Kenmore 79075747991 gas range Parts

On Kenmore gas range model 79075747991, the model and serial number are printed on an identification plate. You will typically find that plate either inside the storage compartment on the right side of the oven front frame (sealed-burner models) or under the lift-up cooktop (other gas models). See the 79075747991 owner's manual for the exact location details.

Common places to check

• Storage compartment: Pull out the storage drawer and look on the right side of the oven front frame.
• Under the cooktop: If your range has a lift-up cooktop, look under the cooktop for the identification plate.
• Warmer drawer area (if equipped): Remove the warmer drawer to access areas behind it (use the safe removal steps in the manual).
• Behind the lower drawer: With some configurations, the label is easiest to spot once the drawer is fully removed.

Quick drawer-removal tip (warmer drawer models)

We follow the same basic approach described in the installation instructions:

• Disconnect electrical power before servicing.
• Open the drawer fully.
• Use the glide levers (left and right) to release the drawer.
• Pull the drawer straight out to expose the frame area.

What you are looking for

The identification plate usually includes these fields:

Label item	What it helps with
Model number	Matching the correct Kenmore parts list and diagrams
Serial number	Identifying production details for service and documentation
Date of purchase (your record)	Tracking maintenance and warranty paperwork

Why it matters

Using the exact model number (like 79075747991) prevents ordering the wrong igniter, regulator, oven rack, or other range parts; Kenmore ranges often have similar-looking versions with different components.

Last updated: February 2026

A Kenmore gas range like model 79075747991 typically lasts 15 years with normal household use. Regular cleaning, correct flame/temperature performance, and prompt repair of ignition or heating issues help you reach that lifespan; see the 79075747991 owner's manual for care and cleaning details.

Typical lifespan and what affects it

Most gas ranges reach their full service life when these basics are consistent:

• Burners ignite quickly and flames stay steady (no repeated clicking or delayed ignition)
• Oven heats evenly and holds temperature (no long preheat times)
• Door seals well so heat stays in the oven cavity
• Spills and grease are cleaned before they bake on and damage finishes
• Controls and wiring stay dry during cleaning

Maintenance that extends range life

The manual’s cleaning guidance is the biggest longevity driver. We recommend:

• Turn all controls OFF and let the range cool before cleaning.
• Wipe up spillovers and heavy soiling as soon as possible.
• Use hot, soapy water for general cleaning; avoid abrasive cleaners that scratch.
• Keep excess water away from the control area (water around controls can cause damage).
• Clean grates and removable pieces regularly; dry thoroughly after washing.

Parts that commonly shorten lifespan when they fail

When these parts start acting up, fixing them early prevents bigger problems:

Symptom	Common cause	Example part on this model page
Oven won’t heat or heats inconsistently	Weak/hot igniter	Frigidaire range oven burner igniter 5303935066
Oven light out	Burned-out bulb or bad socket	Range oven light bulb 316538904
Oven won’t maintain heat, poor bake performance	Gas delivery issue (diagnosis required)	Range oven gas valve 5303208499
Heat escaping, longer cook times	Worn door gasket	Range oven door seal 5303131601

Why it matters

A 15-year gas range lifespan assumes safe, efficient combustion and stable oven temperature. Small issues like a slow igniter or a leaking door seal can increase cook times, strain components, and make the range feel “worn out” years early.

You can order replacement parts for Kenmore 79075747991 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

On the Kenmore 79075747991 gas range, you change a spark electrode igniter by shutting off power and gas, lifting the burner parts to access the electrode, moving the wire to the new electrode, then reinstalling the electrode so it sits correctly by the burner head and is not pinched or bent. See the 79075747991 installation guide for burner component orientation and cautions.

Safety first

• Turn off electrical power to the range at the breaker.
• Close the gas shut-off valve.
• Let all burners cool completely.
• Work in a well-ventilated area.
• Do not force the ceramic electrode; it cracks easily.

Steps to replace a surface burner spark electrode

1. Remove the burner grate and burner cap.
2. Lift off the burner head (or loosen the burner head screws if your burner uses them).
3. Note how the electrode sits next to the burner head and where the wire routes.
4. Disconnect the electrode wire connector from the old electrode.
5. Remove the mounting screw holding the electrode to the burner base/orifice holder.
6. Install the new electrode in the same position; secure it with the screw.
7. Reconnect the wire connector; make sure it is fully seated and the wire is not touching hot metal.
8. Reinstall the burner head, cap, and grate.
9. Restore gas and power; test ignition on that burner.

Quick checks if it still will not spark

• No clicking at any burner: suspect the spark module, such as the range igniter spark module 5304505695.
• Clicks but no spark at one burner: recheck the electrode gap and wire connection at that burner.
• Spark is weak or intermittent: clean and dry the burner head and cap; moisture and grease block spark.

What to inspect while you are in there

Item to inspect	What you are looking for	What to do
Electrode tip	Cracks, chips, heavy carbon	Replace electrode; clean light residue only
Wire/connector	Loose fit, burn marks	Reseat connector; repair damaged wiring
Burner cap seating	Cap not centered	Re-seat cap carefully so the electrode is not damaged
Burner ports	Clogged holes	Clean ports with a soft brush

Why it matters

A correctly positioned electrode and properly seated burner cap help the burner light quickly and prevent constant clicking, delayed ignition, and uneven flame.

For replacement parts for your Kenmore 79075747991, use the parts list for this model or search by model number on Sears PartsDirect.

Last updated: February 2026

For the Kenmore 79075747991 gas range, the most reliable “reset” is a power reset: turn the oven off, cut power to the range for a few minutes, then restore power and reset the clock and any oven functions per the 79075747991 owner's manual.

Quick reset steps (power reset)

• Turn the oven controls to OFF.
• If the oven was running, let it cool down.
• Turn off power at the breaker (or unplug the range if accessible).
• Wait 3 to 5 minutes.
• Restore power.
• Reset the clock and reselect your cooking mode (Bake, Broil, Timed Bake).

If the reset is after a power outage

Our manual guidance is clear: do not operate the oven during a power failure. When power returns, the oven can resume operation if it was not turned off first. After power is restored:

• Confirm all knobs and oven controls are OFF.
• Reset the clock.
• Re-enter any timed settings (Bake Time, Stop Time) if you use them.

If the oven is “stuck” in self-clean

Use the control-panel stop procedure:

• Press CLEAR to stop or interrupt self-clean.
• Wait about 1 hour for the oven to cool and for the door lock indicator to go out.
• Open the door only after it unlocks; do not force it.

What “reset” fixes (and what it does not)

Symptom	Reset helps?	What to check next
Display frozen or unresponsive	Yes	Power reset; then set clock
Timed Bake acting odd	Yes	Reprogram Bake Time/Stop Time
Door locked after self-clean	Sometimes	Use CLEAR; wait for cool-down
Oven will not heat	No	Troubleshoot ignition and gas supply

Why it matters

A reset clears minor control glitches and restores normal timing functions, but it does not correct heating failures caused by ignition or gas-delivery problems. If the oven will not ignite after resetting, a common repair is replacing the oven igniter, such as the frigidaire range oven burner igniter 5303935066.

You can order replacement parts for your Kenmore 79075747991 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026
