Craftsman 917374200 lawn mower Parts

On a Craftsman walk-behind mower like model 917374200, the model number is typically printed on a decal or tag on the mower deck (often near the rear discharge area) or on the rear of the deck near the height-adjustment hardware. Use the 917374200 owner's manual to confirm the exact label location and format.

Check these common spots first (wipe off grass and dirt so the decal is readable):

• Top of the mower deck, near the engine mounting area
• Rear of the deck, behind the engine and above the rear wheels
• Side of the deck near the discharge chute or discharge guard
• Handle bracket area where the upper and lower handles bolt together
• Under the rear door or near the bagging opening (if equipped)

For this Craftsman mower, the manual identifies the model as 917.374200 (you may see it printed with or without the dot). When ordering parts, use the full model number 917374200.

• Match the model number exactly; one digit off can change the blade, cable, or deck parts
• If the decal is damaged, compare your mower’s handle and deck style to the diagrams in the manual
• For common wear items, verify fit by description and diagram callouts (blade, blade adapter, control cable)

The model number ties your mower to the correct parts diagram and hardware sizes. For example, model 917374200 uses a 21-inch blade listed in the parts breakdown; matching the model helps ensure you get the correct cutting system components.

Last updated: February 2026

Common problems we see on the Craftsman 917374200 walk-behind mower include hard starting or a starter rope that is hard to pull, loss of power, poor or uneven cutting, excessive vibration, and drive issues (self-propelled models). Most of these trace back to blade condition, grass buildup under the deck, or routine tune-up items listed in the 917374200 owner's manual.

• Starter rope hard to pull: operator presence control bar not held down, blade dragging in grass, or a damaged blade adapter
• Loss of power: cutting height too low, clogged air filter, grass and debris packed under the deck, or too much oil
• Poor cut or uneven cut: worn/bent/loose blade, wheel height set unevenly, or deck buildup
• Excessive vibration: bent/loose blade or impact damage (stop using the mower until inspected)
• Hard to push: grass too tall, cutting height too low, grass bag overfilled, or handle height not comfortable

1. Move the mower to a hard surface and clear grass and debris from the underside of the deck.
2. Verify all wheels are set to the same cutting height.
3. Inspect the blade for bends, cracks, or heavy wear; replace if damaged.
4. Confirm you are holding the operator presence control bar down before pulling the starter rope.
5. If self-propelled, check for drive belt wear or a drive cable problem.

These issues affect safety and cut quality. A worn or loose blade can cause vibration and damage, and grass buildup under the deck can overload the engine and reduce performance. The manual also stresses using caution around sharp blades and replacing worn components with recommended parts.

Last updated: February 2026

For the Craftsman walk-behind mower model 917374200, the owner’s documentation specifies a Briggs & Stratton 550 Series engine. Craftsman has used multiple engine brands across different mower lines and years, but this specific model is Briggs & Stratton.

Your mower is identified in the documentation as:

• Craftsman model 917374200
• Rotary lawn mower, 21-inch Multi-Cut
• 550 Series Briggs & Stratton gas engine

For model-specific confirmation, use the 917374200 owner’s manual.

Craftsman is a brand label used across many outdoor power products, and engine sourcing can differ by:

• Product type (push mower vs. riding mower)
• Model year and production run
• Deck size and drive system (push vs. self-propelled)
• Supplier changes over time

That is why it’s normal to see Briggs & Stratton on one Craftsman mower and a different engine brand on another.

Use these checks (no disassembly needed):

• Look for the engine shroud decal that says Briggs & Stratton
• Check the engine model/type code label (often near the muffler or recoil housing)
• Match the mower model number 917374200 in the 917374200 owner’s manual
• If ordering engine-related hardware, match by diagram and part ID, not by appearance alone

The engine brand and engine model number determine the correct maintenance parts and specs (oil type/amount, spark plug, air filter, carburetor parts). Using the wrong engine information is a common reason tune-ups and no-start fixes don’t hold.

Last updated: February 2026

The model number is 917.374200 (often written without the dot as 917374200). This is the Craftsman rotary lawn mower model shown on the identification page of the 917374200 owner's manual.

You can confirm the model number on the mower itself by checking the model tag or label. Common locations include:

• On the rear of the deck near the discharge opening
• On the deck surface near the engine mounting area
• On the handle support area (near where the handle bolts to the deck)
• In the documentation that came with the mower

This Craftsman mower has two different identifiers: the mower model number and the engine model number.

Using the correct mower model number (917.374200) ensures you get the right walk-behind mower parts, diagrams, and hardware. For example, the correct blade and blade mounting parts are selected by mower model, not just by engine series.

If you are replacing cutting components, match parts to the mower model, such as the lawn mower 21-in deck mulching blade 532406706 and the husqvarna lawn mower blade adapter 532418373.

Last updated: February 2026

The model number for this Craftsman walk-behind mower is 917.374200 (often written without the dot as 917374200). You can confirm it on the model tag and in the 917374200 owner's manual.

Most Craftsman walk-behind mowers list the model number on a label or stamped plate. Check these common spots:

• Rear of the deck near the discharge opening
• Top of the deck behind the engine
• Near the rear door or rear skirt area
• On the handle support area (varies by build)

Both formats refer to the same mower; the dot is a formatting style used in some manuals and labels.

It is normal to see other identifiers that are not the mower model number:

• Engine model number (this mower uses a Briggs & Stratton 550 Series engine; the manual shows engine model family 9P702-0211-F1)
• Part numbers for replacement items (blade, adapter, fasteners)
• Serial number (used to identify production run)

Using the exact model number 917374200 helps us match the correct Craftsman parts diagrams and ensure you get the right replacement parts (for example, a correct-fit blade or blade adapter).

Last updated: February 2026

The Craftsman 917374200 is not a riding mower; it is a Craftsman rotary walk-behind lawn mower (21-inch Multi-Cut) with a Briggs & Stratton 550 Series engine. To identify the exact production year for your specific unit, use the model and serial information shown in the 917374200 owner’s manual.

We use the model and serial number to determine the build date; the model number alone (917374200) identifies the product family.

• Look for the model/serial label on the mower deck, rear housing, or handle support area.
• Write down the serial number exactly as shown.
• Compare the label details to the identification information in the manual.
• If the label is dirty or faded, clean it gently and take a clear photo before it wears further.

The production year affects which parts and specs match your mower, especially for wear items like the blade, control cable, and hardware. For example, the parts list for this model includes the husqvarna lawn mower zone control cable 532440934 and other model-specific components.

Last updated: February 2026
