Kenmore Elite 79044119110 cooktop Parts

To unlock the control lock on your Kenmore Elite cooktop model 79044119110, press and hold the Control Lock (padlock) touch control until the lock indicator light turns off. Once the light goes out, the cooktop controls respond normally again. See the exact key location in the 79044119110 installation guide.

Quick unlock checklist

• Make sure the cooktop is powered on (breaker on) and the control panel is responsive.
• Press and hold the Control Lock touch pad (padlock icon) for several seconds.
• Watch for the lock indicator light to turn off.
• If the panel beeps but stays locked, wipe the glass over the touch area and try again.
• If the cooktop was just used, let the surface cool slightly and retry (heat and moisture can affect touch response).

If it still will not unlock

A cooktop that will not unlock is usually dealing with a touch-control input issue (moisture, residue, or a stuck control), or a power reset is needed.

Try a safe power reset

1. Turn the cooktop circuit breaker off for 1 minute.
2. Turn the breaker on.
3. Try the Control Lock press-and-hold again.

Check for common causes

• Grease film, cleaner residue, or water droplets on the glass near the touch keys
• A utensil or object resting on the control area
• A knob or switch issue on models with mechanical controls (less common on touch-lock symptoms)

Parts that relate to “won’t change settings” symptoms

If the cooktop unlocks but a burner still will not adjust heat, the issue is often a surface element control switch or knob.

Symptom	Most likely part area	Example part for this model
Burner stuck on one heat level	Element control switch	Cooktop element control switch 318531500
Knob loose, cracked, or slipping	Control knob	Cooktop element control knob (black) 316353554
Burner will not heat at all	Radiant surface element	Range radiant surface element 8583165300010

Why it matters

The control lock is a safety feature that prevents accidental burner activation during cleaning. Unlocking correctly avoids forcing controls and helps prevent damage to the glass touch area.

You can order replacement parts for Kenmore Elite 79044119110 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

For the Kenmore Elite electric cooktop model 79044119110, the installation instructions list two size sets (30-inch and 36-inch versions). Use the product dimensions table in the installation guide to match your exact cooktop width and depth before measuring your countertop cutout.

Product dimensions (from the installation instructions)

These are the overall cooktop and chassis dimensions shown in the install document.

Size family	Glasstop width (A)	Cooktop depth (B)	Chassis width (C)	Chassis depth (D)
30-inch cooktop	30 3/4 in	22 1/16 in	28 1/2 in	20 77/32 in
36-inch cooktop	36 3/4 in	22 1/16 in	34 7/2 in	20 77/32 in

How we recommend confirming which size you have

Because “Kenmore Elite” is a product line (not a single size), we use the install dimensions to identify whether your unit is the 30-inch or 36-inch configuration.

• Measure the visible glass top left-to-right (this is the glasstop width).
• Measure front-to-back across the glass (this is the cooktop depth).
• Compare your measurements to the table above.
• If you are installing into a counter, also verify the cutout dimensions and clearances in the installation guide.

Why it matters

Correct dimensions prevent countertop cutout mistakes and help ensure safe clearances. The installation instructions also call out key spacing needs, including clearance to overhead cabinetry and space below the cooktop for the electrical cable and junction box.

Related installation specs to keep in mind

These are common “gotchas” that affect fit and planning for this Kenmore Elite cooktop installation.

• Electrical supply: single-phase, 3-wire or 4-wire, 120/240V or 120/208V, 60 Hz AC with ground.
• Minimum clearance to unprotected overhead cabinetry: 30 inches.
• Allow space below the cooktop for wiring and junction box placement.
• Handle the cooktop by the sides during installation; avoid loading weight on a corner.

Ordering parts by model

When you are ready to repair or replace components (like a control switch or knob), order parts for 79044119110 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

The average lifespan of the Kenmore Elite cooktop model 79044119110 is 13 years with normal household use and basic care (proper cookware, avoiding overheating, and keeping controls and ventilation clean). Use the owner's manual for model-specific care and operating guidance.

What affects lifespan most

• Heat cycling: frequent high-heat use shortens element and switch life.
• Cookware fit: flat-bottom pans that match the element size reduce stress.
• Spills and boilovers: liquids that reach the controls can damage switches and wiring.
• Ventilation (downdraft models): restricted airflow makes components run hotter.
• Electrical health: loose connections and heat damage accelerate failures.

Typical lifespan by component (what usually wears first)

Component	Typical issue	Common symptom
Radiant surface element	Element opens or heats unevenly	Slow heat, no heat, hot spots
Infinite switch (element control)	Contacts wear or overheat	Stuck on high, cycling wrong, no heat
Knob	Cracks or strips	Knob spins, won’t turn switch
Downdraft blower (if equipped)	Motor wear or grease buildup	Loud fan, weak suction

Maintenance that helps you reach (or beat) 13 years

• Keep the cooktop surface clean and dry; wipe up spills promptly.
• Avoid dragging cookware; it can damage the surface and lead to stress cracks.
• Do not block airflow; keep the downdraft intake and duct path clear.
• If a burner won’t regulate heat, replace the correct switch for your model (for example, cooktop element control switch 318531500 if it matches the failed position).
• If a knob is loose or stripped, replace the matching knob (for example, cooktop element control knob (black) 316353554).

Why it matters

Knowing the expected lifespan helps you decide whether to repair a heating issue (often a switch, element, or knob) versus planning a replacement. On a 79044119110 cooktop, many performance problems are repairable with the right Kenmore-approved parts and safe installation practices.

Last updated: March 2026
