Kenmore 10672153110 refrigerator Parts

For Kenmore top-mount refrigerator model 10672153110, the cabinet measures about 66 3/4 in. high (with hinge), 65 7/9 in. high (without hinge), 33 7/9 in. deep (with handle), and 32 1/8 in. deep (without handle). Use the 10672153110 owner's manual to confirm clearance needs for your exact installation.

Quick dimension breakdown

• Height (with hinge): 66 3/4 in.
• Height (without hinge): 65 7/9 in.
• Depth (with handle): 33 7/9 in.
• Depth (without handle): 32 1/8 in.
• Plan extra space for door swing and airflow behind the cabinet.

Clearance planning tips (what we recommend)

Even with correct cabinet dimensions, most top-mount refrigerators need a little extra room to run efficiently and open comfortably.

• Leave space so the doors open fully without hitting walls or cabinets
• Keep the back from being pushed tight against the wall (helps airflow at the condenser area)
• Confirm the water line routing if your unit has an ice maker or water supply
• Measure the narrowest point on your path (doorways, turns, stairs)
• If you are replacing a door seal, a good seal helps the unit maintain temperature and reduces run time

Dimensions at a glance

Measurement point	Dimension
Height without hinge	65 7/9 in.
Height with hinge	66 3/4 in.
Depth without handle	32 1/8 in.
Depth with handle	33 7/9 in.

Why it matters

Accurate refrigerator dimensions help prevent delivery surprises, ensure proper ventilation for the compressor, and reduce issues like warm temperatures or excessive run time caused by restricted airflow.

Last updated: January 2026

A top-mount refrigerator is a classic refrigerator layout where the freezer compartment is on top and the fresh-food (refrigerator) compartment is below. Your Kenmore 10672153110 is a top-mount style, designed for straightforward storage, easy freezer access, and reliable everyday cooling.

How a top-mount layout is set up

In a top-mount refrigerator, cold air is produced at the evaporator and circulated to keep both sections cold, with the freezer on top typically running colder than the fresh-food section.

Common features you will see in many top-mount models:

• Freezer door on top, refrigerator door below
• Separate temperature controls (or a shared control that balances both sections)
• Evaporator fan moving air through vents between compartments
• Defrost system to prevent frost buildup on the evaporator

Why people choose a top-mount refrigerator

Top-mount refrigerators are popular because they balance capacity, simplicity, and cost.

Benefit	What it means day to day
Simple design	Fewer complex features to maintain
Good freezer access	Frozen foods are at eye level for many users
Efficient use of space	Strong storage capacity for the footprint
Often lower repair cost	Common parts and straightforward service access

Parts that support cooling and airflow (examples)

If cooling performance ever drops, these are common systems we check first on a top-mount refrigerator like the Kenmore 10672153110:

• Evaporator fan system (moves cold air): refrigerator evaporator fan motor WP2315539
• Defrost system (prevents ice blockage): defrost heater, defrost thermostat (bi-metal), and timer/control
• Sealed system components (compressor, condenser, drier)

Why it matters

Knowing the refrigerator style helps you troubleshoot correctly. For example, warm refrigerator temperatures with a cold freezer often point to an airflow or defrost issue, not a door gasket problem.

For model-specific operating details (controls, airflow vents, cleaning, and normal sounds), use the 10672153110 owner's manual.

Last updated: January 2026

On a Kenmore top-mount refrigerator like model 10672153110, the upper section is typically called the freezer compartment (or simply the freezer). It is the colder compartment designed to keep foods frozen and often houses the ice maker and airflow components.

Common names you will hear

• Freezer compartment: the standard name for the upper section on a top-mount refrigerator
• Freezer section: another common term used in manuals and parts diagrams
• Freezer liner: the interior “box” walls of the freezer
• Freezer door: the upper door that seals the freezer opening
• Freezer evaporator area: where the cooling coil and fan move cold air

What’s usually located in the upper (freezer) section

Many Kenmore top-mount designs place key cooling and ice-making parts in or behind the freezer area, such as:

• Ice maker assembly (if equipped)
• Evaporator fan and fan blade (circulates cold air)
• Defrost heater and defrost thermostat (bi-metal)
• Air ducts/damper passages that send cold air down to the fresh food section

Example parts you may see associated with freezer operation

Function	Example part for model 10672153110	What it affects
Makes ice	Refrigerator ice maker 4317943	Ice production and harvest
Moves cold air	Refrigerator evaporator fan motor WP2315539	Freezer cooling and refrigerator cooling
Defrost protection	Refrigerator defrost bi-metal WP627985	Frost control and temperature regulation

Why it matters

Knowing the correct name helps you match symptoms to the right area. For example, “freezer cold but fridge warm” often points to airflow issues (evaporator fan, frost buildup, or blocked vents) rather than a problem in the fresh food compartment.

Where to confirm terms for your exact layout

We recommend checking the diagrams and terminology in the 10672153110 owner's manual, especially if your unit has optional features like an automatic ice maker.

Last updated: January 2026
