Whirlpool WEE750H0HZ5 slide-in electric range Parts

On the Whirlpool WEE750H0HZ5 slide-in electric range, the most commonly replaced parts are the oven heating elements and cooktop heating components, plus the switches that control them. These parts take the most heat and electrical load, so they are the first places we check when baking or a surface burner stops heating.

Most common replacements for this model

• Oven bake element (oven not heating evenly or at all): bake element W10779716
• Oven broil element (no broil or weak broil): element-broi W11321472
• Radiant surface elements (one burner not heating): element (1200w)(left rear & right rear) W11171119 or range surface element, left rear WPW10342780
• Burner control switches (burner stuck on, won’t change heat, or cycles wrong): range infinite switch W10917724 or infinite switch W11129442
• Small but common hardware items (loose panels, rattles after service): range leveling leg WPW10058460 and range screw W10777162

Quick symptom-to-part guide

Symptom	Most likely area	Part examples for WEE750H0HZ5
Oven won’t bake	Bake circuit	Bake element W10779716
Oven won’t broil	Broil circuit	Element-broi W11321472
One cooktop burner dead	Surface element	W11171119, WPW10342780
Burner heat won’t adjust	Infinite switch	W10917724, W11129442
Range rocks or won’t sit flat	Leveling	WPW10058460

How we recommend confirming the right part before ordering

• Match the failed function to the circuit (bake, broil, or a specific surface burner).
• Inspect for visible damage (blisters, breaks, burn marks on an element).
• If you have a multimeter, test the element or switch for continuity.
• If multiple heating functions fail, check wiring connections and harnesses for heat damage.
• Use the model-based parts list for WEE750H0HZ5 to avoid ordering a similar-looking part that does not fit.

Why it matters

Replacing the correct heating element or infinite switch restores safe, predictable temperature control. That protects cookware, improves baking results, and prevents a burner from overheating or failing again due to a poor electrical connection.

Last updated: February 2026

On a Whirlpool WEE750H0HZ5 slide-in electric range, a failing oven control board commonly shows up as a dead or flickering display, keypad buttons that do not respond (or act on their own), random beeping, or bake/broil that will not start or heats unpredictably. Use basic checks to rule out a failed heating element first.

Common symptoms you can see on WEE750H0HZ5

• Display is blank, flickers, resets, or shows intermittent characters
• Oven will not start Bake or Broil even though the cooktop works
• Temperature is erratic (overheats, underheats, or cycles strangely)
• Keypad is unresponsive, delayed, or triggers the wrong function
• Error codes appear repeatedly after clearing power
• Cooling fan runs at odd times or seems to run constantly
• You notice a burnt-electronics smell or visible scorching on the board (after power is off)

Quick checks before blaming the control board

1. Power reset: Turn the range breaker off for 1 minute, then back on. If symptoms return quickly, the issue is persistent.
2. Check for a simple heat failure: If the oven runs but does not heat, inspect and test the heating elements.
3. Look for a single-function failure: If only Bake fails, the bake element W10779716 is a common suspect. If only Broil fails, check the element-broi W11321472.
4. Surface burner odd behavior: If a surface element is stuck on high or will not regulate, a failed infinite switch can mimic “control” problems.

Symptom-to-part clues (fast guide)

What’s happening	More likely cause	What to check next
Display dead or random resets	Control board, power supply issue	Breaker, terminal connections, board area for heat damage
Oven won’t heat but display works	Heating element, relay, wiring	Test bake/broil elements and wiring harness connections
One surface burner won’t regulate	Infinite switch	Try the matching switch such as range infinite switch W10917724
Buttons don’t respond or act “possessed”	Keypad/control board	Inspect ribbon connector, moisture/grease intrusion, board damage

Why it matters

A bad control board can prevent safe temperature control and can also be a “victim” of another failure (shorted element, damaged wiring, or a failing switch). Identifying the real root cause helps you avoid replacing the wrong Whirlpool range part.

Last updated: February 2026

A Whirlpool stove typically lasts 13 to 15 years. For your Whirlpool WEE750H0HZ5 slide-in electric range, consistent cleaning, avoiding overheating, and replacing wear parts (like heating elements or switches) on time helps you reach that full service life.

Typical lifespan (what to expect)

Most electric ranges fall into a predictable window based on heat cycles and how hard the cooktop and oven are used.

Appliance type	Typical lifespan	What shortens it fastest
Electric range (like WEE750H0HZ5)	13 to 15 years	Heavy high-heat use, spills into controls, poor airflow
Gas range	15 to 18 years	Burner clogging, ignition wear, corrosion

Signs your range is nearing end of life

If you see these issues repeatedly, repairs can stack up quickly.

• Oven takes much longer to preheat or won’t hold temperature
• One or more surface elements heat unevenly or not at all
• Controls act erratically (infinite switch settings don’t match heat output)
• Frequent breaker trips or burning smell from wiring
• Door doesn’t seal well, causing heat loss and longer bake times

Repairs that commonly extend life

On the WEE750H0HZ5, these are common, practical fixes that often restore normal cooking performance.

• Replace a weak oven heater: bake element W10779716
• Restore broil performance: element-broi W11321472
• Fix a burner that won’t regulate heat: range infinite switch W10917724 or infinite switch W11129442
• Replace a failed radiant element (rear positions): element (1200w)(left rear & right rear) W11171119

Why it matters

A range that heats correctly and regulates temperature accurately cooks faster, uses less energy, and reduces the chance of overheating wiring or damaging the cooktop. Timely replacement of heating and control parts is the simplest way to keep a Whirlpool electric range running for its full lifespan.
