Kenmore 79097453803 electric range Parts

To reset your Kenmore 79097453803 electric range, turn the range OFF, then cycle power at the home breaker (or unplug it) for about 1 minute and restore power. After power returns, reset the clock and reselect your oven function as needed (see the 79097453803 owner's manual).

• Turn all surface element knobs to OFF.
• If the oven is running, press Cancel/Off on the control.
• Turn OFF the range circuit breaker (or unplug the cord if accessible).
• Wait 60 seconds.
• Turn the breaker ON (or plug back in).
• Set the clock, then test Bake and Broil.

Our manual guidance is clear: do not operate the range during a power failure. Once power resumes, the range can start operating again if it was left on, so always turn it off and then reset the clock and oven function. The 79097453803 owner's manual covers this safety step.

A power-cycle reset clears temporary control glitches and restores normal operation after a power interruption. If a heating problem remains after the reset, it usually points to a failed heating component or temperature feedback issue rather than a control “memory” problem.

If the oven temperature is erratic or the oven will not maintain heat, these model-compatible parts are common suspects:

• Frigidaire range oven temperature sensor 316490000 (temperature feedback to the control)
• Frigidaire range bake element 316505500 (primary heat source for Bake)
• Frigidaire range broil element 316203301 (top heat source for Broil)

Last updated: February 2026

For Kenmore electric range model 79097453803, the model and serial number are printed on an identification (serial) plate located on the right side of the oven front frame inside the storage or warmer drawer compartment. Use the number exactly as shown when ordering parts.

Pull out the bottom drawer (storage or warmer drawer) and check these spots:

• Right side of the oven front frame (main serial plate location)
• The frame area just inside the drawer opening
• The label surface for a printed Model No. and Serial No.
• Nearby metal frame surfaces if the label is slightly offset

For a diagram and wording specific to this range, use the 79097453803 owner's manual.

Having the correct model number lets us match the right Kenmore-compatible parts and diagrams, including common repairs like:

• Oven not heating (bake element, broil element)
• Oven temperature problems (sensor)
• Surface element not working (element switch)
• Control or display issues (control board)

Kenmore model numbers can look similar across different 790-series ranges. Using the exact model number from the serial plate prevents ordering the wrong oven rack, temperature sensor, or control component.

Last updated: February 2026

A Kenmore electric range like model 79097453803 typically lasts 15 years with normal household use and basic maintenance. Keeping the oven door seal tight, elements heating evenly, and electrical connections secure helps you reach that lifespan.

• Heat stress on oven parts: frequent high-heat baking/broiling shortens element life.
• Power quality and wiring: loose terminal connections can overheat and damage wiring.
• Door sealing and insulation: heat leaks make the oven work harder and wear parts faster.
• Cleaning habits: spills left to bake on can damage finishes and create hot spots.
• Part replacement timing: replacing a failing part early prevents secondary damage.

If performance drops, these are typical repair parts for this model:

• Frigidaire range bake element 316505500: provides most of the oven’s baking heat.
• Frigidaire range broil element 316203301: provides top heat for broiling and assists preheat.
• Frigidaire range oven temperature sensor 316490000: tells the control board the oven temperature.
• Range oven door seal 316405000: keeps heat in the oven cavity for stable temperatures.

A range that holds temperature and seals properly cooks more evenly, preheats faster, and puts less strain on the oven control and wiring. That directly supports a full 15-year service life.

For model-specific operating and care recommendations (including control settings and safety guidance), use the owner's manual.
