Kenmore 11069822800 dryer Parts

For Kenmore dryer model 11069822800, the model number is printed on the model and serial number label attached to the dryer cabinet. The label is typically easiest to spot when you open the dryer door and look around the door opening and cabinet frame.

Where to look on the dryer

Check these common label locations first (in this order):

• Inside the door opening on the cabinet frame (most common)
• On the inside edge of the door itself
• On the back of the dryer cabinet near the top
• Behind the lower front access panel (if your version has one)

Use the diagrams and location notes in the 11069822800 owner's manual to match what you see on your exact cabinet style.

What to write down (and why)

Record the full information exactly as shown on the label:

• Model number (example: 11069822800)
• Serial number
• Purchase date (if available)

Why it matters

The model number and serial number ensure we match the correct Kenmore dryer parts and troubleshooting steps for your exact build. Small design changes can affect fit for items like a dryer heating element, dryer door switch, or dryer timer.

Quick checklist: label found vs. next step

What you see	What to do next
Clear model and serial label	Use the model number to select exact parts and diagrams
Label is worn or missing characters	Take a photo with flash and zoom in; copy the full string exactly
No label in door area	Check the back near the top, then the lower front panel area

Last updated: February 2026

The Kenmore 11069822800 dryer cabinet measures about 43 1/2 in. high x 27 in. wide x 29 1/4 in. deep. Plan for extra space behind the dryer for the exhaust vent connection and elbow; that clearance affects the total installed depth. See the 11069822800 installation guide for the exact clearance diagram.

Dimensions and installation clearances

These are the key measurements we use when planning a standard installation:

• Height: 43 1/2 in. (110.5 cm)
• Width: 27 in. (68.6 cm)
• Depth (cabinet): 29 1/4 in. (74.3 cm)
• Recommended rear clearance for venting: typically 5 in. minimum for the exhaust vent and elbow
• Floor requirement: level within 1 in. slope across the full dryer footprint

Quick sizing table

What you’re measuring	What to use	Notes
Space for the dryer body	43 1/2" H x 27" W x 29 1/4" D	Cabinet size only
Space for a typical install	Add ~5" behind	Allows room for vent elbow
Closet door ventilation	Required in many installs	Follow the clearance diagram

Why the installed depth can be larger than the cabinet depth

Even though the dryer itself is 29 1/4 inches deep, the installed depth often increases because of:

• The exhaust vent elbow and duct routing
• The wall outlet location and cord strain relief
• Rear clearance needed to reduce vibration noise transfer
• Closet or recessed installation spacing recommendations

Related spec that helps with fit

If you use a dryer rack accessory, the manual notes rack compatibility by dryer width (27-inch vs 29-inch platforms). For rack use and cycle limitations, check the 11069822800 owner’s manual.

Last updated: February 2026

A Kenmore dryer like model 11069822800 typically lasts 13 years with normal household use. Keeping airflow strong (clean lint screen and venting) and replacing wear items like belts, rollers, and idler pulleys on time is what most often determines whether it reaches that lifespan.

What affects lifespan the most

• Vent restriction (long dry times, overheating, thermal cutoffs opening)
• Overloading the drum, which strains the drive system and motor
• Skipped cleaning (lint screen, lint ducting, blower housing)
• Worn drum support parts (noise, thumping, poor tumbling)
• Heat control issues (cycling too hot or not hot enough)

Maintenance that adds years

Use the care and cleaning schedule in the owner's manual and focus on these habits:

• Clean the lint screen every load; wash it with mild soap if you see residue.
• Check airflow: strong, steady exhaust outside while running.
• Clean the vent run periodically (more often with pets or heavy use).
• Avoid overloading; heavy loads wear the belt, idler, and drum supports faster.
• Address new noises early; they usually point to a wearable drive component.

Common wear parts and what they do

Symptom	Most likely wear area	Example part for this model
Squealing or chirping	Idler pulley or belt path	Dryer idler pulley 279640
Thumping or rumbling	Drum support components	Dryer repair kit 4392067
No heat or weak heat	Heating circuit	Dryer heating element WP3387747
Runs too hot or shuts off	Temperature sensing	Dryer thermistor WP8577274

Why it matters

A dryer can keep running past its average lifespan, but restricted airflow and worn drive parts often trigger repeat breakdowns. Preventive maintenance and timely part replacement usually cost less than repeated overheating or motor strain.

Last updated: March 2026
