Frigidaire FFSS2625TS3 side-by-side refrigerator Parts

The Frigidaire FFSS2625TS3 is a 36-inch class side-by-side refrigerator with about 25.5 cu. ft. of total capacity. For exact outside dimensions (height, width, depth with handles), use the specifications listed in the FFSS2625TS3 owner's manual.

What “big” usually means (and what to check)

When customers ask how big a refrigerator is, we typically look at these measurements:

• Width: the cabinet width and the width with doors/handles
• Height: to the top of the case or top hinge cover
• Depth: cabinet-only vs. depth with doors/handles
• Door swing clearance: space needed to fully open doors and pull out drawers
• Capacity: total cubic feet (fresh food plus freezer)

Installation space and clearance guidelines

For the FFSS2625TS3, plan for airflow and hookup space around the cabinet. The installation guidance calls for:

• Sides and top clearance: 3/8 inch
• Rear clearance: 1 inch
• Nearby grounded outlet (avoid extension cords/adapters)
• Water supply access if you use the ice and water dispenser

Quick clearance table

Location around refrigerator	Recommended clearance
Sides	3/8 in.
Top	3/8 in.
Back	1 in.

Why it matters

Getting the size right prevents delivery surprises, helps the doors open fully, and supports proper air circulation so the compressor and evaporator fan can cool efficiently. It also ensures you have room for the water line if you use the dispenser and ice maker.

Last updated: February 2026

For the Frigidaire FFSS2625TS3 side-by-side refrigerator, the clearest signs of a failing refrigerator are persistent warm temperatures (including a ‘HI’ temperature alarm), excessive run time, unusual noises, leaks, or heavy frost and ice buildup. These symptoms usually point to airflow, sealing, or cooling-system problems that need attention.

Common warning signs to watch for

• Food spoils faster than normal or temperatures will not hold steady.
• The control shows ‘HI’ and the alarm sounds (high temp condition).
• The refrigerator runs “too much” or seems to never cycle off.
• New or louder noises from the evaporator fan area or compressor area.
• Water leaking or puddles forming around the unit.
• Frost or ice buildup that keeps coming back after defrosting.
• Doors do not seal well, or you see condensation around the door edges.

Quick checks we recommend first (before replacing parts)

1. Confirm temperatures and alarms: If the freezer is above 26°F or the refrigerator is above 55°F, the unit can trigger a high temp alarm and display ‘HI’. Review alarm behavior in the FFSS2625TS3 owner’s manual.
2. Adjust set points correctly: Make small changes (1 degree at a time) and allow about 24 hours to stabilize.
3. Inspect door sealing: Dirty, cracked, or poorly fitted gaskets can cause long run times and warm temps.
4. Clean the condenser area: A dirty condenser commonly causes poor cooling and excessive run time.

What the symptom often points to

Symptom	Common cause	What to do next
‘HI’ alarm, warm compartments	Doors left open, airflow issue, dirty condenser	Check door closure, clean condenser, verify vents are not blocked
Runs too long	Hot room, frequent door openings, gasket leak	Reduce door openings, inspect/clean gaskets
Frost buildup	Air leak at door, airflow restriction	Check gaskets and door alignment
Noisy operation	Fan issue, vibration, ice contact	Check for ice obstruction; inspect fan area

Why it matters

Catching these signs early helps prevent food loss and reduces strain on key components like the compressor and evaporator fan. A simple fix (cleaning, sealing, or a control adjustment) often restores normal cooling.

Last updated: February 2026

The model number for your Frigidaire side-by-side refrigerator is printed on the appliance’s rating label. On FFSS2625TS3 units, that label is typically inside the fresh food (refrigerator) compartment on a side wall or near the top, where it’s easy to read with the door open.

Where to look first

Check these common label locations on a Frigidaire side-by-side refrigerator:

• Inside the refrigerator compartment on the left or right interior wall
• Near the top of the refrigerator compartment, behind the door seal area
• On the ceiling area of the fresh food compartment near the control panel
• On the hinge-side door frame area (open the door and look along the frame)

For diagrams and model identification details, use the FFSS2625TS3 owner's manual.

What the label looks like and what to copy

The rating label usually includes several identifiers. Copy the model number exactly as shown.

Label item	What it’s used for	Example format
Model number	Matching parts and manuals	FFSS2625TS3
Serial number	Production info, service history	Letters and numbers
Electrical ratings	Verifying power requirements	Volts/amps

Why it matters

Using the exact model number ensures you get the correct refrigerator parts (like a water filter, ice maker, door gasket, or electronic control) that fit your specific FFSS2625TS3 configuration.

Last updated: March 2026
