Kenmore 10679857990 refrigerator Parts

Your Kenmore refrigerator’s model number is printed on the model and serial number label inside the fresh food (refrigerator) compartment. For Kenmore model 10679857990, the label is typically on an inside wall; confirm the exact label location and format in the 10679857990 owner's manual.

Where to look for the model number label

Check these common spots first (use a flashlight and look for a sticker or metal plate):

• Inside the refrigerator compartment on a side wall (most common)
• Inside the refrigerator compartment near the crisper drawer area
• Inside the freezer compartment on an interior wall
• Behind the lower kickplate or toe grille (less common)

What to write down (and why)

Record the full model number and serial number exactly as shown. This helps us match the correct Kenmore refrigerator parts and diagrams.

• Model number (example format often starts with 106. on many Kenmore units)
• Serial number
• Purchase date (helpful for warranty and service history)

Quick checklist

• Copy every digit and letter; do not skip dashes or suffixes
• Take a clear photo of the label for reference
• Use the model number when ordering parts like an ice maker, thermostat, or door hinge

Model number vs. serial number

Item	What it identifies	Used for
Model number	The exact refrigerator design and parts fit	Parts lookup, diagrams, compatible replacements
Serial number	Your specific unit’s production run	Service history, manufacturing details

Why it matters

Kenmore refrigerators can look similar across multiple model series, but parts like the ice maker assembly, water inlet valve, and door gasket can vary by model. Using the exact model number prevents ordering the wrong part and saves repair time.

Last updated: February 2026

For Kenmore refrigerators like model 10679857990, the model number is the key to getting the right parts and instructions. We use the full model number (not just “106”) to match the exact design version, including door style, controls, and component revisions; confirm it on the model and serial label inside the fresh food compartment and in the 10679857990 owner's manual.

Where to find the model number on this refrigerator

On Kenmore 10679857990, the manual directs you to the model and serial number label on the inside wall of the refrigerator compartment.

Check these common spots:

• Inside the fresh food section on a side wall
• Near the crisper area or lower liner wall
• On a sticker that also lists the serial number
• In the paperwork packet that came with the refrigerator

How Kenmore model numbers are structured (what the digits mean)

Kenmore model numbers typically include a prefix that identifies the manufacturing source, followed by digits that identify the product platform and variation.

• Prefix (often the first 3 digits): identifies who built it for Kenmore
• Remaining digits: identify the base design and the specific variation (features, color, revisions)

Quick example for this model

What you see	What it tells us	Why it matters
106	Manufacturer prefix used on many Kenmore refrigerators	Helps narrow the parts family
79857990	Model-specific identifier	Ensures the exact part fit

Why it matters when ordering parts or using troubleshooting steps

Using the complete model number prevents common mismatches, especially for parts that look similar but mount differently.

Most often, the full model number matters when you are replacing:

• Ice maker components (for example, the ice maker assembly - refrigerator ice maker by whirlpool 4317943)
• Water system parts (for example, the refrigerator inlet valve WP2315576)
• Temperature control parts (for example, the refrigerator thermostat WP627985)
• Door hardware and handles

Tips to avoid mix-ups

• Copy the model number exactly as printed (all digits, no spaces)
• Record the serial number too; it can help confirm production variation
• When searching parts, use 10679857990 (not just “106”)

Why it matters: Kenmore used the same prefix across many refrigerator designs; the full model number is what locks in the correct parts list and repair instructions.

Last updated: February 2026

Most Kenmore refrigerators average 10 to 15 years of service life. For a Kenmore top-mount like model 10679857990, lifespan depends most on basic care (clean airflow, tight door seals, correct temperatures) and fixing small problems early; see the owner's manual for model-specific care and operating guidance.

Typical lifespan ranges (what we see most often)

• 10 to 15 years: common for many household refrigerators
• 15 to 20 years: achievable with consistent maintenance and timely part replacement
• Under 10 years: usually tied to poor airflow (dirty condenser area), door seal leaks, or unresolved cooling/defrost issues

Refrigerator type	Typical lifespan	What most affects it
Top-mount (top freezer)	10 to 15 years	Coil/condenser airflow, door seal condition, defrost performance
Side-by-side	10 to 15 years	Ice and water system upkeep, airflow, fan performance
French door	10 to 15 years	Ice maker and dispenser use, door alignment, gasket sealing

Maintenance that extends life

• Keep the condenser area clean so the compressor does not run hot for long periods.
• Confirm the doors close fully and the gaskets seal all the way around.
• Set and maintain safe temps: 0°F in the freezer and 37°F to 40°F in the fresh food section.
• Avoid overpacking; blocked vents reduce airflow and cause longer run times.
• Address frost buildup or warm temps quickly (often tied to the defrost system or airflow).

When repairs make sense (and common parts involved)

If the refrigerator is cooling poorly but the cabinet and doors are in good shape, replacing a failed component often restores normal operation.

Symptom	Common cause	Example part for this model
No ice or weak ice production	Ice maker issue or water supply/valve issue	Ice maker assembly - refrigerator ice maker by whirlpool 4317943
Warm fridge, freezer OK or noisy airflow	Evaporator fan airflow problem	Refrigerator evaporator fan blade WP2163777
Water not filling ice maker (if equipped)	Water inlet valve not opening fully	Refrigerator inlet valve WP2315576

Why it matters

A refrigerator that runs longer than normal uses more energy and puts extra wear on the sealed system (compressor and refrigerant tubing). Simple upkeep and quick fixes help your Kenmore 10679857990 reach the upper end of its expected lifespan.

Last updated: February 2026

We find the cubic-foot capacity for your Kenmore refrigerator model 10679857990 by checking the model and serial label inside the fresh food compartment and matching it to the specifications listed in the owner's manual. That label-based method is the most accurate for your exact configuration.

Where to find the capacity information

Look in these common places on Kenmore top-mount refrigerators:

• Model and serial number label on an inside wall of the refrigerator compartment
• Specifications section in the owner's manual
• Sometimes on a rating plate near the crisper area or side wall (varies by build)

Quick way to estimate cubic feet (when you need a ballpark)

If you need an estimate before you locate the label, most Kenmore top-mount refrigerators in the 106 series commonly fall in a mid-size range.

Refrigerator type	Typical capacity range	Best use
Top-mount (top freezer)	14 to 22 cu. ft.	General household use
Compact top-mount	10 to 14 cu. ft.	Small kitchens, garages
Large top-mount	22 to 25 cu. ft.	Higher storage needs

Why it matters

Capacity affects how we match parts and accessories and how you set expectations for storage and airflow. For example, shelf and bin layouts can vary by capacity and interior design, even within the Kenmore 106 model family.

Related checks while you are locating the label

Since you are already looking inside the cabinet, we recommend these quick checks:

• Confirm the full model number is exactly 10679857990
• Write down the serial number for parts matching and service records
• Verify door bins and shelves are seated correctly for proper airflow
• Keep about 1/2 inch clearance at the sides and top for ventilation (common installation guidance)

Last updated: February 2026

Common problems on Kenmore refrigerators like model 10679857990 include warm temperatures (cooling loss), ice maker not making ice, water leaks, and noisy operation. Most fixes start with basic care steps (cleaning, airflow checks) and then move to diagnosing fans, the defrost system, and water supply components using the owner's manual.

Most common symptoms and what usually causes them

• Not cooling or weak cooling: dirty condenser coils, blocked air vents, failed evaporator fan, or a defrost problem.
• Freezer cold but fridge warm: restricted airflow, frost buildup on the evaporator, or an evaporator fan issue.
• Ice maker not working: water supply issue, frozen fill tube, or a failed ice maker.
• Water leaking: clogged defrost drain, cracked water line, or a leaking inlet valve.
• Clicking or humming noises: condenser fan motor issues, compressor start device problems, or ice maker cycling.

Quick checks we recommend first (10 to 20 minutes)

1. Set temperatures to typical targets: 0°F freezer, 37°F fresh food.
2. Make sure vents are not blocked by food packages.
3. Clean condenser coils and the area around the condenser fan.
4. Check door closing and gasket sealing all the way around.
5. If you have an ice maker, confirm the shutoff arm is down and the water supply valve is fully open.

Parts that commonly solve these problems on this model

If symptoms point to a specific system, these are common replacement parts for model 10679857990:

Symptom	Likely system	Example part on this model
Ice maker not making ice	Ice maker assembly	Ice maker assembly - refrigerator ice maker by whirlpool 4317943
Water leaking at back/bottom	Water supply	Refrigerator inlet valve WP2315576
Frost buildup, warm fridge	Defrost protection	Refrigerator defrost bi-metal WP4387503
Warm temps, poor airflow	Condenser fan	Condenser motor W10822259

Why it matters

Cooling, ice, and leak complaints often share the same root causes: restricted airflow, poor heat removal at the condenser, or inconsistent water flow. Catching these early helps prevent food spoilage, ice clumping, and water damage.

For model-specific care, cleaning, and troubleshooting steps (including sections like “Refrigerator care” and “Troubleshooting”), follow the owner's manual.

Last updated: February 2026
