Kenmore 79579432211 refrigerator

Kenmore 79579432211 refrigerator Parts

Here are the diagrams and repair parts for Kenmore 79579432211 refrigerator, as well as links to manuals and error code tables, if available.

By Schematic
By Part
SELECT DIAGRAM
?

This is the number corresponding to the part on the diagram / schematic

Browse Parts for 79579432211 Refrigerators

Kenmore Refrigerator 79579432211 FAQs

On the Kenmore 79579432211 top-mount refrigerator, the top compartment is the freezer. It’s designed to keep foods frozen, support ice storage or an ice maker (if equipped), and send cold air down to help cool the fresh food section.

What the freezer does in a top-mount refrigerator

In this style of refrigerator, the freezer is more than just storage; it’s part of the cooling system.

  • Freezes and stores food at a safe, sub-zero temperature
  • Helps drive airflow that cools the refrigerator section below
  • Provides space for ice trays or an automatic ice maker (if installed)
  • Works with the temperature controls to balance both compartments

Airflow basics (why the top compartment matters)

Your freezer is the starting point for cold-air circulation. Air typically enters at the top of the freezer, circulates, then moves into the refrigerator section through vents. Keeping vents clear helps prevent warm spots and uneven temperatures.

If you notice… Common cause in a top-mount design What to do first
Fridge is warm but freezer is cold Blocked air vents or airflow restriction Rearrange items to clear vents
Temps swing after adjusting controls Normal stabilization time Wait 24 hours before adjusting again
Frost buildup in freezer Door not sealing or frequent openings Check gasket contact and door closing

Quick tips to keep the freezer working correctly

  • Avoid packing food tightly against air vents
  • Let temperature changes stabilize for a full day before adjusting again
  • Keep the door closing fully; a weak seal can cause frost and poor cooling
  • If the interior light stays on when the door is shut, test the door switch

If you suspect the light is not turning off, the door switch is a common wear item on this model; see lg refrigerator door switch 6600JB1010A.

Why it matters

Because the freezer supplies cold air to the refrigerator section, problems that start “up top” (blocked vents, poor door seal, or a door switch issue) often show up as fresh food warming, frost, or temperature imbalance.

For control settings and airflow guidance specific to the Kenmore 79579432211, use the 79579432211 owner's manual.

Last updated: January 2026

On a Kenmore top-mount refrigerator like model 79579432211, the most expensive repair is typically the compressor (sealed system) because it is a major component and usually requires specialized labor. Other high-cost repairs can include an electronic control board or ice maker assembly.

What usually costs the most (and why)

The compressor is the heart of the cooling system. Replacing it often involves sealed-system work, which is why the total repair cost is commonly higher than most other part replacements.

Common high-cost items include:

  • Compressor: major cooling component; sealed-system labor is typically the biggest cost driver
  • Electronic control board: can be expensive and is model-specific
  • Ice maker assembly: higher part cost than many mechanical items
  • Door assembly: large, model-specific, and costly to ship/handle
  • Shelves and bins: can be surprisingly expensive, but usually less than sealed-system repairs

Examples of higher-priced parts for model 79579432211

These are examples of parts on this model that tend to be on the higher end compared to switches, gaskets, and small hardware:

Part type Example part for this model Why it can be costly
Compressor Refrigerator compressor TCA35931726 Sealed-system component; labor is typically high
Control board Refrigerator electronic control board EBR74799501 Model-specific electronics
Ice maker Refrigerator ice maker assembly 5989JA0002X Large assembly with multiple components

How we decide whether a big repair is worth it

Before investing in a compressor, control board, or ice maker repair, we recommend these practical checks:

  • Confirm the symptoms and any displayed error indicators using the 79579432211 manual
  • Check for simple airflow issues (blocked vents, heavy frost, door left ajar)
  • Inspect door sealing and closing; warm air leaks can mimic cooling failures
  • Clean condenser cover and vents as described in the manual (dust buildup can hurt cooling)
  • If the issue involves LED lighting, follow the manual guidance that service should be performed by a qualified technician

Why it matters

High-cost parts are often tied to core cooling performance (compressor) or model-specific electronics (control board). Ruling out basic issues first helps avoid replacing an expensive part when the real cause is airflow, maintenance, or a door-seal problem.

Last updated: January 2026

Kenmore refrigerator model 79579432211 is a top-mount (top freezer) refrigerator in the Kenmore 795.7940* and 795.7943* model series. For exact exterior dimensions (width, depth, height) and capacity for your specific color/version, we recommend checking the specifications section in the 79579432211 owner's manual.

How to find the exact dimensions for 79579432211

Use these quick checks so you measure and compare the right “size”:

  • Look for a specifications or product dimensions section in the manual
  • Confirm whether depth is listed with handles or without handles
  • Check if height is listed to the top of hinge (common for refrigerators)
  • Measure your opening and allow airflow clearance behind and above the cabinet
  • If you are replacing an older unit, measure the door swing and pathway clearance too

Typical size range for Kenmore top-mount refrigerators (helpful for planning)

Most Kenmore top-mount refrigerators in this style commonly fall into these planning ranges:

Measurement Typical range
Width 29 to 33 inches
Height 66 to 70 inches
Depth 30 to 34 inches
Capacity 18 to 23 cu. ft.

These ranges help with rough planning; use the manual specs for the exact numbers for 79579432211.

Why it matters

Getting the correct “size” prevents fit issues in a cabinet opening and helps avoid airflow problems that can lead to warm temperatures, frost buildup, or longer compressor run times.

If you are troubleshooting cooling or door-closing issues while checking fit, a worn door seal can also affect performance; see how to fix a fridge door seal for common checks.

Last updated: January 2026
