How big is the Kenmore Coldspot refrigerator?
For Kenmore model 10659599993 (Coldspot side-by-side), the cabinet is typically about 66 3/4 in. tall (with hinge) and about 32 1/8 in. deep (without handle); plan for extra clearance around the refrigerator so doors can open fully and air can circulate.
Dimensions and clearance to plan for
Use these common planning dimensions for this Kenmore 106 model family, then confirm your exact configuration in the 10659599993 owner's manual.
- Height with hinge: 66 3/4 in.
- Depth without handle: 32 1/8 in.
- Depth with handle: about 33 7/8 in.
- Max depth with doors open: about 49 7/8 in.
- Ventilation space: 1/2 in. on each side and at the top
- Door swing clearance near a wall: 2 in. minimum (varies by setup)
Quick fit checklist (before you buy or move it)
- Measure the opening height, width, and depth in three places (top, middle, bottom).
- Add space for the water line if you use the ice maker.
- Confirm you can remove doors or trim if the path is tight.
- Leave room to pull the unit out for condenser cleaning.
Planning guide (what to measure)
| What you are measuring | What to include | Why it matters |
|---|---|---|
| Opening depth | Cabinet depth plus handle and door swing | Prevents doors from hitting walls or cabinets |
| Side clearance | At least 1/2 in. each side | Helps airflow and cooling performance |
| Wall-side clearance | About 2 in. if next to a fixed wall | Allows full door opening |
Why it matters
Correct sizing prevents poor airflow (warm temperatures), door interference, and installation headaches, especially when you have an ice maker water line and need door swing clearance.
Last updated: January 2026
Where is the model number on a Kenmore side by side refrigerator?
On Kenmore side-by-side refrigerator model 10659599993, the model number is printed on the model and serial number label located on the inside wall of the refrigerator compartment. Use that label any time you order parts or schedule service; it lists both the model and serial number.
How to find the label quickly
- Open the fresh food (refrigerator) door, not the freezer door
- Look along the inside side wall of the refrigerator compartment
- Check near the crisper area and shelf supports where labels are commonly placed
- Use a flashlight; the label can be small and easy to miss
- Write down the full model number and serial number exactly as shown
What you should record (and why)
The label typically includes both identifiers; we recommend recording them together.
| Item on label | What it’s used for | When you’ll need it |
|---|---|---|
| Model number (10659599993) | Matching the correct parts diagrams and replacement parts | Ordering parts like an ice maker or inlet valve |
| Serial number | Identifying the production run and service details | Service calls, warranty, and technician support |
Why it matters
Kenmore model numbers can look similar across side-by-side refrigerators, but parts like the ice maker, water inlet valve, and door components can vary by model. Using the exact model number from the label helps ensure you get the right replacement the first time.
For additional model-specific details and diagrams, use the 10659599993 owner's manual.
Last updated: January 2026
What is the average lifespan of 10659599993?
The average lifespan of the Kenmore 10659599993 side-by-side refrigerator is about 14 years. Keeping the condenser area clean, maintaining good door seals, and replacing water filters on schedule helps this model reach that typical service life.
What “lifespan” means for this refrigerator
Most refrigerators fail from wear in a few key systems. Planning around them helps you avoid food loss and surprise breakdowns.
Common life-limiting areas include:
- Sealed system components (compressor, refrigerant tubing)
- Evaporator fan and airflow path
- Defrost system (heater and defrost thermostat)
- Ice maker and water delivery parts (valves, tubing)
- Door gaskets and hinges that affect temperature stability
Maintenance that extends service life
Use these habits to keep temperatures stable and reduce compressor run time.
- Vacuum condenser coils and the grille area regularly
- Keep doors closing tightly; correct sagging or gasket gaps
- Set typical temps: 37°F fresh food, 0°F freezer
- Replace the water filter on schedule (many Kenmore systems are 6 to 9 months)
- Clear ice buildup and keep vents unblocked for proper airflow
Quick “replace vs. repair” guide
| Situation | Usually worth repairing? | Why |
|---|---|---|
| Not making ice or dispensing water | Yes | Often a valve, ice maker, or tubing issue |
| Door not sealing, sweating, warm spots | Yes | Gasket or alignment restores efficiency |
| Loud fan noise, warm refrigerator section | Yes | Airflow repairs are typically straightforward |
| Sealed system or compressor problem | Depends | Higher cost, more labor |
Why it matters
A refrigerator near end-of-life often shows longer run times, temperature swings, and more frost or moisture. Addressing airflow, defrost, and door seal issues early helps protect the compressor and keeps energy use in check.
For model-specific care and schedules, follow the Kenmore 10659599993 owner's manual.
