Kenmore 58716248701 dishwasher Parts

Yes. You can still get replacement parts for Kenmore dishwashers, and for Kenmore model 58716248701 we still see common service parts available such as door seals, drain components, and fill parts. The key is matching parts by the full model number and the exact part ID.

How to make sure you order the right part

Use the model number 58716248701 and confirm the part by name and part ID (not just a description). For this dishwasher, common examples include:

• Door leak fixes: gasket 809006501
• Drain problems: hose 807117001 or dishwasher drain pump A00126501
• No fill or slow fill: dishwasher water inlet valve 154637401
• Poor drying or no heat: heater 154665201

What parts are commonly still available (and what they do)

Symptom	Part type	Example for 58716248701
Water leaking at the door	Door seal / gasket	Gasket (809006501)
Dishwasher not draining	Drain hose or drain pump	Hose (807117001), Drain pump (A00126501)
Dishwasher not filling	Water inlet valve	Water inlet valve (154637401)
Dishes not drying	Heating circuit parts	Heater (154665201)

Why the model number matters for Kenmore

Kenmore dishwashers are built by different manufacturers across model lines, so “Kenmore dishwasher parts” is not specific enough. Using 58716248701 helps us match the correct fit, mounting style, and electrical connectors for items like a water inlet valve, float switch, or wire harness.

Helpful next steps before you buy

• Check your symptom first (leak, no drain, no fill, no heat)
• Look for visible wear: cracks, swelling, corrosion, loose clamps
• Confirm the part location and access steps in the 58716248701 installation guide
• Use the diagrams and part list to match the exact part ID

Why it matters

Ordering by model number and part ID prevents returns and repeat repairs, especially on fit-critical items like a door gasket, drain hose routing, and inlet valve connections.

Last updated: February 2026

To identify your Kenmore dishwasher model, open the door and look for the model and serial number label on the right side of the tub or along the inner door frame. For this model page, the correct model number format is 587.1624__ (example: 58716248701). See the 58716248701 owner's manual diagram for the label location.

Where to look on the dishwasher

Check these common label locations first (in order):

• Right side wall of the tub (most common on Kenmore 587 models)
• Inner door frame or top edge of the door opening
• Along the tub opening near the latch area
• Lower edge of the door (inside), near the hinge area
• Behind the toe-kick panel (if the label is missing inside the tub)

What the model number looks like (and why it matters)

Kenmore dishwashers often use a prefix that identifies the manufacturer series. For this Kenmore family, you will typically see 587.1624__ on the label, and the full model on our parts page is 58716248701.

Quick ID guide

What you see on the label	What it means	What to do next
587.1624__	Model family/series format	Match the full number to order parts
58716248701	Full model number	Use this exact number for parts lookup
Serial number	Production identifier	Keep it for service records

Tips to avoid ordering the wrong part

Even one digit off can change the door seal, drain hose routing, or control panel style. Before ordering, we recommend:

• Copy the model number exactly as printed (including dots and any suffix)
• Take a clear photo of the label for reference
• Use the model number when selecting parts like a door seal or drain hose
• Confirm the part description matches your symptom (leak, no drain, won’t start)

Why it matters

The model number ties your dishwasher to the correct parts diagrams and repair instructions, which helps you get the right fit for items like the wash system components, door latch parts, and rack hardware.

Last updated: February 2026

Yes; repairing a Kenmore dishwasher such as model 58716248701 is worth it when the failure is a single, common wear item (door leak, drain issue, rack roller) and the repair total stays well below the cost of a comparable replacement. Multiple major failures at once usually shifts the value toward replacement.

Quick repair vs replace checklist

We use these checkpoints before ordering parts:

• Age: Under 10 years favors repair; over 10 years depends on overall condition.
• Repair cost: If the repair approaches 50% of replacement cost, replacement usually makes more sense.
• Failure count: One failed part is a good repair candidate; two major components at once is not.
• Leak risk: Active leaks should be addressed quickly to protect cabinets and flooring.
• Performance: Poor cleaning often improves with maintenance and correct loading first.

Common, cost-effective repairs for model 58716248701

Symptom	Likely cause	Example part for this model
Water leaking at the door	Worn lower door seal	Gasket 809006501
Won’t drain or drains slowly	Clogged/kinked drain path or weak pump	Hose 807117001 or dishwasher drain pump A00126501
Won’t fill	Inlet valve problem or supply issue	Dishwasher water inlet valve 154637401
Rack won’t roll smoothly	Worn lower rack rollers	Dishwasher dishrack roller, lower 5304532229

Why it matters

This dishwasher recirculates filtered water for cleaning; when sealing, filling, or draining is compromised, you get poor wash results and higher risk of water damage. Targeting the most likely failure point keeps the repair cost-effective.

What to check first

Follow the troubleshooting and care steps in the 58716248701 owner’s manual:

• Confirm the door closes and latches firmly; inspect the seal for gaps or tears.
• Check for standing water; clear the filter area and drain path.
• Verify the water supply valve is open and the inlet line is not kinked.

Last updated: February 2026

The Kenmore dishwasher model 58716248701 fits a standard built-in dishwasher opening; most installations use a 24-inch-wide cabinet space with an opening height that can be adjusted using the leveling legs. For the exact fit requirements and leveling targets, use the 58716248701 installation guide.

Standard opening and fit guidelines

For Kenmore built-in dishwashers like 58716248701, the cabinet opening and leveling setup matter more than the outer shell measurements.

• Typical cabinet width: 24 inches (standard built-in dishwasher space)
• Typical overall height range: about 33 3/4 to 35 inches depending on leg adjustment
• Typical depth: about 24 inches plus door thickness (varies by handle and panel style)
• Minimum opening height called out for fit: 33 3/4 inches (measured from underside of countertop to floor)
• Leveling is required side-to-side and front-to-back for proper door sealing and draining

What the installation guide tells you to measure

Use these measurements before you slide the dishwasher into the opening:

• Measure from the underside of the countertop to the floor
• Confirm you have at least 33 3/4 inches of opening height
• Adjust the front and rear leveling legs to match the opening
• Verify the unit is level using a bubble level (top front of tub and along the opened door)

Quick fit reference table

What you measure	Where you measure it	What to look for
Opening height	Countertop underside to floor	At least 33 3/4 in. for a standard fit
Level, side-to-side	Across top front of tub	Bubble centered
Level, front-to-back	Along side of opened door	Bubble centered

Why it matters

Correct sizing and leveling prevents common problems like door leaks, poor wash performance (spray arms hitting racks), and drain issues caused by standing water in the sump.

Related parts that affect “fit” symptoms

If you are checking size because of leaking or door alignment, these parts are often involved:

• Gasket 809006501 (lower door seal)
• Door latch strike alignment (door must close squarely)
• Rack rollers and rack position (racks should glide without forcing the door)

Last updated: February 2026
