Kenmore 25321742513 upright freezer Parts

On a Kenmore upright freezer like model 25321742513, the model number is printed on a rating label inside the cabinet or on the exterior cabinet near the base. We most often see it on an inside side wall, the ceiling area, or behind the lower kick plate.

Common places to check

• Inside the freezer on a side wall (upper or mid-level)
• Inside the freezer on the ceiling area
• Along the door opening (door jamb) near the hinge side
• Behind the lower toe grille or kick plate
• On the back of the cabinet near the bottom

Quick steps to find it fast

1. Open the door and scan the inside side walls first.
2. Look up at the interior ceiling panel area.
3. Check the door opening frame around the gasket.
4. If you see a toe grille or kick plate, remove it and look for the label behind it.

What the label usually includes

Label item	What it’s used for
Model number	Matching the correct parts diagrams and parts list
Serial number	Identifying production run and version differences
Electrical ratings	Verifying power requirements for safe service

Why it matters

The exact model number helps us match the right Kenmore upright freezer parts (like a door switch, door gasket, or temperature control) because small design changes can affect fit and wiring.

For model-specific label location notes and diagrams, check the 25321742513 owner's manual.

Last updated: February 2026

A Kenmore upright freezer like model 25321742513 typically lasts 10 to 15 years with normal household use. Consistent temperatures, clean airflow, and a tight door seal are the biggest factors that help an upright freezer reach the high end of that range.

Typical lifespan and what affects it

Most upright freezers fall into a similar life expectancy range, but day-to-day conditions make a real difference.

• Room temperature and ventilation: Hot garages and blocked airflow make the compressor work harder.
• Door seal condition: A leaking gasket causes longer run times and frost buildup.
• Cleaning and maintenance: Dust on condenser areas reduces heat transfer.
• How often the door is opened: Frequent openings add moisture and warm air.
• Power quality: Repeated outages or surges can stress electrical components.

Quick checks that help your freezer last longer

Use these practical habits to reduce wear on the sealed system and cooling components.

• Keep the freezer set near 0°F (typical target for food safety and performance).
• Make sure the door closes fully; replace worn seals such as the freezer door gasket, 32-7/8 x 61-1/4-in (white) 5304505529 when needed.
• Avoid overpacking; leave space for air circulation between shelves.
• Defrost and remove heavy frost if your unit is not self-defrosting.
• Review cleaning and operating guidance in the owner's manual.

When “end of life” is near: common symptoms

These issues often show up as a freezer approaches the end of its service life.

Symptom	What it often points to	What to check first
Warmer temps or thawing	Cooling system struggling	Door seal, airflow, thermostat setting
Heavy frost on walls/shelves	Air leak or defrost issue	Door gasket, door alignment
Clicking, then no start	Start components	Start relay and run capacitor
Runs constantly	Heat load or air leak	Room temp, gasket, condenser cleanliness

Why it matters

A freezer that runs longer than it should uses more electricity and can shorten the life of key components like the compressor. Catching gasket leaks, airflow problems, and early electrical symptoms helps protect food and extend the service life.

Last updated: February 2026

An upright freezer like Kenmore 25321742513 usually stops freezing because the sealed system is not moving heat (compressor/start components), the temperature control is not calling for cooling, or warm air is leaking in through the door. Use the owner's manual to confirm control settings and basic checks.

Most common causes (and what to look for)

• Start components failing: clicking, humming, or the compressor tries to start then stops; check the freezer start relay 297259515 and gibson refrigerator run capacitor 297286803.
• Temperature control issue: freezer runs too warm or won’t cycle correctly; inspect the control and consider the freezer temperature control thermostat 5304514707.
• Door not sealing: frost buildup, longer run times, or warm spots near the door; inspect the gasket and consider the frigidaire freezer door gasket, 32-7/8 x 61-1/4-in (white) 5304505529.
• Dirty or blocked heat rejection: poor cooling and hot cabinet sides; clean airflow areas and keep clearance around the unit.
• Frosted evaporator (airflow blocked): weak airflow, heavy frost behind the rear panel; defrost system or airflow problems are likely.

Quick checks we recommend before replacing parts

• Verify the control is set colder and the freezer has 24 hours to stabilize after changes.
• Make sure the door closes fully; check for packages preventing closure.
• Look for heavy frost on the back interior panel (a sign airflow is blocked).
• Listen for the compressor: steady running, repeated clicking, or silence.
• Unplug the freezer for 5 minutes, then restore power and observe start-up behavior.

Symptom-to-part guide

Symptom	Most likely area	Parts on this model page that often apply
Repeated clicking, won’t start	Compressor start circuit	Start relay, run capacitor
Runs but not cold enough	Temperature control or airflow	Temperature control thermostat, door gasket
Frost buildup near door	Air leak	Door gasket, gasket fasteners
Light stays on with door closed	Door switch	Door switch

Why it matters

A freezer that is not freezing can quickly lead to food spoilage and can overwork the compressor. Catching a door-seal leak or a failing start relay early often prevents bigger, more expensive repairs.

Last updated: February 2026

Most Kenmore upright freezers, including model 25321742513, do not have a single dedicated “reset” button. A practical reset is to power-cycle the freezer (unplug, wait, then restore power); if your unit has electronic temperature controls, a button-combo reset may also be available in the control panel instructions in the owner's manual.

How to reset a Kenmore 25321742513 upright freezer

• Power reset (most reliable): Unplug the freezer for 5 minutes, then plug it back in.
• If the freezer is hardwired or difficult to reach, turn OFF the circuit breaker for 5 minutes, then turn it back ON.
• After restoring power, allow 24 hours for temperatures to fully stabilize.
• If your freezer has Up/Down temperature buttons, check the control section in the owner's manual for any specific “press and hold” reset procedure.
• If the control is unresponsive after a reset, inspect for a door not closing fully or a light switch issue.

When a “reset” will not fix the problem

A reset only clears minor control glitches. If the freezer still will not cool or the alarm returns, these are the most common causes to check:

• Door not sealing (warm air leaks)
• Door not fully closing or misaligned
• Start components failing (compressor tries to start, then clicks off)
• Dirty condenser area restricting heat removal
• Temperature control issue

Quick symptom-to-part checklist

Symptom	What to check first	Related part for this model
Interior light stays on, alarm, warm temps	Door switch operation	Freezer door switch 216822900
Frost, moisture, or warm edge around door	Door gasket condition	Freezer door gasket, 32-7/8 x 61-1/4-in (white) 5304505529
Clicking, humming, then stops cooling	Start device and capacitor	Freezer start relay 297259515 and gibson refrigerator run capacitor 297286803

Why it matters

Resetting can restore normal operation after a brief power event, but repeated warm-temperature issues usually point to airflow, door sealing, or a starting/cooling component problem. Checking the door seal and start components early helps prevent food loss and compressor strain.

Last updated: February 2026

The Kenmore upright freezer model 25321742513 is a full-size upright freezer. For the exact capacity (cubic feet) and exterior dimensions (H x W x D) for this specific model, use the specifications section in the 25321742513 owner's manual.

What “size” can mean for model 25321742513

When you’re matching a replacement freezer or planning an install space, “size” usually refers to one or more of these:

• Capacity (cu ft): total storage volume
• Exterior dimensions: height, width, depth (fit through doorways and into the spot)
• Door swing clearance: space needed to open the door fully
• Usable storage: shelf and bin layout versus total capacity

How to get the exact size (fast checklist)

Use this approach to confirm the correct numbers for your Kenmore 25321742513:

• Open the 25321742513 owner's manual and look for Specifications or Product dimensions
• Measure width at the widest point (often hinges)
• Measure depth including the handle if it protrudes
• Measure height to the top (include hinge cover if present)
• Plan clearance for airflow and door swing

Measurement	What to include	Why it matters
Width	Cabinet plus hinges	Prevents binding in a tight opening
Depth	Cabinet plus handle	Avoids blocking walkways/doors
Height	Top of cabinet/hinge area	Ensures overhead clearance
Capacity	Listed in specs	Confirms storage needs

Why it matters

Using the exact specs for 25321742513 prevents fit problems and helps you match parts correctly. For example, door sealing parts must match the door size; the frigidaire freezer door gasket, 32-7/8 x 61-1/4-in (white) 5304505529 is sized for specific door dimensions.

Last updated: February 2026
