Kenmore 25328052809 freezer Parts

For Kenmore upright freezer model 25328052809, the exact cubic-foot capacity is listed on the model’s rating label and in the 25328052809 owner's manual. If you do not have that number handy, we can still estimate capacity by measuring the interior and converting to cubic feet.

How to find the exact capacity (fastest method)

Check these common locations for the capacity and model data:

• Inside the cabinet on a side wall near the front
• On the door liner edge
• Behind the lower toe grille or near the bottom front frame
• In the specifications section of the 25328052809 owner's manual

How to estimate cubic feet from measurements

If the label is missing or unreadable, measure the usable interior (not the outside cabinet):

• Measure interior width, height, and depth in inches
• Multiply: W x H x D to get cubic inches
• Divide by 1,728 to convert to cubic feet

What you measure	Use this	Notes
Interior width	inches	Measure wall-to-wall at the widest usable point
Interior height	inches	Do not include the door gasket area
Interior depth	inches	Measure to the back wall, not into door bins

Typical upright freezer size ranges (helpful for a quick check)

Most upright freezers fall into these general capacity groups:

• Compact: 3 to 5 cu ft
• Small: 5 to 9 cu ft
• Medium: 10 to 16 cu ft
• Large: 17+ cu ft

Why it matters

Capacity helps you plan safe loading and freezing performance. For example, many upright freezers are designed so you freeze only a limited amount of fresh food per cubic foot at one time; overloading can slow pull-down and increase frost.

Last updated: January 2026

A 20 cubic foot upright freezer typically weighs about 170 to 230 lb when empty. For the Kenmore 25328052809, the exact shipping and net weight are listed in the 25328052809 owner's manual; the floor should be strong enough to support the freezer when fully loaded.

Typical weight range (what to expect)

Most freestanding 20 cu. ft. upright freezers fall into a fairly tight range because the cabinet insulation, door, and sealed system (compressor and evaporator) are similar across brands.

• Empty (net) weight: ~170 to 230 lb
• Shipping weight: often 10 to 30 lb higher due to packaging
• Heavier units usually have thicker insulation, larger door assemblies, or more shelving/baskets
• Lighter units often have simpler interiors or thinner cabinet construction

Why it matters

Weight affects delivery planning, floor support, and safe handling. The manual also emphasizes that the freezer must sit level on a solid floor to help the door seal correctly and prevent cooling, frost, or moisture problems.

Quick planning guide

What you’re planning	Practical rule of thumb	Why
Moving the freezer	Plan for 2 adults and an appliance dolly	Reduces tip-over and injury risk
Installing in place	Confirm the floor can support a fully loaded freezer	Food load adds significant weight
Final positioning	Level the front feet so the door closes easily	Helps prevent air leaks and frost

Tips for moving and setting up

• Remove food, baskets, and loose shelves before moving.
• Keep the freezer upright during transport to protect the sealed system.
• Allow space around the cabinet for airflow; exterior surfaces can feel warm during operation.
• Level the unit after placement; a misaligned door can cause frost buildup.
• After plugging in, allow a cool-down period before loading unfrozen food (per the manual guidance).

Last updated: January 2026

For the Kenmore 25328052809 upright freezer, we recommend manually defrosting whenever frost buildup reaches about 1/4 to 1/2 inch. Many upright freezers need this about once a year, but high humidity, frequent door openings, or a weak door seal can make it necessary more often (check the frost level, not the calendar).

What the manual recommends

Our guidance comes straight from the care and defrosting instructions in the 25328052809 owner's manual. The manual notes that some upright freezers are frost-free (automatic defrost), but they still need occasional cleaning; for manual defrosting, it’s important to act when frost reaches the 1/4 to 1/2 inch range.

Quick signs it’s time to defrost

• Frost is thicker than a pencil (about 1/4 inch) on walls or shelves
• The door is harder to close or seems to “bounce” back
• Packages are getting frosty or stuck to surfaces
• You see frost building faster near the top (common from warm, moist air)
• Cooling seems less consistent after the door has been opened often

How to reduce how often you need to defrost

• Open the door less often and close it quickly
• Make sure food is cooled before placing it in the freezer
• Keep items organized so you can grab what you need fast
• Check for gaps, tears, or stiffness in the door gasket
• Use a plastic scraper between defrosts; never use metal tools

Defrost frequency guide (typical)

Usage and conditions	Typical manual defrost interval
Light use, low humidity	About once per year
Frequent openings, humid area	Every few months
Door not sealing well	Often, until the seal issue is fixed

Why it matters

Heavy frost acts like insulation and reduces airflow and heat transfer. That can make the freezer work harder, waste energy, and reduce usable storage space.

Last updated: January 2026
