Kenmore 41743052200 washer Parts

For Kenmore washer model 41743052200, the model and serial number are printed on the identification plate at the top, inside of the door opening. Use that exact model number when ordering parts or looking up troubleshooting steps in the 41743052200 owner's manual.

On this front-load Kenmore 417-series washer, open the door and check the cabinet frame area at the top of the door opening. The identification plate lists both the model number and serial number.

• Open the washer door fully
• Look along the top edge of the door opening (cabinet frame)
• Find the identification plate or sticker
• Write down the model number and serial number exactly as shown
• Keep the information with your purchase records for future reference

Having the correct model number prevents ordering the wrong door lock, drain pump, or hose, and it also helps match the right operating instructions for your exact control panel and features.

• Use the full model number, not just the “417.” prefix
• Copy every digit in order; one wrong digit can point to a different parts list
• If the label is worn, take a clear photo and zoom in to confirm characters
• When shopping for parts, match by model first, then confirm by part name and symptoms

Kenmore washers share similar styling across multiple series, but internal components (like the door lock and drain system) can vary by model. Using the identification plate information keeps repairs accurate and reduces returns.

Last updated: February 2026

A Kenmore washer typically lasts 10 to 15 years. For the Kenmore 41743052200 front-load washer, consistent care (proper loading, routine cleaning, and fixing small leaks early) helps you reach the longer end of that range.

• Overloading or washing heavy items too often (stresses bearings, shocks, and the drive system)
• Standing water or slow draining (can overwork the drain pump and leave odors)
• Door seal care (front-loaders last longer when the boot is kept clean and dry)
• Water quality (hard water can increase buildup in valves and dispenser paths)
• Vibration and out-of-level setup (shortens life of suspension and tub components)

Use the care and cleaning steps in the 41743052200 owner's manual as your baseline. These habits make the biggest difference:

• Wipe the door boot and glass dry after the last load of the day
• Leave the door slightly open between loads to reduce mildew
• Run a monthly cleaning cycle (or hot wash) with an approved washer cleaner
• Use HE detergent and avoid overdosing
• Check pockets and remove coins, screws, and debris before washing

If the door won’t secure, the door catch 131763256 is one of the model-specific parts that can be involved in door-closing and lock engagement problems.

Knowing the typical 10 to 15 year lifespan helps you decide whether to repair or replace. If your 41743052200 is near that age and showing multiple symptoms (leaks plus noise plus draining issues), targeted repairs can still be worthwhile, but you will want to prioritize safety and reliability.

Last updated: February 2026

On the Kenmore 41743052200 washer, an F5 code points to a door lock or door switch problem. The washer is not sensing the door as safely locked, so it stops to prevent the drum from tumbling or spinning with the door unsecured.

• Press Pause/Cancel, wait 30 seconds, then restart the cycle.
• Open and firmly close the door; make sure clothing is not caught in the door opening.
• Check the door strike area for detergent buildup; wipe it clean and try again.
• Unplug the washer for 2 minutes (this resets the control), then plug it back in.
• If the door will not latch or you do not hear a solid “click,” focus on the latch/lock parts.

Most F5 situations come down to one of these:

If you need the replacement part for the latch/lock, use the model-matched door catch 131763256.

A front-load washer relies on the door lock circuit as a safety interlock. If the control cannot confirm the door is locked, it will stop the cycle to prevent leaks and reduce the risk of injury from a moving drum.

For model-specific operating and safety guidance (including safe steps like disconnecting power before maintenance), follow the 41743052200 owner's manual.

Last updated: February 2026

To hard reset your Kenmore washer model 41743052200, we recommend a simple power reset first: unplug the washer (or switch off the breaker) for 1 minute, then restore power and start a cycle. This clears minor control glitches and cycle interruptions.

• Push in the cycle selector knob to stop the washer.
• Unplug the power cord from the outlet (or turn the breaker OFF).
• Wait 60 seconds.
• Restore power.
• Close the door fully, then pull out the cycle selector knob to start.
• If the door stays locked, wait 1 to 2 minutes after stopping a spin for the lock to release.

For model-specific operating details and control behavior, use the 41743052200 owner's manual.

A “reset” will not fix a condition that is actively preventing operation. On this model, the most common start blockers are power, door lock, and control position.

• Confirm the plug is tight in the outlet.
• Check the house breaker or fuse (reset breaker or replace fuse with the correct rating).
• Make sure the door is completely closed.
• Make sure the cycle selector is set correctly; turn the knob slightly clockwise, then pull it out.
• If the motor overheated, allow up to 30 minutes for it to cool and restart.

If the washer will not start and the door will not lock consistently, inspect the latch area and consider replacing the door catch 131763256 if it is worn or damaged.

A hard reset is the fastest way to clear temporary electronic “hang-ups,” but checking the door lock, power supply, and selector knob position prevents repeat no-start issues and protects the control and motor.
