Kenmore Elite 79097473800 electric range Parts

The Kenmore Elite electric range model 79097473800 is a 30-inch class freestanding range (the manual covers models 790.9747* and 790.9748*). For exact exterior dimensions and oven capacity for your specific configuration, use the dimensions section in the owner's manual.

What “size” usually means for this range

When customers ask for oven size, it typically refers to one of these measurements:

• Overall range width (commonly about 30 inches for this model family)
• Overall height (varies with leveling legs and floor)
• Overall depth (varies with handle and rear clearance)
• Oven capacity (cubic feet, sometimes listed separately)
• Usable rack positions (this range has multiple rack positions for cooking flexibility)

How to confirm the exact dimensions for model 79097473800

We recommend verifying the exact measurements using the documentation for your model series.

• Check the specifications/dimensions page in the owner's manual
• If you are measuring for a cutout or move, measure the range in place:
  • Width at the widest point (often the cooktop edge)
  • Depth including the door and handle
  • Height from floor to cooktop, with leveling legs set
• Allow clearance for airflow; the oven vent is under the left side of the control panel, so keeping that area unobstructed helps performance

Quick reference: what you can expect

Measurement	What to expect	What changes it
Width	30-inch class	Trim/cooktop lip tolerances
Height	Adjustable	Leveling legs, flooring
Depth	Varies	Door handle, rear spacing

Why it matters

Correct sizing prevents installation problems (clearance, anti-tip bracket alignment, and door swing space) and helps you choose compatible accessories like racks and pans.

Last updated: February 2026

On the Kenmore Elite electric range model 79097473800, error code F90 (often grouped with F9, F91 to F95) points to a problem in the oven door lock system. It commonly shows up during or after Self-Clean when the control does not sense the door locking or unlocking correctly; resetting power can sometimes clear it.

What to do first (safe, quick checks)

• Press STOP/CLEAR to stop the beeping and clear the display.
• Let the oven cool completely if the code appeared during Self-Clean.
• Turn off power at the breaker for 30 seconds, then restore power.
• Try a normal Bake cycle (not Self-Clean) to see if the code returns.
• If the door is stuck locked, avoid forcing it; wait for the lock to cool and retry after the reset.

Parts that commonly cause F90 symptoms

If the code returns, the issue is usually in the lock motor, switches, or the sensing circuit.

Symptom you notice	Most likely area	Example part on this model page
Door will not lock for Self-Clean	Lock motor or lock switch	Oven door lock motor and switch assembly 5304528973
Door locks but code returns	Lock switch feedback or wiring	Door lock assembly circuit and harness connections
Oven temperature seems erratic and faults appear	Temperature sensing can contribute to control faults	Oven temperature sensor 316490000

Why it matters

The control uses the door lock feedback as a safety check, especially for Self-Clean. If the lock does not move fully or the switch signal is wrong, the range may disable Self-Clean and sometimes interrupt baking to prevent unsafe operation.

Where to find model-specific steps

For keypad sequences, Self-Clean behavior, and “before you call” troubleshooting for F-code beeping, use the owner's manual.

Last updated: February 2026

Your Kenmore Elite electric range model number 79097473800 is printed on the appliance’s model and serial tag. On this style of freestanding range, you’ll typically find that tag around the oven door opening (door jamb) or in the storage or warming drawer area. For diagrams and exact label locations, check the owner's manual.

Most common places to check

• Open the oven door and look along the left or right door jamb (the frame around the opening)
• Pull out the warming drawer or storage drawer and look on the frame behind it
• Check the lower front frame behind the drawer front
• If needed, look on the back panel of the range (near the power cord area)

Quick tips so you spot it fast

• Look for a sticker or metal plate labeled “Model” and “Serial”
• Wipe grease or dust off the tag; the print can be faint
• Take a photo of the tag so you can zoom in and read it clearly

Why it matters

We use the full model number (including all digits) to match the correct Kenmore parts and diagrams for your range, such as the frigidaire range bake element 316505500 or the frigidaire range oven temperature sensor 316490000. Even one missing digit can pull up the wrong parts list.

What the model number looks like

What you’ll see	Example	What it’s used for
Model number	79097473800	Identifies the exact range configuration
Serial number	(varies)	Identifies production run and date

Last updated: February 2026

If your Kenmore Elite electric range model 79097473800 is not working, the most common causes are a power problem (plug, breaker, outage) or an electronic control fault that needs to be cleared by pressing STOP. If the display shows an “F” code or “- -”, the control may be in a fault or lockout state.

Quick checks to do first (no tools)

• Confirm the range cord is fully plugged into the outlet.
• Check your home circuit breaker(s) for a tripped breaker.
• Verify it is not a home power outage (check other lights/outlets).
• If the control is beeping or showing a fault, press STOP to clear the display.
• If the cooktop shows “- -”, unlock the cooktop by touching CLOCK for 3 seconds (or wait for Self-Clean to finish).
• Make sure you are using the correct knob/keypad for the surface element you want.

What the display messages usually mean

What you see	What it points to	What to do
No display, nothing works	No power to the appliance	Check plug, breakers, and outage
“F” code (any “F” message)	Control detected a fault condition	Press STOP; if it returns, plan a diagnosis
“- -” on ESEC	Lockout condition (cooktop lockout or Self-Clean)	Finish Self-Clean or hold CLOCK 3 seconds

If the oven heats poorly or not at all

Power can be fine but the oven still will not heat correctly if a heating circuit component fails.

• If baking is weak or uneven, inspect the bake element for damage; consider replacing the frigidaire range bake element 316505500.
• If broil does not heat, inspect the broil element; consider the frigidaire range broil element 316203301.
• If temperatures seem inaccurate (burning or undercooking), the oven temperature sensor can be the cause; check the frigidaire range oven temperature sensor 316490000.

Why it matters

An electric range that is completely dead is usually a power supply issue, while error codes and lockout messages point to control logic or a safety mode. Separating “no power” from “won’t heat” helps you choose the right next step and the right part.

For model-specific keypad sequences, error-code behavior, and the “Before you call” checklist, follow the owner's manual.

Last updated: February 2026

To reset the control settings on your Kenmore Elite electric range model 79097473800, press and hold the recipe keypad for about 6 seconds until you hear a single beep, then press the same keypad once. This clears stored recipes and resets most user adjustments back to factory defaults (including clock format and temperature display). See the owner's manual for the exact keypad name and display prompts.

What this reset does (and does not do)

This procedure is a control reset for user-programmed settings; it is not a repair for failed heating parts.

• Clears any stored recipe/program memory
• Resets common preferences (12/24-hour clock, silent mode, Fahrenheit/Celsius)
• Resets any oven temperature offset you previously adjusted
• Does not fix a no-heat condition caused by a failed element, sensor, or control board
• Does not bypass the door lock or safety features

Step-by-step: factory-default reset

1. Make sure the oven is in an idle state (not baking, broiling, or self-cleaning).
2. Press and hold the recipe keypad until the first single beep sounds (about 6 seconds).
3. After the beep, press the same keypad once to confirm.

If the display is beeping with an error

If the electronic control is showing a fault code and beeping, press STOP to clear the display and stop the beeping, then reprogram the oven settings.

Quick checks if you are resetting because the oven is acting “weird”

These checks solve the most common post-reset complaints.

• Clock is wrong after a power outage: reset the clock and reselect your bake settings
• Oven will not start: confirm you are pressing START after setting a function
• Door shows locked: toggle the lockout feature (press and hold the lockout pad for about 3 seconds)
• Temperature seems off: run a simple bake test after the reset; if it still drifts, check the sensor

Parts that commonly relate to “won’t heat” symptoms

If the oven still will not heat after a reset, these model-compatible parts are common suspects:

Symptom	Common part to check	Example part on this model page
Underheats, overheats, temp swings	Oven temperature sensor	Oven temperature sensor 316490000
No bake heat	Bake element	Bake element 316505500
No broil heat	Broil element	Broil element 316203301

Why it matters

A factory-default reset is the fastest way to eliminate incorrect settings after a power interruption or accidental programming. If the problem continues after the reset, it usually points to a heating circuit issue (sensor, element, wiring, or control).

Last updated: February 2026
