasher repair is most cost-effective when it restores core functions (fill, wash, drain, heat) with one or two parts. Once you start stacking multiple high-cost repairs, you pay more and still keep an older machine with more wear.

Safety and installation notes we follow

The installation instructions for this dishwasher include key requirements that affect performance and safety:

• Do not operate the dishwasher until it is fully installed and secured
• Install the drain hose with a high loop at least 20 inches above the cabinet floor to help prevent draining problems
• Use proper electrical supply cable sizing (the guide specifies minimum #14 AWG, 2 conductor plus ground)

Last updated: February 2026

Common problems we see with Kenmore dishwashers (including Kenmore Elite model 63013003017) are no-start conditions, poor draining, leaks, and weak cleaning. These issues usually trace back to door safety switches, drain components, water fill parts, or installation factors like an incorrect drain-hose high loop; see the installation guide for key setup requirements.

Most common symptoms and what they usually mean

• Dishwasher will not start: door not fully latched, a failed door switch, or a power supply issue
• Water left in the tub: drain path restriction, drain pump problem, or drain hose installed too low
• Leaking: unit not level, loose connections, or overfill protection issue
• Poor cleaning: spray obstruction, loading issues, or sensor-related wash performance problems
• Stops mid-cycle: intermittent power, door switch opening, or a safety float/overfill event

Quick checks you can do first (before replacing parts)

• Confirm the door closes firmly and the latch engages consistently.
• Reset power at the breaker for 1 minute, then try a normal cycle.
• Check the sink drain and disposer inlet for clogs that can block dishwasher draining.
• Verify the drain hose has a high loop at least 20 inches above the cabinet floor (a common cause of drain-back and poor draining).
• Make sure the dishwasher is level and plumb; an unlevel unit can affect operation and contribute to leaks.

Parts that commonly solve these problems on this model

If your symptom matches, these are frequently involved components for model 63013003017:

Symptom	Common part involved	Example part on this page
Won’t drain / standing water	Drain pump or drain path	Drain pump 00611332
Overfills or acts like it’s leaking from below	Overfill protection	Dishwasher float switch assembly 00622039
Won’t start when door is closed	Door safety circuit	Dishwasher door switch 00611312
Wash results inconsistent	Water clarity sensing	Sensor 00611323

Why it matters

Dishwashers rely on safety interlocks (like the door switch) and correct installation (leveling and drain-hose routing) to run safely and drain correctly. Fixing the root cause prevents repeat clogs, drain-back, and nuisance leaks.

Last updated: February 2026

Your Kenmore Elite dishwasher model number is printed on the rating label located just inside the dishwasher door opening (typically along the left-hand side). For model 63013003017, that label shows both the model number and the serial number.

Where to look (fast checklist)

• Open the dishwasher door fully.
• Look along the inner door frame and tub lip area.
• Check the left-hand side first (most common location).
• Wipe the label gently if it is cloudy or greasy.
• Write down the full model number and serial number exactly as shown.

What the model number helps us match

When you give us the exact model number, we can match the correct Kenmore Elite dishwasher parts and diagrams for your unit, including common repair items such as the drain pump 00611332 or the dishwasher on/off switch 00611295.

You find on the label	What it’s used for
Model number (example: 63013003017)	Ensures the right parts fit your exact dishwasher
Serial number	Helps identify production details when parts vary by revision

Why it matters

Kenmore dishwashers often have similar-looking doors and controls across multiple series. Using the exact rating-label model number prevents ordering the wrong drain pump, door switch, wire harness, or toe panel parts.

Related installation note (helpful when checking the door area)

If you are also installing or re-installing the dishwasher, follow the safety and placement guidance in the installation guide. It covers basics like shutting off water and power before service and ensuring proper clearances.

Last updated: February 2026
