Frigidaire FTF2140FS1 washer Parts

Yes. For your Frigidaire washer model FTF2140FS1, looking up parts by the full model number is the most reliable way to match the correct replacement part because it ties the search to your washer’s exact configuration and parts list.

How to find the correct model number

The model and serial tag for this washer is located at the top, inside the door opening. Use the model number exactly as shown (including all letters and numbers). See the FTF2140FS1 owner’s manual for the model tag location and basic product information.

• Open the washer door and look along the top edge of the door opening
• Write down the full model number: FTF2140FS1
• Keep the serial number too (helpful for production changes)
• Use the model number when searching diagrams and parts lists
• Match the part by name and identifier before ordering

What you can look up with the model number

Once you search by FTF2140FS1, you can quickly narrow to common repair parts such as a door lock, drain pump, water inlet valve, control board, or door boot (bellows).

What’s happening	Common part area to check	Example part for this model
Door won’t lock or cycle won’t start	Door lock system	Door lock switch 131763256
Washer won’t drain or leaves water	Drain system	Washer drain pump 137221600
No fill or slow fill	Water inlet	Water valve 134866600

Why it matters

Frigidaire often uses similar-looking parts across multiple washer series, but connectors, mounting points, and control revisions can differ. Searching by FTF2140FS1 helps prevent ordering a part that fits a different version of the washer.

Last updated: February 2026

If your Frigidaire FTF2140FS1 washer will not spin, the fastest fixes are correcting an unbalanced or too-small load, fully closing the door and dispenser drawer, and power-cycling the washer. These issues commonly stop the spin cycle even when nothing is “broken.”

Quick checks that restore spin most often

• Add 1 to 2 similar items if the load is very small; small loads can’t balance for spin.
• Rearrange the load so it’s evenly distributed in the drum.
• Confirm the washer door is fully closed and the door lock engages.
• Make sure the dispenser drawer is fully closed; opening it during operation can stop the washer.
• Unplug the washer for 5 to 10 minutes, then plug it back in and try Drain/Spin.

What to do next if it still won’t spin

Start with the simplest “no-tools” causes, then move to drain and lock issues.

1) Rule out a drain problem

A washer that cannot drain often will not spin.

Symptom	Most likely direction	What we do first
Water left in drum after cycle	Drain restriction or pump issue	Check drain hose for kinks, then inspect pump area
Hums but won’t drain	Pump jam or failing pump	Check for debris, then consider pump replacement

If you suspect the pump is not moving water, the model-specific replacement is the washer drain pump 137221600.

2) Check door lock operation

If the door does not lock, the control will typically prevent high-speed spin. If the door lock is intermittent, the model-specific part is the door lock switch 131763256.

Why it matters

Spin problems are often load-balance, door-lock, or drain related. Fixing the root cause prevents repeated wet loads, long cycle times, and extra strain on the motor and control board.

Helpful model resources

• Use the troubleshooting chart and operating tips in the FTF2140FS1 owner's manual.
• If you’re seeing an error code, match it to the symptom using Frigidaire front load washer error codes.

Last updated: February 2026

A Frigidaire washing machine typically lasts 10 to 12 years. For a Frigidaire FTF2140FS1 front-load washer, consistent cleaning, correct loading, and fixing small problems early (like draining or door-lock issues) are the biggest factors in reaching that lifespan; see the FTF2140FS1 owner's manual for routine care and operating guidance.

Typical lifespan (what to expect)

Most residential washers fall into these ranges with normal household use:

Washer type	Typical life expectancy
Front-load washer (like FTF2140FS1)	10 to 12 years
Top-load washer	11 to 14 years
Heavy use (large family, daily loads)	7 to 10 years

What shortens washer life fastest

• Overloading the drum (extra strain on the motor, tub, and shocks)
• Too much detergent (causes residue, odors, and extra rinsing stress)
• Ignoring small leaks (can damage the control board and wiring)
• Running with excessive vibration (wears suspension and tub components)
• Letting drain problems continue (overworks the drain pump)

What to do to help your FTF2140FS1 reach 10 to 12 years

• Use the correct amount of HE detergent and avoid “extra suds” loads.
• Leave the door slightly open between loads to reduce moisture and odor.
• Check pockets and wash small items in a mesh bag to protect the drain system.
• Level the washer and keep it stable to reduce shaking and shock wear.
• If the washer will not start or stops mid-cycle, check the door latch system; a failing door lock switch 131763256 can prevent normal operation.

Why it matters

Washer life is mostly about preventing repeat stress on high-wear systems (drain, suspension, and door lock). A small issue that is corrected early often prevents bigger failures later, especially on front-load washers.

Last updated: February 2026

The Frigidaire FTF2140FS1 is a 27-inch front-load washer. For installation planning, we use the model’s rough-in dimensions and clearance guidance in the FTF2140FS1 installation guide to confirm fit, hookups, and drain standpipe requirements.

What “size” usually means (and what to check)

When customers ask for washer size, it typically refers to one or more of these:

• Width (the common “27-inch” class)
• Overall height and depth (for closet or alcove fit)
• Capacity (cubic feet, how much laundry it holds)
• Hookup clearances (water inlet, drain standpipe height, power)

Installation measurements we use for this model

Based on the installation requirements for the FTF2140FS1, these are key fit and hookup specs to measure at home:

• Hot and cold faucets within 42 in. (107 cm) of the water inlet
• Water pressure between 30 and 120 psi
• Standpipe height 24 to 96 in. above the floor
• Standpipe diameter 1-1/4 in. (3.18 cm) minimum
• Drain must handle 17 gal (64.3 L) per minute

Quick reference table

What to measure	Target for FTF2140FS1 install	Why it matters
Washer width class	27 in.	Cabinet and doorway fit
Faucet distance to inlet	Within 42 in.	Hose reach and leak prevention
Standpipe height	24 to 96 in.	Prevents siphoning and drain overflow
Water pressure	30 to 120 psi	Proper fill and valve operation

Why it matters

A washer can be “27 inches” wide and still not fit if the depth, door swing, drain height, or hose routing is tight. Confirming rough-in dimensions and drain requirements prevents vibration issues, slow draining, and installation rework.

Helpful tip for accurate fit

We recommend measuring your space and comparing it to the diagrams in the FTF2140FS1 installation guide. If you are stacking or using a pedestal, follow the accessory-specific instructions referenced in the guide.

Last updated: February 2026

On the Frigidaire FTF2140FS1 front-load washer, the “filter” most people mean is the drain pump clean-out (coin trap) located at the very bottom front of the cabinet, behind the lower toe panel. Access is from the front, close to the floor; have towels ready for water.

Where to look on the FTF2140FS1

• Check the lower front of the washer, near the floor.
• Remove the toe panel to reach the drain pump clean-out.
• The clean-out cap is typically on the front of the drain pump housing.
• Place a shallow pan and towels under the opening before loosening the cap.
• For the exact panel removal steps for your unit, follow the FTF2140FS1 installation guide.

Quick access checklist (before you open it)

• Unplug the washer (or switch off the breaker).
• Turn off both water supply valves.
• Keep towels and a shallow container ready.
• Open the cap slowly to control the water flow.
• Clear coins, lint, and small items; then reinstall the cap snugly.

What you will see once the toe panel is off

Item	What it does	Common symptom when clogged
Drain pump clean-out (coin trap)	Catches debris before it reaches the pump	Won’t drain, slow drain, water left in tub
Drain pump	Moves water out through the drain hose	Hums but won’t drain, grinding noise

If the clean-out is clear but the washer still will not drain, the pump itself can be the failure point; the correct replacement for this model is the washer drain pump 137221600.

Why it matters

A clogged pump clean-out can cause no-drain errors, standing water, odors, and repeated cycle interruptions. Cleaning it periodically helps protect the drain pump and keeps spin performance consistent.

Last updated: February 2026

Frigidaire front load washers (including model FTF2140FS1) are made under the Frigidaire brand, which is part of Electrolux. That means Electrolux is the parent company behind Frigidaire-branded laundry products.

What this means for parts and service

For your Frigidaire FTF2140FS1 washer, you should match parts by the full model number and the exact part ID to ensure fit and electrical compatibility. The best place to confirm model-specific details (features, electrical requirements, and troubleshooting steps) is the FTF2140FS1 owner's manual.

• Use the complete model number FTF2140FS1 when searching parts.
• Match by part ID (not just a description) when ordering.
• Follow the installation requirements for a properly grounded 3-prong outlet.
• Use low-sudsing HE detergent designed for front-load washers.
• Check the troubleshooting section before replacing parts.

Common parts customers replace on this model

If the washer will not start or the door will not lock, the door lock is a common first check on front-load designs.

Symptom	Common area to check	Example part for FTF2140FS1
Door won’t lock, cycle won’t start	Door lock system	Door lock switch 131763256
Won’t drain or leaves water in tub	Drain pump, drain path	Washer drain pump 137221600
Excessive vibration or banging	Suspension/shocks, leveling	Shock absorber 5304485917

Why it matters

Knowing the manufacturer behind the brand helps when you are comparing documentation, sourcing correct replacement parts, and following installation and grounding requirements. For safe operation, we recommend following the electrical and grounding guidance in the FTF2140FS1 installation guide.
