Whirlpool WFW5620HW3 washer Parts

On a Whirlpool front load washer like model WFW5620HW3, the model and serial number label is typically on the door opening area (door jamb) or just inside the door. We recommend matching the full model number exactly before ordering parts or using troubleshooting steps in the WFW5620HW3 owner's manual.

• Door jamb (around the opening when you open the washer door)
• Behind the door (on the inner frame area)
• Along the front edge of the cabinet near the bottom
• Back of the control panel area (less common, but possible)
• Rear panel of the washer cabinet

1. Open the washer door and inspect the door opening frame with a flashlight.
2. Run your fingers along the jamb; the label is often a smooth sticker or metal plate.
3. If you do not see it, check the lower front cabinet edge and then the rear panel.
4. Write down both the model number and serial number; the serial helps confirm production details.

We use the model number to match the correct Whirlpool parts and diagrams for your washer. Even small model-number differences can change fitment for items like the door lock, water valve, or drain pump.

Last updated: February 2026

For Whirlpool washers, the most common issues we see are draining and spinning problems. On a front-load model like WFW5620HW3, that often traces back to restricted water flow out of the tub (coins, lint, small socks) or installation and maintenance items such as kinked hoses, poor leveling, or worn inlet hoses; use the WFW5620HW3 owner's manual to match symptoms to the right checks.

• Won’t drain: drain path restriction, pump area blockage, or a failing pump
• Won’t spin or stops mid-cycle: load imbalance, door not locking, or a drain issue preventing spin
• Leaks at the front: door boot (bellow) not sealing, debris on the seal, or a tear
• Won’t fill or fills slowly: faucet/house supply issue, clogged inlet screens, or a valve problem
• Excess vibration or walking: washer not level, feet not set firmly on the floor

1. Confirm both water supplies are on and connected; this washer needs both hot and cold connected to operate properly.
2. Inspect inlet hoses for bulges, kinks, cuts, wear, or leaks; replace hoses at 5 years as routine maintenance.
3. Level the washer; proper leveling reduces excess noise and vibration.
4. Run a cleaning cycle periodically; the Clean Washer cycle can prompt you to remove items (“rL”) and recommends leaving the door slightly open after the cycle for ventilation.

If the basic checks point to a failed component, these are frequent fixes on front-load Whirlpool washers:

Drain, fill, and vibration problems can trigger cycle interruptions, poor cleaning, and leaks. Staying on top of hose condition, correct hookups, and leveling helps prevent repeat failures and protects nearby flooring.

Last updated: February 2026

On Whirlpool washer model WFW5620HW3, the F6 E3 (or E3 F6) error points to a communication problem between the main control (appliance control unit) and the user interface (console), or a wiring connection issue between them. A power reset and connection checks typically resolve it.

• Press Power/Cancel to stop the cycle.
• Unplug the washer (or switch the breaker off) for 1 minute, then restore power.
• If the code returns, avoid repeated restarts; it can interrupt draining and door unlocking.
• Confirm the washer is plugged into a grounded 3-prong outlet and not using an extension cord.
• Follow the electrical and grounding guidance in the WFW5620HW3 owner's manual.

• Loose or oxidized wire connection between the console and main control
• Moisture or detergent residue affecting console connections
• Failed user interface (console) or main electronic control
• Power quality issue (shared circuit, intermittent outlet)

• Power supply: Use a dedicated 120 V, 15 A or 20 A circuit when possible.
• Console behavior: Random beeping, dead buttons, or flickering display often matches a UI communication fault.
• Recent events: Code appearing after moving the washer can indicate a connector that shifted.

If the reset does not hold, these are the most common components tied to control and UI communication:

F6 E3 is not a “load size” or “drain” code; it is a control-to-console communication fault. Fixing the underlying connection or control issue prevents repeated cycle interruptions and helps protect the washer’s electronics.

Last updated: February 2026

Whirlpool washer parts are not universally interchangeable, even within Whirlpool models. For Whirlpool model WFW5620HW3, we recommend replacing parts with the exact part listed for your model so fit, connectors, and control compatibility stay correct and the washer operates as designed.

Some items can look identical but still differ in mounting points, wiring plugs, hose sizes, or software calibration.

• Model-specific parts: control boards, door lock assemblies, sensors, pumps
• Sometimes interchangeable: screws, clamps, some hoses (only when length and fittings match)
• Rarely safe to swap: electronic parts between different model numbers or revisions
• Best practice: match by model number first, then confirm the part ID

Use your model number and the diagrams/part lists to avoid ordering a “close enough” replacement.

1. Verify the washer is WFW5620HW3 (from the model tag).
2. Use the parts list in the WFW5620HW3 owner's manual.
3. If you are installing or re-installing hoses and drain components, follow the WFW5620HW3 installation guide for the correct setup and clearances.

If your washer is not draining, a common model-correct replacement is the washer drain pump assembly W11458345. If the washer will not fill or fills incorrectly, the water valve W11688995 is a common model-matched part to check.

Using the exact Whirlpool WFW5620HW3 part prevents leaks, wiring issues, and repeat failures. It also reduces troubleshooting time because you are not introducing a compatibility variable into the repair.

Last updated: February 2026
