Frigidaire FGGH3047VDB gas range Parts

Yes. For your Frigidaire gas range model FGGH3047VDB, looking up parts by the exact model number is the most reliable way to get compatible replacement parts because it matches the correct diagrams, revisions, and part substitutions for your specific range.

Where to find the model number on FGGH3047VDB

Frigidaire places the serial plate (with model and serial) on the right-hand surface of the oven front frame near the storage or warmer drawer area; an alternate location may be under the cooktop. The FGGH3047VDB owner's manual also describes where to record and reference this information.

Quick checks that usually work:

• Open the lower storage drawer and look along the lower right front frame
• Check the right-hand oven front frame (door opening area)
• If needed, look under the cooktop for an alternate label location
• Write down the model number, serial number, and lot number/letter

How to use the model number to get the right part

Once you have FGGH3047VDB exactly as shown on the serial plate, use it to narrow results to the correct parts list.

Best practices we use to avoid wrong-part orders:

• Match the model number character-for-character (letters and numbers)
• Use the model to select the correct diagram section (oven burner, door, controls, etc.)
• Compare the part name and ID to what you are replacing
• If your range has multiple versions, use the serial/lot info to confirm the right revision

Examples of model-matched parts for this range

Common need	Example part on this model page	What it affects
Oven will not heat (bake)	Bake igniter 316489403	Ignites gas at the bake burner
Oven temperature seems off	Frigidaire range oven temperature sensor 316490000	Senses oven temperature for control accuracy
Oven light is out	Frigidaire range oven light bulb 316538904	Interior oven lighting

Why it matters

Gas ranges often have similar-looking parts across models, but mounting, wiring connectors, and calibration can differ. Using the exact FGGH3047VDB model number helps us align the correct Frigidaire part ID and reduce returns and downtime.

Last updated: February 2026

On the Frigidaire gas range model FGGH3047VDB, the model and serial information is on the serial plate located behind the lower storage drawer. Pull the drawer open and look for the label on the frame area inside the opening; record both numbers for parts matching.

Where to look on FGGH3047VDB

Check these common label locations in this order:

• Open the lower storage drawer and look for the serial plate inside the drawer opening
• Look along the front frame behind the drawer (around the opening lip)
• Check the interior-side trim visible when the oven door is open (some ranges place an additional label here)
• If your range has a warmer drawer, check the front frame visible when the drawer is open

Quick steps to find it fast

1. Turn the oven off and let it cool.
2. Pull the storage drawer straight out until it stops; lift slightly and continue removing if needed.
3. Use a flashlight and read the label; write down the model number and serial number.
4. Match the model number exactly when ordering parts (for example, FGGH3047VDB).

What you should record (and why)

Item	Example	Why it matters
Model number	FGGH3047VDB	Ensures the part fits your exact Frigidaire range configuration
Serial number	(varies)	Helps identify production details when troubleshooting or confirming compatibility

Why it matters

We use the model number to match the correct Frigidaire gas range parts list, diagrams, and compatible components (such as an igniter, temperature sensor, or door seal). A single character difference can point to a different revision.

For the official location and product record page, use the FGGH3047VDB owner's manual.

Last updated: February 2026

If your Frigidaire FGGH3047VDB gas range smells like gas, treat it as a potential gas leak first: stop using the range, avoid switches or flames, and contact your gas supplier from outside the home. If the smell only happens during ignition, it often points to delayed ignition or incomplete combustion.

What to do right now (safety first)

Follow the “what to do if you smell gas” steps in the FGGH3047VDB installation guide.

• Do not try to light any appliance
• Do not touch electrical switches or use a phone inside the building
• Leave the area and call your gas supplier from a neighbor’s phone
• If you cannot reach your gas supplier, call the fire department

Common causes when the smell happens only while cooking

If the odor is brief and occurs only when a burner or the oven is trying to light, these are the most common causes:

• Burner ports are dirty or partially clogged, causing uneven flame and delayed ignition
• Igniter is weak, so gas flows longer before lighting (oven bake or broil)
• Air to gas mixture is off (more noticeable after an LP conversion or regulator issue)
• Oven burner lights late, then “whooshes” on (delayed ignition)
• Loose burner cap or misaligned burner head on the cooktop

Parts that commonly relate to gas odor symptoms

These parts are often involved when ignition is slow or inconsistent:

Symptom	Most likely area	Example part for this model
Oven smells like gas before it lights	Bake ignition circuit	Bake igniter 316489403
Broil smells like gas before it lights	Broil ignition circuit	Frigidaire range broil igniter 5304506545
Odor and poor oven temperature control	Oven sensing/control	Frigidaire range oven temperature sensor 316490000
Odor after fuel type change	Gas supply setup	Range lp conversion kit GRLP4

Quick checks we recommend (after the area is safe)

• Confirm the smell is not from a recently extinguished burner (gas knob turned on without flame)
• Look for delayed ignition: long clicking, then sudden ignition
• Check flame appearance: steady blue flames are normal; large yellow flames indicate combustion issues
• Clean burner heads and ports (cool range only)
• If the oven is the source, inspect and test the igniter circuit per the FGGH3047VDB owner’s manual

Why it matters

A persistent gas odor can signal unburned gas or a supply leak. Addressing ignition problems quickly helps prevent flare-ups, improves cooking performance, and keeps your kitchen safe.

Last updated: February 2026

On Frigidaire gas range model FGGH3047VDB, the model and serial number information is on the serial plate. Open the lower oven storage drawer and look for the plate on the oven front frame at the drawer area; copy the model number exactly as shown.

Where to look on model FGGH3047VDB

• Pull the lower storage drawer fully open.
• Look along the front frame around the drawer opening.
• Check the right-hand surface of the oven front frame at the drawer area.
• If your range has a lower panel area instead of a drawer, check that area.
• Wipe the frame with a damp cloth so the printing is readable.

What to write down from the serial plate

Record these items exactly; they are used to match Frigidaire parts and diagrams:

• Model number
• Serial number
• Lot number or letter (if listed)

Label item	What we use it for
Model number	Matches the correct parts list for igniters, sensors, racks, and controls
Serial number	Confirms the correct production version when variations exist
Lot number/letter	Helps narrow down small running changes

Why it matters

Frigidaire ranges can have multiple versions that look the same but use different components. Using the exact model number from the serial plate prevents ordering the wrong replacement part.

For the manufacturer-described label location, see the FGGH3047VDB owner’s manual and the FGGH3047VDB installation guide.

Last updated: February 2026
