Kenmore Elite 79097313412 electric range Parts

On the Kenmore Elite electric range model 79097313412, the most common problems we see are uneven baking or temperature swings, surface elements that will not heat or will not regulate, oven door lock issues during self-clean, and control or indicator light failures. Use the owner's manual for model-specific operating and error-code details.

Common symptoms and what usually causes them

• Oven not heating evenly or takes too long to preheat: failing temperature sensor, weak bake element, or airflow issues.
• Oven temperature seems inaccurate: temperature sensor drifting out of range.
• Surface burner stays on high or will not turn on: failed surface element control switch.
• Self-clean will not start or door will not unlock: door lock motor or lock switch problem.
• Display, beeping, or intermittent oven operation: relay/control board or wiring connection issue.

Parts that commonly fix these issues

If your symptoms match, these model-compatible parts are frequent solutions:

• Range oven temperature sensor 5304504897 for temperature accuracy and error conditions tied to sensing.
• Frigidaire range surface element control switch 316238201 or range triple surface element control switch 5304490134 for burner control problems.
• Range oven door lock motor and switch assembly 5304528973 for self-clean lock and unlock failures.
• Frigidaire range oven relay control board 316443927 for control-related heating or communication issues.

Quick checks we recommend before replacing parts

1. Confirm the range has the correct power supply (a range typically needs 240 volts for full heating).
2. Inspect the terminal block and power cord connections for heat damage (turn power off first).
3. For baking issues, test with an oven thermometer and compare results across multiple cycles.
4. For burner issues, try a different burner position (if your cooktop design allows) to isolate switch vs. element.
5. After self-clean, allow a full cool-down; many locks stay engaged until the oven is below a safe temperature.

Symptom-to-part cheat sheet

Symptom	Most likely area	Common part on this model
Oven temp off by 25 to 50 degrees	Temperature sensing	Range Oven Temperature Sensor 5304504897
Burner stuck on high	Infinite switch	Frigidaire Range Surface Element Control Switch 316238201
Self-clean door will not unlock	Lock mechanism	Range Oven Door Lock Motor And Switch Assembly 5304528973
No bake or intermittent heat	Control or heating circuit	Frigidaire Range Oven Relay Control Board 316443927

Why it matters

Catching the right failure early protects expensive components (like the control board), improves cooking results, and reduces the chance of overheated wiring at the terminal block.

Last updated: March 2026

For the Kenmore Elite electric range model 79097313412, the exact oven capacity and exterior dimensions are listed in the product specs section of the documentation; use the 79097313412 owner's manual for the official size information for your specific configuration.

What “size” usually means for an oven

Oven “size” can refer to more than one measurement. Before ordering parts or planning a cutout, we recommend confirming which spec you need:

• Oven capacity (cubic feet)
• Overall range dimensions (width, height, depth)
• Cutout/opening requirements (for slide-in or built-in installs)
• Door-open depth (clearance in front of the range)
• Interior cavity dimensions (usable rack space)

How to find the correct dimensions for model 79097313412

We recommend pulling the measurements from the documentation for this exact model number (not a similar 790-series range), then measuring your unit as a double-check.

• Check the specifications section in the 79097313412 owner's manual
• Use the 79097313412 installation guide for clearance and opening requirements
• Measure the range at the widest points (handle and rear cover can change depth)
• If you are replacing an older range, compare depth to the backguard and depth to the handle

Quick reference: which document to use

If you need this	Best source to use
Oven capacity (cu. ft.)	Owner's manual/spec sheet
Overall width/height/depth	Owner's manual
Cutout, clearance, anti-tip placement	Installation guide

Why it matters

Using dimensions from a different Kenmore Elite 790 model can lead to fit issues (counter depth, door clearance, or required side clearances). Confirming the specs for 79097313412 helps you plan installation and avoid ordering the wrong accessories.

Last updated: January 2026

Kenmore model 79097313412 is made for Kenmore by Frigidaire (Electrolux/Frigidaire family). We identify the manufacturer by the 790 prefix in the model number, which is the source code used on many Kenmore ranges.

How to confirm it on your range

You can verify the model and prefix on the appliance identification label, then match the prefix to the manufacturer.

• Check the ID label for the full model number: 79097313412
• Confirm the first three digits are 790
• Use the prefix to identify the manufacturer (Frigidaire for 790)
• Keep the full model number handy when ordering parts like a control board or surface element switch

What the 790 prefix means (quick reference)

Kenmore model prefix	Typical manufacturer	What it helps with
790	Frigidaire	Parts lookup, wiring diagrams, service-style design
970	Frigidaire	Same manufacturer family, different product lines
791	Frigidaire	Same manufacturer family, different product lines

Why it matters when buying parts

Knowing Frigidaire made this Kenmore Elite electric range helps you match the correct component design and electrical connectors when you replace parts such as the oven temperature sensor, relay control board, or surface element control switch.

For model-specific diagrams and identification details, use the 79097313412 owner's manual and the 79097313412 installation guide.

Last updated: January 2026
