How do I reset my Kenmore dishwasher control board?
To reset the controls on your Kenmore dishwasher model 66513402N412, cancel the current cycle by pressing and holding START/RESUME for 3 seconds, then close the door so the unit can drain and clear the selection. This restores normal control operation in most reset situations; see the 66513402N412 owner's manual for your exact button labels.
- Open the door slightly to stop the cycle; wait for spraying to stop.
- Press and hold START/RESUME for 3 seconds to CANCEL/DRAIN.
- Close the door within 3 seconds so the drain cycle can run.
- Wait for draining to finish (typically about 2 minutes).
- Select a new cycle and press START/RESUME.
A “reset” often fails because the dishwasher is still locked out or not latching.
- Control Lock is on: Press and hold SANI RINSE for 3 seconds to toggle Control Lock off.
- Door not fully latched: Make sure the door closes firmly; a weak latch can prevent starting.
- Power glitch: Turn off the breaker for 1 minute, then restore power.
- Standing water remains: Check for a drain restriction (air gap, disposer inlet plug, kinked hose).
| Symptom | What it usually means | What to do next |
|---|---|---|
| Buttons do nothing, lock light on | Control Lock enabled | Hold SANI RINSE 3 seconds |
| “Drain” shows but no draining | Door open or drain path blocked | Close door; check drain hose routing |
| Won’t start, door feels loose | Latch not engaging | Inspect/replace dishwasher door latch WPW10653840 |
Resetting by using CANCEL/DRAIN clears a stuck cycle and forces the dishwasher to safely stop spraying and drain. That prevents water from sitting in the sump and helps you restart with the correct cycle and options.
Last updated: January 2026
What does red lock mean on a dishwasher?
On Kenmore dishwasher model 66513402N412, a red lock (padlock) light means the Control Lock option is turned on. When Control Lock is lit, the buttons are disabled and the dishwasher will not start until you unlock the controls. See the 66513402N412 owner's manual for the exact button sequence.
When the Lock indicator is on:
- All control buttons are disabled.
- The dishwasher cannot start.
- The door can still be opened and closed.
- Pressing a button while locked makes the light flash (commonly 3 flashes).
Use the Control Lock instructions for model 66513402N412:
- Press and hold the Control Lock function (on this model it is activated through a specific option key) for about 3 seconds.
- Confirm the Lock indicator turns off.
- Press START/RESUME to begin the cycle.
Work through these common no-start checks:
- Close the door firmly until it latches.
- If START/RESUME is blinking, close the door and press START/RESUME (some cycles require pressing START again after opening the door).
- Select a wash cycle and any options, then press START/RESUME.
- Check the house breaker or fuse for the dishwasher circuit.
| What you see | What it means | What to do |
|---|---|---|
| Red lock/padlock light on | Control Lock enabled | Follow the unlock steps in the manual |
| Buttons do nothing | Controls are locked | Unlock, then press START/RESUME |
| START/RESUME blinking | Door not latched or door opened | Close door, press START/RESUME |
Control Lock prevents accidental cycle changes and unintended starts between cycles. If it is enabled, the dishwasher looks “powered” but will not respond to normal button presses.
If you also have an error code or unusual light pattern, use our Kenmore 665 model dishwasher error codes reference to narrow the problem quickly.
Last updated: January 2026
What is the service code F2E2?
On the Kenmore 66513402N412 dishwasher, service code F2E2 points to a user interface (keypad) problem, meaning the control is seeing a stuck key, an unresponsive key, or a communication issue between the keypad and the main control.
- Press Cancel/Drain and then power the dishwasher off for 1 minute (breaker or unplug), then restart.
- Wipe the control panel dry; moisture can make keys act “stuck.”
- Press each key one at a time; a key that feels jammed or does not “click” is a strong clue.
- If the code returns immediately, stop cycling power and move to inspection steps below.
- If the dishwasher also will not start, confirm the door is fully closed and latched.
| What’s happening | What it usually indicates | Typical fix |
|---|---|---|
| Code appears as soon as you power up | Stuck key or shorted keypad circuit | Inspect keypad, replace UI if needed |
| Code appears after pressing buttons | One key not registering correctly | Clean panel, check ribbon/connector |
| Intermittent code | Moisture, loose connection, or failing UI | Reseat connections, replace UI if recurring |
On this model, F2E2 is most often tied to the console user interface, but a failing main control can also misread keypad signals.
- If you suspect the latch is not engaging (unit thinks the door is open), check the dishwasher door latch WPW10653840.
A stuck or shorted keypad can prevent normal cycle selection, cause random beeping, or stop the dishwasher mid-cycle. Addressing it early helps avoid repeated shutdowns and protects the electronic control from ongoing input faults.
For model-specific diagnostics and any built-in test steps, follow the 66513402N412 owner's manual. For code definitions across Kenmore electronic-control dishwashers, use our Kenmore 665 model dishwasher error codes reference.
Last updated: January 2026
