LG LRSC26922SB refrigerator Parts

The LG LRSC26922SB is typically a 26 cu. ft. class side-by-side refrigerator (commonly listed around 25.9 cu. ft.). For the exact total and compartment breakdown for your unit, use the capacity specs in the LRSC26922SB owner’s manual.

How to confirm the exact capacity for LRSC26922SB

Capacity can vary slightly by how manufacturers round, and some listings show “class” capacity instead of an exact number. The most reliable way is to confirm it in the model’s documentation.

• Check the “Specifications” section in the manual for total capacity
• Look for separate refrigerator and freezer compartment capacities
• Use the model number on the rating label to confirm you have LRSC26922SB
• If you are comparing to another LG model, compare “total capacity” and “usable capacity” the same way

Why you might see different numbers online

Many retailers and spec sheets round differently. Here is how the numbers usually show up:

What you see	What it means	What to use for planning
26 cu. ft. class	Rounded “size class”	Shopping comparisons
25.9 cu. ft.	Common exact listing	Closer estimate
Compartment-only numbers	Separate fridge/freezer volumes	Food storage planning

Why it matters

Knowing the true cubic feet helps when you are matching a replacement refrigerator, planning kitchen fit and airflow space, or comparing storage between side-by-side models.

Last updated: January 2026

On the LG LRSC26922SB, a “22 22” display is commonly treated as a diagnosis code pointing to a compressor start problem; the refrigerator may click repeatedly and struggle to cool. A frequent fix is replacing the compressor start relay, then rechecking cooling performance.

What you’ll usually notice

• Repeated clicking from the back of the refrigerator (near the compressor)
• Warm refrigerator and freezer temperatures
• Compressor tries to start, then stops
• Interior lights work, but cooling is weak or stops
• Code returns after a power reset

Quick checks before replacing parts

1. Keep power on so the diagnostic function can help identify the failure (LG notes diagnostics work best when power is not interrupted). See the LRSC26922SB owner’s manual.
2. Confirm the doors are closing fully; warm air intrusion can mimic cooling failures.
3. Make sure the condenser area is not blocked by dust buildup or items behind the unit.
4. Listen for a click every few minutes; that pattern strongly matches a start device issue.

Parts that commonly solve “22 22” symptoms

If the clicking and no-cool symptoms match, these are the most common repair paths:

Symptom	Most likely part	Notes
Clicking, compressor will not stay running	Compressor start relay	Often the first part to replace
Runs but still not cooling well	Compressor	Sealed-system repair; typically pro service
Cooling issues plus weak airflow	Evaporator fan motor	Airflow problems can cause warm temps

For this model, the start device is the refrigerator compressor start relay EBG32952202.

Why it matters

When the compressor cannot start reliably, the refrigerator cannot remove heat, so temperatures rise quickly and food safety becomes a concern. Addressing the start relay early can prevent extended warm periods and repeated cycling.

Last updated: January 2026

If your LG LRSC26922SB side-by-side refrigerator is not freezing, the most common causes are incorrect temperature settings, doors not sealing or being opened too often, or an airflow problem. If settings and airflow are good, a failed start relay, compressor, or control issue can prevent proper freezing.

Quick checks we recommend first

• Set the freezer control colder and give it time to stabilize; a refrigerator needs time to reach the selected temperature after changes.
• Confirm both doors close completely and stay closed.
• Reduce door openings; warm air entering raises freezer temperature.
• Do not block air vents with food; smooth circulation keeps temperatures even.
• Wait after loading warm groceries; the freezer may need time to pull down.

What to check next (cooling system and airflow)

A side-by-side that cools poorly often has a problem moving heat out (condenser area) or moving cold air around (fans and ducts).

• Listen for the condenser fan near the compressor; it should run when the compressor runs.
• Check for heavy dust on the condenser area; restricted airflow reduces freezing performance.
• Listen for the evaporator fan inside the freezer; if it is not running, cold air will not circulate.

If you want model-specific operating and temperature-control guidance, use the LRSC26922SB owner’s manual.

Parts that commonly affect “not freezing” symptoms

If the freezer is warm and you also notice clicking, humming without cooling, or intermittent cooling, these parts are common suspects:

Symptom you notice	Most likely area	Example part for LRSC26922SB
Clicking, compressor tries to start then stops	Start components	Refrigerator compressor start relay EBG32952202
No water to ice maker and other water issues at same time	Water supply system (separate from cooling)	Refrigerator water inlet valve 5221JB2006K
Warm freezer and poor heat removal at back/bottom	Condenser airflow	Refrigerator dc motor 4681JB1029B
Warm freezer, no air movement inside	Evaporator fan system	Refrigerator motor assembly 4681JB1029A

Why it matters

A freezer that is not freezing can lead to food spoilage and can also force the compressor to run longer than normal. Catching a door, airflow, or fan issue early often prevents bigger cooling-system problems.

Last updated: January 2026

LG side-by-side refrigerator prices vary widely by size, finish, and features; for an older model like LG LRSC26922SB, the most reliable “price” today is the cost of the specific replacement part or repair you need, not a single new-unit price. Use the LRSC26922SB owner’s manual to confirm features and configuration before comparing models.

What you can expect to pay (typical ranges)

New LG side-by-side refrigerators are typically priced in a broad range depending on capacity and options.

• Entry level: about $1,000 to $1,600
• Mid-range: about $1,600 to $2,500
• Premium: about $2,500 to $4,000+

LRSC26922SB: common repair costs you can compare instead

If you are pricing your LRSC26922SB because it is not cooling, not dispensing water, or not making ice, comparing key part costs is often more useful than trying to match a new-unit price.

What you’re pricing	Example part for LRSC26922SB	What it affects
Water not dispensing or slow fill	Refrigerator water inlet valve 5221JB2006K	Water flow to dispenser and ice maker
Bad taste, low flow, overdue maintenance	Refrigerator water filter 5231JA2006A	Water quality and dispenser flow
No cooling, loud running, won’t start	Refrigerator compressor (model-specific)	Sealed system cooling

Quick checks before you spend money

These steps help you avoid buying a part you do not need.

• Confirm the refrigerator and freezer controls are not set too warm.
• Make sure doors close fully; warm air entering can raise temperatures.
• Reduce frequent door openings and allow several hours for temperatures to stabilize.
• If the door is not closing smoothly, level the unit and adjust door height as shown in the manual.
• If you are troubleshooting water or ice, replace the filter first if it is overdue.

Why it matters

A “price” question usually comes down to a decision: repair vs. replace. For the LRSC26922SB, knowing the cost of high-impact parts (water inlet valve, water filter, fan components, compressor-related parts) helps you estimate repair value more accurately than comparing to an unrelated new model.
