Kenmore 79060712902 gas range Parts

A Kenmore gas range like model 79060712902 typically lasts 15 years with normal household use. Keeping burners clean, ensuring proper gas flow, and following the care steps in the 79060712902 owner's manual helps you get full life from key parts like the igniter and gas valve.

What affects lifespan most

• Daily cooking load and high-heat use (frequent broiling, long bakes)
• Cleaning habits (grease buildup around burners and oven venting)
• Proper installation and grounding (power cord and outlet condition)
• Wear items (knobs, grates, seals, igniters) replaced as needed
• Gas quality and correct pressure regulation

Maintenance that adds years (simple, high impact)

• Clean spills promptly; avoid harsh cleaners not recommended for range surfaces.
• Keep surface burner ports clear so flames stay even and blue.
• Clean the cooktop and exterior with hot, soapy water; rinse and dry.
• For stubborn spots, use the ammonia soak method described in the manual, then rinse thoroughly.
• Inspect the oven door seal for gaps that let heat escape.

Common “end-of-life” symptoms and likely fixes

Symptom	What it often points to	Example part for this model
Oven won’t ignite or takes too long to light	Weak igniter	Range oven burner igniter 5304509706
Oven temperature swings widely	Burner/ignition or gas flow issue	Burner and ignition system checks in the manual
Smell of gas or inconsistent flame	Gas regulation or valve issue	Range pressure regulator 5304521339
Heat leaking, longer cook times	Worn door seal	Frigidaire range oven door seal 316239700

Why it matters

A gas range can keep working well past the midpoint of its life, but performance and safety depend on clean combustion and reliable ignition. Replacing a worn igniter or door seal on time often restores normal baking and reduces wasted heat.

Last updated: February 2026

On the Kenmore 79060712902 gas range, you typically do not fully remove the cooktop to access the burner box; you lift the front of the cooktop and lock it in the raised position using the support rods for cleaning or service access. Follow the steps in the 79060712902 owner’s manual to avoid bending the top or damaging burner parts.

Before you start (safety and prep)

• Turn all surface burner knobs to OFF and let the range cool completely.
• Shut off the gas supply if you will be working near the manifold or regulator.
• Disconnect electrical power (unplug or switch off the breaker) before servicing.
• Remove cookware and clear the counter space around the range.
• Use a towel or cardboard to protect the finish while you lift the cooktop.

Steps to lift the cooktop (hinged top)

1. Remove the burner grates (and drip pans if your version has them).
2. Grasp the cooktop at both front sides.
3. Lift up from the front edge until the cooktop support rods snap into place and hold the top up.
4. Clean or service underneath as needed.

To lower the cooktop

• Hold the front corners of the cooktop, push back on each support rod with the heel of your hand to release the notch, then gently lower the top.

If you need more access: removing surface burners

If the cooktop needs to be raised and the burners removed for cleaning or service:

• Remove the surface burner mounting screws.
• Tilt the burner to release the locator tab (front burners tilt right; rear burners tilt left).
• Slide the burner toward the back to separate it from the gas valve.

Task	What you usually remove	Tool
Lift cooktop for cleaning	Grates (and drip pans on some models)	None
Remove surface burner	Mounting screws	Phillips screwdriver
Access regulator area	Cooktop raised and locked	Wrench (as needed)

Why it matters

Lifting and supporting the cooktop the correct way prevents warped metal, chipped porcelain, and misaligned burners that can cause uneven flames or ignition problems.

Last updated: February 2026

On the Kenmore gas range model 79060712902, an oven that stops working is usually caused by a control setting issue, loss of electrical power (electric ignition), the gas supply being off, or a failed ignition or gas delivery component. Start with the basic power and gas checks, then move to ignition.

Quick checks we recommend first

• Confirm the oven controls are set correctly for Bake or Broil (not just the surface burners).
• Make sure the range is plugged in firmly (electric ignition models need power to light the oven burner).
• Check for a home power outage or a tripped breaker.
• Verify the gas supply is turned on.
• Confirm the regulator gas valve is in the ON position (see the 79060712902 installation guide).

Most common repair causes (gas oven)

If the range has power and gas but the oven still will not heat, these are the most common failures:

• Weak or failed oven igniter: the igniter may glow but not draw enough current to open the gas valve.
• Oven burner problems: burner ports can be blocked, or the burner can be damaged.
• Gas valve or regulator issues: gas may not be delivered to the oven burner correctly.
• Wiring or connection problems: loose or damaged wires can stop ignition.

Parts that often fix “oven won’t heat” on this model

Symptom	What you may notice	Part to consider
No ignition or delayed ignition	No glow, or long wait before lighting	Range oven burner igniter 5304509706
No gas flow to oven burner	Igniter works but burner never lights	Frigidaire range oven gas valve 3203459
Gas supply/pressure problems	Oven and burners act inconsistent	Range pressure regulator 5304521339

Why it matters

A gas oven needs both gas flow and a working ignition system. This model’s troubleshooting guidance also points to basic items like correct control settings, power to the range (for electric ignition), and the regulator valve being ON. Checking those first prevents unnecessary parts replacement.

Safety notes before troubleshooting

• Let hot surfaces cool; burners and oven surfaces can stay hot even when flames are not visible.
• Avoid spraying cleaners on electrical controls; it can cause shorts or sparking.
• If you smell gas, stop and have the gas supply and range checked by a qualified technician.

Last updated: February 2026

MTD 951-10292 is a small-engine spark plug reference, not a Kenmore 79060712902 gas range part. For this Kenmore range, we match replacements by the range model number and the exact range component (igniter, burner, regulator), using the 79060712902 installation guide and parts list.

What to do instead (fastest way to get the right replacement)

• Confirm the appliance is a Kenmore gas range model 79060712902 (model tag on the frame or storage/broiler drawer area).
• Identify the failing range function: oven won’t heat, surface burner won’t light, gas smell, or weak flame.
• If the oven is not igniting, the most common replacement is the oven igniter: range oven burner igniter 5304509706.
• If you are converting gas type (Natural gas to LP/Propane or back), follow the regulator and orifice steps in the 79060712902 installation guide.
• If you suspect a gas supply regulation issue, check the range regulator option: range pressure regulator 5304521339.

Common “replacement” matches for this model (by symptom)

Symptom on Kenmore 79060712902	Most likely area	Example part to check
Oven won’t light, no flame	Ignition system	Range oven burner igniter
Oven lights late, gas odor before ignition	Weak igniter or burner issue	Igniter, oven burner
Surface burner uneven flame	Surface burner assembly	Range surface burner
Converting to LP/Propane	Regulator and orifices	Regulator, LP orifices per guide

Why it matters

Spark plug numbers like 951-10292 are for engines; gas ranges use completely different ignition and fuel components. Matching by model 79060712902 prevents ordering a part that cannot fit or function safely.

Last updated: February 2026

On Kenmore gas range model 79060712902, the model and serial number are printed on the serial plate (identification plate) on the range. Use the plate information when ordering parts, scheduling service, or checking installation requirements; see the 79060712902 owner's manual for the serial plate location.

Common places to check on a freestanding gas range

We typically see the serial plate in one of these spots:

• Behind the oven door, along the door frame (door jamb)
• On the frame behind the storage or broil drawer (pull the drawer out)
• On the back panel near the upper vent area
• Along a side frame rail (visible after opening the door)

Quick steps to find it fast

1. Turn the oven light on and open the oven door.
2. Look along the left and right door frame for a sticker or metal plate.
3. If you do not see it, pull the bottom drawer out and look on the frame behind it.
4. Write down both the model and serial numbers exactly as shown.

What the label usually looks like

What you will see	Why it matters
Model number (starts with 790.)	Ensures diagrams and parts match your exact range
Serial number	Helps identify production details for correct replacement parts
Rating information	Useful for installation and troubleshooting

Why it matters

We use the model number to match the correct Kenmore parts (like an igniter, gas valve, or pressure regulator) to your exact configuration. A single digit difference can change the burner system, control layout, or hardware.

Last updated: February 2026
