Kenmore Elite 11078062801 dryer Parts

For Kenmore Elite dryer model 11078062801, the most reliable way to get cubic feet is to look up the listed “capacity” in the product specifications section of the 11078062801 owner's manual. If you do not see capacity listed, you can calculate it by measuring the drum and converting the drum volume to cubic feet.

Option 1: Find capacity in the manual (fastest)

Check the specifications or feature summary in the 11078062801 owner's manual. Capacity is typically shown as “cu. ft.” or “cubic feet.”

• Look for headings like Specifications, Features, or Product dimensions
• Search within the PDF for capacity, cu. ft., or cubic
• Use the model number 11078062801 from the rating label to confirm you have the correct manual

Option 2: Calculate cubic feet from drum measurements

Dryer drums are cylinders, so you can calculate volume from diameter and depth.

• Unplug the dryer before measuring
• Measure inside drum diameter (wall to wall through the center)
• Measure inside drum depth (front lip to back wall)
• Convert inches to feet (divide by 12)
• Use: Cubic feet = π × (radius in feet)² × (depth in feet)

Quick conversion table

What you have	Convert to	Formula
Inches	Feet	inches ÷ 12
Diameter	Radius	diameter ÷ 2
Cylinder size	Cubic feet	π × r² × depth

Why it matters

Cubic-foot capacity helps us compare dryer sizes, choose realistic load sizes (bedding vs. everyday loads), and avoid overloading that can increase dry time and wear on drum support components.

Last updated: February 2026

On Kenmore Elite dryer model 11078062801, the most common display codes are PF (power failure) and F-series service codes (such as F1, F2, F20). PF is typically cleared by restarting the cycle; F-codes indicate a control-related fault that needs service guidance from the 11078062801 owner's manual.

Common codes and what they mean

• PF: Power failure interrupted the cycle.
• F1 (F:01): Main electronic control board fault.
• F2 (F:02): Keypad or user interface fault.
• F20: Heater relay fault.
• F22 / F23: Outlet thermistor fault.
• F24 / F25: Inlet thermistor fault.

What to do when a code appears

1. PF code
   • Press and hold START to restart the dryer.
   • If PF returns often, check the outlet, breaker, and power cord connection.
2. Any F-series code (F1, F2, F20, etc.)
   • Unplug the dryer for 1 minute, then restore power and retry.
   • If the code returns, follow the service steps in the manual or schedule service.

Quick troubleshooting table

Code type	What it points to	Best next step
PF	Power interruption	Press and hold START to restart
F1 / F2	Control or keypad issue	Power reset; then service if it returns
F20	Heater relay/control issue	Stop using heated cycles; service
F22-F25	Temperature sensing circuit	Check airflow first; then service

Why it matters

These codes help separate power interruptions (PF) from component or control failures (F-codes). Addressing airflow and overheating risks also helps prevent repeat shutdowns that can lead to blown safety devices like the dryer thermal fuse WP3390719.

For a fuller list and definitions across Kenmore Elite dryers, use our Kenmore elite dryer error codes reference.

Last updated: February 2026

A Kenmore dryer typically lasts 10 to 13 years. With consistent care on your Kenmore Elite 11078062801 (especially lint and vent cleaning), it’s common to reach 15 years or more before major repairs like a belt, drum rollers, or a thermal fuse become likely.

Typical lifespan and what affects it

Most dryers fail early from heat stress and airflow restriction, not from “age” alone. These factors have the biggest impact:

• Vent restriction (long runs, crushed flex duct, clogged hood)
• Lint buildup inside the cabinet and exhaust ducting
• Overloading (extra strain on the drive belt, idler, and drum supports)
• High-heat cycles used constantly (more wear on thermostats and fuses)
• Moisture and corrosion in laundry areas (garage, damp basement)

Maintenance schedule we recommend

Your model’s care guidance calls out regular lint removal and periodic deep cleaning. Use this as a practical schedule:

• Every load: Clean the lint screen
• Monthly: Check airflow at the outside vent hood (strong, steady flow)
• Every 6 to 12 months: Clean the full vent run from dryer to outside
• Every 2 years: Have lint removed from inside the dryer cabinet and exhaust vent (more often with heavy use); see the 11078062801 owner's manual

Parts that commonly wear as a dryer ages

If your dryer still runs but gets noisy, stops tumbling, or shuts off from overheating, these are common wear items on this platform:

Symptom	Common wear area	Example part for this model
Squealing, thumping	Drum support rollers, idler	Support WPW10314173
Drum not turning	Belt, idler	Dryer drum belt WP8547157
Runs but no heat (often after overheating)	Thermal fuse, cutoff	Dryer thermal fuse WP3390719

Why it matters

Knowing the expected lifespan helps you decide whether to maintain, repair, or replace. On a 10 to 13-year-old dryer, restoring airflow and replacing common wear parts often brings back safe, efficient drying and prevents repeat overheating failures.

Last updated: February 2026

On Kenmore Elite dryer model 11078062801, the model and serial information is on the rating plate in the door well; open the dryer door and look around the door opening (cabinet frame) for the label. The 11078062801 owner's manual also references the rating plate location.

Where to look first (fast checklist)

• Open the dryer door and inspect the door opening (the door well).
• Check the cabinet frame near the latch side and hinge side.
• Look along the top edge of the door opening.
• Use a flashlight; the print can be small or lightly stamped.
• Wipe dust off the label so the model number is readable.

What the label may be called

You may see any of these terms on the same plate:

• Model/serial rating plate
• Rating plate
• Model and serial tag

Why it matters

We use the exact model number to match Kenmore parts and diagrams to your dryer so you get the correct items (for example, a belt, thermal fuse, or drum support roller) the first time.

Quick reference table

What you need	Where it’s typically found on this model	What it’s used for
Model number	Door well rating plate	Parts lookup and compatibility
Serial number	Door well rating plate	Date/series identification for service

Last updated: February 2026
