Frigidaire FGGF3054MFA gas range Parts

Yes. We look up Frigidaire parts by model number so you get parts that fit your exact appliance configuration. For your Frigidaire gas range model FGGF3054MFA, use the model and serial information from the ID plate, then match parts by description and part ID.

Where to find the model number on FGGF3054MFA

Your range’s identification plate is on the right-hand surface of the oven front frame. Open the storage drawer, warmer drawer, or broiler drawer (depending on your configuration) to access it. See the FGGF3054MFA owner's manual.

What to write down before ordering

• Model number (example: FGGF3054MFA)
• Serial number
• Lot number or letter (from the identification plate)
• Fuel type and pressure rating listed on the plate (helps ensure correct gas components)

How we recommend searching parts by model number

Use the model number first, then confirm the part by name and part ID.

• Start with the model number to filter to compatible diagrams
• Identify the system you’re repairing (surface burners, oven bake, broil, controls)
• Match the part by part name and part ID
• Compare symptoms to the “Before You Call” section in the manual for quick checks

Example parts you can match to common symptoms

Symptom	Common part to check	Example part ID on this model page
Oven won’t heat (bake)	Oven burner igniter	Tappan range oven burner igniter 316489403
Oven temperature seems off	Oven temperature sensor	Frigidaire range oven temperature sensor 316490000
Oven light out	40-watt appliance bulb	Appliance light bulb, 40-watt 316538904

Why it matters

Frigidaire ranges can have multiple versions that look similar but use different igniters, sensors, burner caps, or control parts. Using the exact model number from the ID plate helps prevent ordering a part that does not fit or does not match the gas setup.

Last updated: February 2026

On the Frigidaire FGGF3054MFA gas range, the most commonly replaced stove parts are ignition-related parts (for burners and the oven), the oven temperature sensor, and the oven light bulb. These parts wear with normal use and are often involved when the range will not heat, will not ignite, or has an oven light that will not work.

Most common replacement parts (and what they fix)

• Oven igniter: common when bake or broil will not ignite or takes a long time to light.
• Surface burner igniter and orifice holder: common when a cooktop burner clicks but will not light.
• Oven temperature sensor: common when oven temperature is inaccurate or swings too hot or too cool.
• Oven light bulb (40-watt appliance bulb): common when the interior light is out (the manual specifies a 40-watt appliance bulb). See the FGGF3054MFA owner's manual.
• Spark module: common when multiple burners stop sparking or sparking becomes erratic.

Parts we see replaced often for this model

Symptom	Likely part to check/replace	Example part for FGGF3054MFA
Oven will not ignite (bake)	Oven burner igniter	Tappan range oven burner igniter 316489403
Oven temperature seems wrong	Oven temperature sensor	Frigidaire range oven temperature sensor 316490000
Oven light does not work	40-watt appliance bulb	Appliance light bulb, 40-watt 316538904
Burners do not spark correctly	Spark module	Range spark module 5304508269

Quick checks before you order parts

• Confirm the symptom: bake, broil, convection, or surface burner issue.
• For surface burners, remove the cap and clean the ignition port; a partially blocked port can cause ignition problems (the manual describes clearing it with a small wire or paper clip). See the FGGF3054MFA owner's manual.
• Make sure burner caps are seated correctly after cleaning.
• If the oven light is out, replace only with a 40-watt appliance bulb and reinstall the glass shield.
• If ignition problems affect multiple burners at once, prioritize checking the spark module and wiring connections.

Why it matters

Replacing the right part first saves time and prevents repeat failures. On gas ranges like the Frigidaire FGGF3054MFA, ignition and sensing components (igniters, spark module, temperature sensor) directly control lighting and temperature accuracy, so small failures can look like bigger oven or burner problems.

Last updated: February 2026

On your Frigidaire FGGF3054MFA gas range, the model and serial identification plate (used to look up the correct replacement part numbers) is located on the right-hand surface of the oven front frame; you access it by opening the storage, warmer, or broiler drawer. See the FGGF3054MFA owner’s manual for the exact label location illustration.

What to look for on the label

Use the information on the identification plate when ordering parts or matching diagrams.

• Model number: FGGF3054MFA
• Serial number
• Lot number or letter
• Burner ratings (BTU)
• Fuel type (natural gas or LP) and gas pressure setting

Quick steps to find it

1. Turn the oven off and let it cool.
2. Pull out and open the bottom drawer (storage, warmer, or broiler drawer depending on your configuration).
3. Look at the right-hand surface of the oven front frame for the identification plate.
4. Write down the model and serial numbers exactly as shown.

Why we ask for model and serial numbers

Ranges often use different igniters, sensors, and burner parts across production runs. Using the identification plate details helps us match the correct Frigidaire parts for your exact build.

You have	We use it for
Model number	Selecting the correct parts list for FGGF3054MFA
Serial number	Matching production series changes
Lot number/letter	Confirming the right revision of parts

If you are trying to match a specific replacement part

Once you have the model and serial, compare the part name and ID to your symptom. For example, no-heat or slow-ignition oven issues commonly point to an igniter such as the tappan range oven burner igniter 316489403.

Last updated: February 2026

On the Frigidaire gas range model FGGF3054MFA, the model and serial number identification plate is on the right-hand surface of the oven front frame. You can see it by opening the storage drawer, warmer drawer, or broiler drawer (depending on your configuration) as shown in the FGGF3054MFA installation guide.

Quick steps to locate the tag

• Turn the oven light on and use a flashlight for easier viewing.
• Open the bottom drawer (storage, warmer, or broiler drawer).
• Look at the right side of the oven front frame (the front frame area just inside the opening).
• Write down the model number, serial number, and any lot number/letter listed.
• Keep the information with your paperwork or note it in the FGGF3054MFA owner's manual.

What the identification plate tells you (and why it matters)

The identification plate is more than a label; it helps us match the correct Frigidaire parts and settings for your exact gas range.

On the plate	Why we use it
Model number	Ensures diagrams and parts lists match your exact range
Serial number	Helps confirm production details for service and parts lookup
Lot number/letter	Helps narrow down version changes within the same model
Fuel and pressure info	Confirms how the range was adjusted when it left the factory

When you will need the model number

• Ordering replacement parts such as an igniter, temperature sensor, or control board
• Checking burner ratings and fuel type information
• Troubleshooting heating issues (bake or broil) and verifying correct adjustments

Last updated: February 2026

If your Frigidaire FGGF3054MFA gas range smells like gas, treat it as a safety issue first: follow the “What to do if you smell gas” steps in the FGGF3054MFA owner’s manual and stop using the range until the source is identified. A gas odor is commonly caused by a loose connection, a burner that is not lighting cleanly, or a problem in the oven ignition system.

What to do right now (safety first)

• Do not try to light any appliance.
• Do not touch electrical switches.
• Use a neighbor’s phone to call your gas supplier and follow their instructions.
• If you cannot reach your gas supplier, call the fire department.
• Keep the area clear until the issue is resolved.

Common causes on a gas range

• Surface burner not lighting fully: clogged burner ports, wet burner parts after cleaning, or a misaligned burner cap.
• Weak or failed oven igniter: the igniter glows but does not open the gas valve quickly, letting gas linger before ignition.
• Gas valve or regulator issue: improper gas flow or a valve that is not operating correctly.
• Installation or conversion mismatch: the range is factory set for natural gas; LP conversion must be done correctly.

Quick checks you can do (after the area is safe)

• Confirm all burner knobs are fully in the OFF position.
• Remove and reseat burner caps and heads; make sure they sit flat and dry.
• Look for delayed ignition in bake or broil (a “whoosh” after a pause points to ignition trouble).
• If the oven has delayed ignition, plan to replace the igniter, such as the tappan range oven burner igniter 316489403 (model-compatible part listing).

Symptom-to-likely-cause guide

What you notice	Most likely cause	What we recommend
Smell only when a surface burner is on	Burner cap/head alignment or clogged ports	Clean and reseat caps/heads; verify steady blue flame
Smell when oven starts, then it lights late	Weak oven igniter	Replace igniter; verify prompt ignition
Smell even when everything is OFF	Gas supply connection leak or valve issue	Stop using range; have gas supplier/tech check

Why it matters

Unburned gas can accumulate if ignition is delayed or a connection leaks. Addressing burner alignment, ignition performance, and gas connections protects your home and helps your Frigidaire range heat consistently.

Last updated: February 2026
