For your Kenmore 79551314012 side-by-side refrigerator, cleaning the condenser coils means safely removing dust and pet hair from the coil area and the condenser fan so the refrigerator can release heat properly. We recommend doing this every 6 to 12 months (more often with pets).

Steps to clean the condenser coils

• Unplug the refrigerator (or switch off power at the breaker).
• Pull the refrigerator straight out to avoid damaging the water line.
• Remove the lower rear access panel or front toe grille (whichever your unit uses); see the 79551314012 owner's manual for panel locations.
• Vacuum loose debris first using a crevice tool.
• Brush the coils gently with a coil brush, then vacuum again.
• Clean the condenser fan area (if accessible) so airflow is not restricted.
• Reinstall the panel/grille, push the unit back carefully, then restore power.

What to use (and what to avoid)

Item	Recommended?	Why
Vacuum with crevice tool	Yes	Removes loose dust without bending fins
Soft coil brush	Yes	Lifts packed lint from coil surfaces
Compressed air	Sometimes	Can help, but can blow dust deeper if used carelessly
Water or wet cleaning	No	Increases risk of electrical damage and mess
Hard wire brush	No	Can damage coil fins and tubing

Signs the coils need cleaning

• Refrigerator runs longer than normal
• Cabinet feels hot on the sides
• Freezer or fresh food temps drift warmer
• You hear the condenser fan working harder than usual

Why it matters

Dirty coils trap heat, which forces the compressor to run longer. Keeping the condenser area clean helps maintain stable temperatures, improves energy efficiency, and can reduce wear on cooling components.

If you find the coil is damaged or the condenser fan area is obstructed by a broken mount or clip, we stock model-matched parts such as the refrigerator compressor mount retainer clip 4620JA3015A for Kenmore 79551314012. You can also search by model number on Sears PartsDirect.

Last updated: February 2026

The exact cubic-foot capacity for Kenmore model 79551314012 is listed on the model’s rating label and in the specifications section of the owner's manual. For most Kenmore 795 side-by-side refrigerators, capacity commonly falls in the 20 to 22 cu. ft. range.

How to find the exact cubic feet on your refrigerator

Check these common locations for the rating label (it typically lists total capacity in cubic feet):

• Inside the fresh food compartment on a side wall
• On the ceiling area inside the refrigerator section
• Behind the crisper drawers (on the liner wall)
• Inside the freezer compartment on a side wall
• On the hinge-side frame when you open the refrigerator door

Quick capacity guide (what you will typically see)

This helps you sanity-check what you find on the label for a Kenmore side-by-side.

Refrigerator type	Typical total capacity	What that means day to day
Side-by-side (standard width)	20 to 22 cu. ft.	Balanced fridge and freezer space
Side-by-side (larger)	23 to 26 cu. ft.	More door storage and wider shelves

Why the exact cubic feet matters

Capacity affects more than storage space. It helps us match the right replacement parts and troubleshoot performance issues (airflow, ice maker output, and temperature recovery) for your exact Kenmore configuration.

Parts that often relate to capacity and cooling performance

If you are checking capacity because cooling or ice production seems off, these are common related components for model 79551314012:

• Refrigerator thermistor 6500JB2002T (temperature sensing)
• Refrigerator evaporator fan motor 4681JB1029S (moves cold air through compartments)
• Refrigerator defrost heater ADL74581702 (prevents frost buildup that restricts airflow)

If you need to order parts after confirming your specs, we list model-matched parts on this page, and you can also search by model number on Sears PartsDirect.

Last updated: February 2026

If your Kenmore 79551314012 side-by-side refrigerator is warm, runs nonstop, or clicks on and off, the compressor or its start components may be failing. We confirm compressor trouble by checking cooling symptoms, compressor behavior, and basic electrical indicators, then following the troubleshooting steps in the 79551314012 owner’s manual.

Quick signs that point to a compressor problem

Look for a pattern of symptoms (not just one):

• Refrigerator and freezer both warm or only weak cooling
• Repeated clicking every few minutes (start attempt then shutdown)
• Compressor runs but cabinet temperatures keep rising
• Compressor is very hot after trying to run (avoid touching bare tubing)
• Fans run, lights work, but cooling does not recover after several hours

Check these first (often mistaken for a bad compressor)

These issues can mimic compressor failure on model 79551314012:

• Dirty condenser coil restricting heat removal (clean the coil area)
• Evaporator fan not running; airflow stops (see refrigerator evaporator fan motor 4681JB1029S)
• Heavy frost blocking airflow; points to a defrost problem (see refrigerator defrost heater ADL74581702)
• Fresh food warm but freezer cold; often an air movement issue, not the compressor

Symptom-to-next-step guide

What you observe	Test/area to check next	Why it matters
Clicking, won’t stay running	Start device/overload, compressor windings	A locked or failing compressor often cannot start under load
Runs constantly, still warm	Sealed system or compressor efficiency	Compressor may run but not pump effectively
Freezer OK, fridge warm	Air damper/airflow	Cold air is not moving to fresh food

Why it matters

A compressor replacement is a major repair; ruling out airflow, defrost, and fan problems first prevents unnecessary parts. If the compressor is confirmed failed, the model-correct replacement is the refrigerator compressor TCA37091210.

You can order model-specific parts from the parts list for Kenmore 79551314012, or search by model number on Sears PartsDirect.

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 79551314012 are not cooling, water leaks, ice maker or dispenser failures, and unusual noises. These usually come from restricted airflow, defrost ice buildup, drain or water-line clogs, or a failing fan, sensor, or control.

Common symptoms and likely causes

• Not cooling or warm temps: dirty condenser coil, evaporator fan not running, air damper stuck, defrost system icing
• Water under the unit or inside: clogged/iced defrost drain, split drain tube, loose water tube fitting
• Ice maker not making ice: low water flow, frozen fill path, failed ice maker assembly
• Dispenser problems: auger motor issues, ice clumps in bin, chute door motor not opening
• Rattling or grinding noises: fan blade hitting ice, worn fan motor, vibration at compressor mounts

Quick checks before replacing parts

• Set temps to 37°F (fresh food) and 0°F (freezer)
• Keep vents clear; avoid overpacking
• Check for heavy frost on the freezer back panel (defrost issue)
• Look for leak location: front floor (drain) vs. dispenser area (tubing)
• Listen for noise source: freezer (evaporator) vs. back/bottom (condenser/compressor)

Parts that often fix these issues on model 79551314012

Symptom	Example part	What it affects
No ice dispensing	Refrigerator auger motor EAU59551204	Drives ice through the dispenser
Water leaks from drain	Refrigerator drain tube 5251JA3003D	Routes defrost water to the drain pan
Warm or noisy freezer	Refrigerator evaporator fan motor 4681JB1029S	Circulates cold air
Frost buildup	Refrigerator defrost heater ADL74581702	Melts evaporator frost

Why it matters

Most “big” complaints start as small airflow or water-flow problems. Fixing them early protects food, prevents ice buildup, and reduces strain on the compressor and electronic control.

Helpful references

• Use the owner's manual for temperature settings, control locations, and access guidance.
• For ordering, use the parts list for model 79551314012 or search by model number on Sears PartsDirect.

Last updated: February 2026

Water leaking from your Kenmore 79551314012 side-by-side refrigerator is typically caused by a clogged or frozen defrost drain, or a drip from the ice maker and water dispenser tubing. Start by identifying whether the water is inside the compartments or underneath the cabinet.

Most common leak sources to check

• Defrost drain clog or ice plug: Water backs up during defrost and spills into the refrigerator or freezer.
• Drain tube not directing water to the pan: Water misses the drain pan and ends up on the floor.
• Water line connection drip: Push-in fittings can seep after the fridge is moved.
• Cracked water reservoir or internal tubing: Leaks show up as puddles under the fresh food section.
• Ice maker fill or dispenser area leak: Drips can track down the door or collect under the ice bin.

Quick troubleshooting steps we recommend

1. Unplug the refrigerator and remove food as needed for access.
2. Locate the leak:
   • Water inside the fridge or freezer often points to the defrost drain.
   • Water behind or under the unit often points to a supply line or fitting.
3. Clear the defrost drain: Melt visible ice, then flush the drain with warm water until it flows freely.
4. Inspect water tubing and fittings: Look for slow drips, reseat tubing fully, and check for kinks or rub-through.

Parts that commonly fix leaks on this model

What you see	What it usually means	Part to consider
Water pooling inside, then dripping out	Drain not carrying defrost water away	Refrigerator drain tube 5251JA3003D
Drip at a connection	Worn or loose connector	Refrigerator water tube fitting 4932JA3002C
Puddle under fresh food section	Reservoir or internal water path leak	Refrigerator water tank MJM61904702

Why it matters

Stopping a small leak early prevents ice buildup around the evaporator area, helps maintain stable temperatures, and protects flooring and nearby cabinetry.

For access panels, drain locations, and safe disassembly steps for model 79551314012, use the 79551314012 owner’s manual. If you need to order parts, use the parts list for this model or search by model number on Sears PartsDirect.
