Kenmore Elite 79691963710 dryer Parts

On the Kenmore Elite dryer model 79691963710, the model number is printed on the identification plate located inside the dryer door. Open the door and look along the door opening on the cabinet frame for the label that lists the model and serial number (useful for parts and service).

Check these common label locations in this order:

• Inside the dryer door opening on the cabinet frame (most common)
• Along the front opening near the lint screen housing area
• On the inner door area near the hinge side (less common)
• If the label is worn: look for a second sticker nearby with the serial number

For diagrams and the exact identification-plate location notes, use the 79691963710 owner's manual.

The identification plate typically includes:

• Model number (example: 79691963710)
• Serial number
• Electrical rating information
• Certification markings

• Wipe the label gently with a damp cloth to remove lint and film.
• Use a flashlight and view from an angle; faded ink is easier to read.
• Take a photo and zoom in to confirm each digit.

We use the full model number to match the correct Kenmore Elite dryer parts and diagrams. Even one wrong digit can lead to ordering the wrong component (for example, a control board, door switch, or thermostat that will not fit).

Last updated: January 2026

The model number for this Kenmore Elite dryer is 796.9196* (the asterisk is the color code); your specific unit is 79691963710. You can also confirm the exact model and serial number on the identification plate inside the dryer door; see the 79691963710 owner's manual.

We recommend checking the appliance label so you match parts and instructions correctly.

• Open the dryer door.
• Look for the identification plate inside the door opening.
• Record both the model number and serial number.
• Keep the information with your purchase date for service and parts ordering.

Kenmore Elite model numbers are often shown with punctuation and a color placeholder in manuals.

Using the exact model number helps us match the correct parts and diagrams for your dryer, especially for items that vary by revision, such as the control panel, electronic control board, or door components.

Last updated: January 2026

A Kenmore dryer typically lasts 10 to 13 years. With consistent airflow and lint maintenance, many units reach 15 years; the biggest life-shorteners are restricted venting, overheating, and running the dryer with worn drum support parts. For model-specific care steps, use the 79691963710 owner's manual.

• Venting and airflow: lint buildup forces longer run times and higher heat.
• Lint filter care: a clogged or wet filter reduces airflow.
• Load size: overloading strains the motor, belt, and drum support system.
• Heat system health: repeated overheating can damage thermostats and wiring.
• Wear parts condition: rollers, idler pulley, and belt wear gradually and get noisy before failing.

The Kenmore Elite 79691963710 manual calls out regular lint and ductwork care; following a simple schedule is the easiest way to extend lifespan.

If your dryer is getting loud, squealing, thumping, or taking longer to dry, these are common wear items to inspect and replace.

• Dryer drum support roller 4581EL2002H (thumping, rumbling)
• Dryer idler pulley 4560EL3001A (squealing, belt slip)
• Dryer drum belt 4400EL2001D (drum not turning, burning rubber smell)
• Lint screen and venting components (slow drying, overheating symptoms)

A dryer that dries slowly usually is not “just getting old”; it is often running with restricted airflow. That extra heat and run time accelerates wear on the motor, belt, drum rollers, and safety thermostats, shortening the dryer’s usable life.

Last updated: January 2026

To hard reset your Kenmore Elite dryer model 79691963710, turn it off, unplug it (or switch the breaker off) for 1 to 5 minutes, then restore power and start a Normal cycle. This clears temporary control glitches but does not fix airflow, power, or safety shutoff problems.

• Press POWER to turn the dryer off.
• Unplug the dryer (or turn the circuit breaker off).
• Wait 1 to 5 minutes.
• Restore power.
• Select Normal.
• Press START/PAUSE to begin.

For button functions and cycle behavior, follow the 79691963710 owner's manual.

A reset will not correct a door circuit, control lock, or supply power issue.

• Confirm the door closes firmly and latches.
• If CL shows, press and hold CHIME for 3 seconds to toggle Control Lock.
• Make sure the cord is fully seated and the outlet has power.
• Reset the breaker; electric dryers can sometimes run with no heat if one leg trips.

If drying is slow or CHECK VENT appears, focus on airflow. This model has a built-in vent test (Power, then hold Temp and Chime, then START/PAUSE) described in the manual.

• Clean the lint screen before every load.
• Check the vent hose for kinks or crushing.
• Clear lint from the duct to the outside hood.

The dryer uses safety and performance checks (door circuit, power supply, vent restriction) that a reset cannot override; fixing the root cause prevents no-start, no-heat, and overheating conditions.

Last updated: January 2026
