Kenmore 25328432805 freezer Parts

For Kenmore model 25328432805, the most reliable way to determine cubic feet is to look up the capacity in the product specifications section of the 25328432805 owner's manual. If you need a quick estimate, we calculate interior volume by measuring usable inside dimensions and converting cubic inches to cubic feet.

1. Empty the compartment enough to measure the usable interior space.
2. Measure width x height x depth in inches (use the main cavity, not door bins).
3. Multiply the three numbers to get cubic inches.
4. Divide by 1,728 to convert to cubic feet.

• Measure in multiple spots if walls taper; use the smallest measurement.
• Exclude shelves, drawers, and the evaporator cover area if it reduces usable space.
• For an upright freezer, measure the main cavity and subtract any fixed hump or duct space.
• If you are planning a big load of fresh food, the manual guideline is about 3 lb per cubic foot at one time.

Kenmore model numbers sometimes hint at size families, but they are not a dependable “capacity code.” For 253-prefix Kenmore units (commonly Frigidaire-built), the model number helps identify the platform and parts, while the exact cubic feet is best confirmed in the 25328432805 owner's manual.

Capacity affects how you organize food, how long it takes to pull temperatures down after loading, and how much fresh food you can freeze at once without warming the cabinet.

If you are shopping for repair parts while you check capacity, you can also search by model number on Sears PartsDirect.

Last updated: February 2026

Kenmore upright freezer model 25328432805 does not use one single reset button for the entire unit. It uses an ALARM RESET button to silence the Hi Temp alarm; for a true “reset,” we typically power-cycle the freezer. See the 25328432805 owner's manual for control-panel details.

Most reset requests fall into these actions:

• Silence the alarm: Press ALARM RESET when the Hi Temp light is on and the buzzer sounds.
• Power-cycle the control: Unplug the freezer, wait 5 minutes, then plug it back in.
• Restore temperature: Let the freezer run until the cabinet temperature drops back to normal.

The manual explains that when the freezer is first plugged in, or if the inside temperature rises high enough, the Hi Temp indicator can light and the buzzer can sound.

• Press ALARM RESET to stop the buzzer.
• The Hi Temp light stays on until the temperature drops back down.
• If the alarm returns, look for the cause (door left ajar, warm food load, blocked airflow, or a cooling/defrost problem).

An “E” on some electronic-control versions points to a control-related fault. Use the Kenmore electronic control module freezer error codes guide to identify the code and the next checks.

• Confirm the outlet has power and the cord is firmly plugged in.
• Make sure the door closes fully and the gasket seals.
• Keep packages from blocking interior vents.
• After changing the temperature setting, allow several hours to stabilize.

Resetting the alarm is only acknowledging the warning; fixing the underlying warming issue protects food and prevents repeat alarms.

Last updated: February 2026

If your Kenmore upright freezer model 25328432805 stops freezing, the most common causes are a power or control setting issue, warm air leaking in through the door seal, poor airflow around the cabinet, or a failed cooling/defrost component (fan motor, defrost heater, thermostat, or electronic control). For model-specific operating and temperature guidance, use the 25328432805 owner's manual.

• Confirm the freezer is plugged in firmly and the outlet has power.
• Verify the temperature control is not set too warm; allow several hours after adjusting for temperatures to stabilize.
• Make sure the door closes and seals fully; a misaligned door can cause cooling and frost problems.
• Check that the freezer is level; leveling helps the door seal correctly.
• Allow space for air circulation around the freezer, especially in hot areas.

When an upright freezer can’t keep warm, moist air out or can’t move cold air across the evaporator, it may run longer, build frost faster, and still lose freezing performance. Fixing door sealing, leveling, and airflow often restores normal operation without replacing major parts.

• Freezer door gasket 5304507201
• Freezer evaporator fan motor 297309000
• Defrost heater 5304496687
• Refrigeration appliance defrost bi-metal thermostat 297216600
• Electronic control 297370602

To order replacement parts for model 25328432805, use the parts list for this model or search by model number on Sears PartsDirect.

Last updated: February 2026

On the Kenmore upright freezer model 25328432805, the model and serial number plate is typically on the upper left wall inside the freezer compartment. We recommend copying both numbers exactly as shown before ordering parts or using troubleshooting steps in the 25328432805 owner's manual.

If you do not see the label right away, check these spots (in this order):

• Upper left interior wall (most common for upright models)
• Side wall inside the cabinet near the front opening
• Ceiling area inside the freezer (some upright designs)
• Behind the lower kick plate or base panel area
• Back exterior panel of the cabinet

The plate is usually a sticker or metal tag. For the best results:

• Use a flashlight and look along the cabinet walls near the door opening
• Wipe frost or condensation off the surface so the print is readable
• Record both the model number and serial number (the serial helps match revisions)
• Take a clear photo for reference when ordering parts

The model number ensures we match the correct Kenmore freezer parts and diagrams for your exact configuration. Even small production changes can affect fit for items like a door gasket, electronic control, or door switch.

If you are ordering, you can shop the parts list for model 25328432805 on this page, or search by model number on Sears PartsDirect.

Last updated: February 2026
